| 視頻壓縮 | H.265 Pro/H.265 When 1080p Lite mode is not enabled: 3K Lite/5 MP Lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K Lite/5 MP Lite/4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF Main stream: When 1080p Lite mode not enabled: For 3K stream access: 3K Lite@12 fps; 4 MP Lite/1080p@15 fps; 720p/WD1/4CIF/VGA/CIF@20 fps For 5 MP stream access: 5 MP Lite@12fps; 4 MP Lite/10 |
|---|
| Frame Rate | (P)/30 fps (N) For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode enabled: 3K Lite/5 MP Lite@12fps; 4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N) According to the actual scene, scene-adaptive |
|---|
| 音訊壓縮 | G.711u |
|---|
| Audio Bitrate | 64 Kbps 1-ch |
|---|
| IP 視頻輸入 | Up to 6 MP resolution Support H.265+/H.265 IP cameras 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection 5 MP@20 fps, 3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps |
|---|
| AHD Input | 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
|---|
| HDCVI Input | 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
|---|
| CVBS Input | Support |
|---|
| HDMI 輸出 | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
|---|
| VGA 輸出 | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
|---|
| 視頻輸出模式 | HDMI/VGA simultaneous output |
|---|
| 音訊輸入 | 4-ch via coaxial cable |
|---|
| 音訊輸出 | 1-ch via HDMI |
|---|
| 同步回放 | 4-ch 72 Mbps Incoming bandwidth: 4 Mbps |
|---|
| 網絡協議 | TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS |
|---|
| 遠程連接 | 32 |
|---|
| 網絡接口 | 1, RJ45 10/100 Mbps self-adaptive Ethernet interface Built-in 512 GB eSSD (480 GB available) Note: The device can store about 2 weeks videos for 4-ch analog cameras (default parameters), this estimation is for reference only |
|---|
| USB 接口 | Rear panel: 2 × USB 2.0 |
|---|
| 警報輸入/輸出 | N/A |
|---|
| 供電 | 12 VDC, 1 A |
|---|
| 功耗 | ≤ 5.4 W (with eSSD) |
|---|
| 工作溫度 | -10 °C to 45 °C (14 °F to 113 °F) |
|---|
| 工作濕度 | 10% to 90% |
|---|
| 尺寸 | 151 × 121 × 46 mm (5.94 × 4.76 × 1.81 inch) |
|---|
| 重量 | ≤ 0.5 kg (with eSSD, 1.1 lb.) Analog and IP signal input types are not configurable, and analog channel cannot be disabled to increase the maximum accessible number of network cameras. |
|---|
| No. | Description No. Description 1 Video and coaxial audio in 4 LAN network interface and USB interface 2 HDMI interface 5 Power supply 3 VGA interface 6 GND |
|---|
