HONEYWELL DOC-02-199 防盜報警安裝・保養

Name: HONEYWELL DOC-02-199 Visual Alarm Devices (VAD)
Brand: honeywell
SKU: DOC-02-199

產品簡介

honeywell DOC-02-199 為Visual Alarm Devices (VAD)，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DOC-02-199 香港價格連安裝報價。

Excellent System Performance：Quality & Reliability
• High output LED technology ensures：• Independently approved
optimum light output and low power：to all required standards:
requirements：- Product performance: Approved • High efficiency piezo disk
generate powerful sound output：- Environmental: RoHS, WEEE • Automatic synchronization of s

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝ALARM、裝防盜、裝警鐘工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

DOC-02-199 honeywell Visual Alarm Devices (VAD) 產品圖片

詳細規格

Excellent System Performance	Quality & Reliability
• High output LED technology ensures	• Independently approved
optimum light output and low power	to all required standards:
requirements	- Product performance: Approved • High efficiency piezo disk and horn profile to AS ISO 7240.3 and AS ISO 7240.23
generate powerful sound output	- Environmental: RoHS, WEEE • Automatic synchronization of sounder and strobe
Reduced Install Error & Easy Diagnosis	Simple, Fast, Flexible Installation • Simple twist fit onto B501AP base (positive • Large cable access
“poke yoke” engagement)	• Rear or surface cable entry
• Anti-tamper feature	• Loop continuity spring • In-built loop isolator • Address tag for clear indication
Flexible Cost Effective System Design	Reduced Inventory Count • Single point of installation – saves time, cost • Device protocol is backward compatible
& inventory	through CLIP Protocol • Low current draw enables more devices on • Global 32 tone set (selectable from device or loop from panel) • Adjustable volume control (on device or from panel) • Rotary wheels for clear address indication
SUPPLY VOLTAGE	15 to 29 VDC (Isolation)
STANDBY CURRENT	450 μA maximum
CURRENT CONSUMPTION SOUNDER	10 mA
AND BEACON	(High Volume Tone 13 @ 24V) 96dB (A) ±3dB @ 1metre SOUND OUTPUT (High Volume, Tone 13 @ 24V)
BEACON FLASH RATE	1 Hz
MAXIMUM DEVICES PER LOOP	40
工作溫度	-25 °C to +70 °C
相對濕度	93% ±3% non condensing
防護等級	IP21C (with low profile B501AP base)
BODY COLOUR	Pure White
LENS COLOUR	Clear
FLASH COLOUR	Red
WEIGHT NET/ GROSS	199g/ 229g
CABLE TERMINAL SIZE	0.5-2.5 mm 2 max
NUMBER OF TONES	32
VOLUME SETTING	High, Medium, Low
MOUNTING OPTIONS	Low profile Wiring and Dimension Ordering Notifier CLIP pure white Sounder Beacon Base, red flash, clear lens, DSS-PC-I02 with Isolator
B501-AP	AV-device base, pure white for Intelligent range
WPW	Waterproof AV-device base, pure white for Intelligent range Agency Listings and Approvals The listings and approvals below apply to the devices specified in this document. In some cases, certain devices or applications may not be listed by certain approval agencies, or listing may be in process. Consult NOTIFIER for latest listing status. • AS ISO 7240.3:2014 • AS ISO 7240.23:2014 O Category; SAI
www.notifier.co.nz	ISO9001 FS 520324
© 2020 Honeywell International Inc.	DOC-02-199 / 09/20 \| Rev B ENGINEERING & MANUFACTURING QUALITY SYSTEMS
