HIKVISION iDS-TCH55P-H CCTV攝影機安裝・保養

Name: HIKVISION iDS-TCH55P-H 5 MP Axles Counting Trinocular Camera
Brand: Hikvision
SKU: iDS-TCH55P-H

產品簡介

Hikvision iDS-TCH55P-H 為5 MP Axles Counting Trinocular Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 iDS-TCH55P-H 香港價格連安裝報價。

快門速度：50 to 20000 μs
日夜切換：IR cut filter Fixed focal lens Middle camera: 1.16 mm, horiz
鏡頭接口：M12
光圈類型：Fixed iris Middle camera: F2.2, Left and right camera: F1.6
Built-in Supplement Light Type：IR light,White light

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

iDS-TCH55P-H Hikvision 5 MP Axles Counting Trinocular Camera 產品圖片

詳細規格

快門速度	50 to 20000 μs
日夜切換	IR cut filter Fixed focal lens Middle camera: 1.16 mm, horizontal FOV 164°, vertical FOV 164°, diagonal FOV 164°, Left and right camera: 4 mm, horizontal FOV 89.2°, vertical FOV 50.9°, diagonal FOV 101.7°
鏡頭接口	M12
光圈類型	Fixed iris Middle camera: F2.2, Left and right camera: F1.6
Built-in Supplement Light Type	IR light,White light
Light Bead	18
Built-in Supplement Light Range	Left and right light: Up to 20m, Middle light: Up to 4m
紅外波長	850 nm Middle camera: 50Hz: 50fps(2688×1944, 1920×1088, 1280×1024, 640×480); 60Hz:
主碼流	60fps(2688×1944, 1920×1088, 1280×1024, 640×480), Left and right camera: 50Hz 25fps(2944×1728, 1920×1200, 1920×1080, 1280×720); 60Hz 30fps(2944×1728, 1920×1200, 1920×1080, 1280×720) Middle camera: 50Hz 50fps(1920×1088, 1280×720, 704×576, 352×28 8); 60Hz
子碼流	60fps(1920×1088, 1280×720, 704×576, 352×288), Left and right camera: 50Hz 25fps(1920×1080, 1280×720, 704×576, 352×288); 60Hz 30fps(1920×1080, 1280×720, 704×576, 352×288) Main stream: H.264/H.265/MJPEG, Sub-stream: H.264/H.265/MJPEG
視頻碼率	32 Kbps to 8 Mbps
H.264 類型	Baseline Profile,Main Profile,High Profile
H.265 類型	Main Profile
網絡協議	TCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP ,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,IS UP,ARP,IGMP,SMTP
同時取流	Up to 6 channels
API	ISAPI,SDK,ISUP
用戶管理	Up to 32 users,3 user levels: administrator, operator, and user Password protection,HTTPS encryption,Complicated password,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5)
網絡儲存	Local storage,SD card (512 GB)
客戶端	Hik-Central Pro
瀏覽器	Chrome V61+, IE9 to IE11, Firefox V41+, Edge AGC,White balance,Gain,Sharpness,Contrast,Brightness,Saturation,Adjustable by client software or web browser.
日夜模式	Day,Night,Auto,Schedule Supported
影像增強	BLC,HLC,3D DNR 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface
機身儲存	Built-in memory card slot, supporting SD/SDHC/SDXC card, up to 512 GB
警報	1 IO input(s)
RS-485	1 RS-485 ((half duplex, HIKVISION)
RS-232	1 RS-232
基本事件	HDD error,Network disconnected,IP address conflict
Trigger Mode	Video trigger
Smart Function	License plate recognition, Axle total number recognition, Tyre total number recognition, Axle type recognition, Floating axle recognition Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain, Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Ang
Accuracy (Under recommended	Capture rate > 99%,
installation and lighting	LPR accuracy > 98%,
conditions)	Mistaken capture rate < 2%
操作系統	Linux AC 100 V to 240 V, 2.0 A, max. 60 W, 2-core terminal block, SGCC
