Honeywell LINEAR-POSITION-SENSOR 為Issue 10，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 LINEAR-POSITION-SENSOR 香港價格連安裝報價。
| Certification/approval | CE, UKCA Mounting |
|---|---|
| Housing | Thermoplastic |
| Mounting screws | 1/4-20 or M6 |
| Mounting torque | 6 Nm to 10 Nm [53.1 in-lb to 88.5 in-lb] Recommended Magnet |
| Magnet | Neodymium Iron Boron |
| Field strength | 13500 Gauss SPS Linear Series Datasheet | automation.honeywell.com | 2 TABLE 2. 75 mm SPECIFICATIONS (Analog: SPS-L075-HALS) |
| Min. | Typ. Max. Units Sensor Charactertistics |
| Sensing range | 0 – 75 mm |
| Supply voltage | 6 – 24 Vdc |
| Supply current | – – 32 mA |
| Output type | Regulated |
| Output at min. pos | – 4.31 – Vdc |
| Output at max. pos | – 0.561 – Vdc |
| Full scale span | – 3.75 – Vdc mV/mm |
| 靈敏度 | -48 -50 -52 (negative slope) |
| Linearity | ± 0.4% Full scale output |
| 解像度 | 50 μm |
| Update rate | 400 μS |
| Reverse polarity | -26.4 at 125 °C V |
| Startup time | 30 mS Connector |
| Termination | Flying leads |
| Cable bend radius | 40 mm [1.6 in] min. Operating Environment |
| 工作溫度 | -40°C to 125°C [-40°F to 257°F] |
| 儲存溫度 | -40°C to 150°C [-40°F to 302°F] |
| Air gap | 3,0 mm ±2,5 mm [0.118 in ±0.098 in] |
| 防護等級 | IP67, IP69K |
| Radiated immunity | 100 V/m per ISO 11452-2 |
| Conducted immunity | 100 mA BCI per ISO 11452-4 |
| Mechanical shock | 50 G half sine wave with 11 ms duration |
| Vibration | 20 G from 10 Hz to 2000 Hz |
| Length = 0 | Length = 35,0 |
| Sensor | Mounting ear Magnet actuator Linearity 1.0% 5.0 of full scale 4.8 4.5 4.15 4.0 Output Signal (V) Reference point B 3.0 Nominal signal output curve 2.0 (Through reference points A and B) 1.0 0.55 |
| Reference Point A | Measurement Difference (mm) 0 mm Length 35 mm SPS Linear Series Datasheet | automation.honeywell.com | 5 Wiring Red = Vcc Mounting |
| ear | Black = GND Green = Output Sensor Mounting ear Mounting ear Magnet actuator Length Mounting ear Reference point A Linearity 0.4% 5.0 of Full Scale 4.310 4.0 3.0 Nominal signal output curve (Through reference points A and B) 2.0 Reference point B 1.0 0.561 Measurement Difference (mm) 0 mm Length 75 mm SPS Linear Series Datasheet | automation.honeywell.com | 6 Figure 3. SPS-L225-HALS Mounting Dimens |
| CATALOG LISTING | DESCRIPTION SPS Series SMART Position Sensor, 35 mm linear configuration, 0 mm to 35 mm [0 in to 1.38 in] sensing SPS-L035-LATS range, 0.5 Vdc to 4.5 Vdc analog output, magnet actuator included (sensor also available separately) SPS Series SMART Position Sensor, 75 mm linear configuration, 0 mm to 75 mm [0 in to 2.95 in] sensing SPS-L075-HALS range, 0 Vdc to 5 Vdc analog output, magnet actuator in |
| Honeywell warrants goods of its | PERSONAL INJURY manufacture as being free of defective DO NOT USE these products as safety |
| materials and faulty workmanship | or emergency stop devices or in any |
| during the applicable warranty period. | other application where failure of the |
| Honeywell’s standard product warranty | product could result in personal injury. |
| applies unless agreed to otherwise by | Failure to comply with these |
| Honeywell in writing; please refer to | instructions could result in death or |
| your order acknowledgment or consult | serious injury. your local sales office for specific warranty details. If warranted goods are returned to Honeywell during the m WARNING |
| period of coverage, Honeywell will | MISUSE OF |
| repair or replace, at its option, without | DOCUMENTATION |
| charge those items that Honeywell, | • The information presented in this |
| in its sole discretion, finds defective. | product sheet is for reference only. Do not use this document as a The foregoing is buyer’s sole remedy product installation guide. |
| and is in lieu of all other warranties, | • Complete installation, operation, |
| expressed or implied, including those | and maintenance information |
| of merchantability and fitness for a | is provided in the instructions |
| particular purpose. In no event shall | supplied with each product. |
| Honeywell be liable for consequential, | Failure to comply with these |
| special, or indirect damages. | instructions could result in death or serious injury. While Honeywell may provide application assistance personally, through our literature and the Honeywell web site, it is buyer’s sole responsibility to determine the suitability of the product in the application. Specifications may change without |
| For more information | notice. The information we supply is |
| Honeywell Sensing & Safety Technolo- | believed to be accurate and reliable |
| gies services its customers through a | as of this writing. However, Honeywell |
| worldwide network of sales offices and | assumes no responsibility for its use. |
| USA/Canada | +1 302 613 4491 |
| Latin America | +1 305 805 8188 |
| Europe | +44 1344 238258 |
| Japan | +81 (0) 3-6730-7152 |
| Singapore | +65 6355 2828 |
| Greater China | +86 4006396841 000674-10-EN | 10 | 02/24 |
| www.honeywell.com | © 2024 Honeywell International Inc. All rights reserved. |
* 規格以原廠最新 Datasheet 為準。
