| Standard Model Numbers | ST12000VN0007 ST10000VN0004 ST8000VN0022 ST6000VN0033 ST4000VN008 |
|---|
| 接口 | SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s Features and Performance |
|---|
| Drive Bays Supported | 1-8 Bays 1-8 Bays 1-8 Bays 1-8 Bays 1-8 Bays |
|---|
| Multi-User Technology | 180TB/year 180TB/year 180TB/year 180TB/year 180TB/year |
|---|
| Rotational Vibration (RV) Sensor | Yes Yes Yes Yes Yes |
|---|
| Dual-Plane Balance | Yes Yes Yes Yes Yes |
|---|
| Error Recovery Control | Yes Yes Yes Yes Yes |
|---|
| Max. Sustained Transfer Rate OD (MB/s) | 210MB/s 210MB/s 210MB/s 210MB/s 180MB/s |
|---|
| Spindle Speed (RPM) | 7200 7200 7200 7200 5900 |
|---|
| Cache (MB) | 256 256 256 256 64 Reliability |
|---|
| Load/Unload Cycles 1 | 600,000 600,000 600,000 600,000 600,000 |
|---|
| Nonrecoverable Read Errors Rate, Max | 1 per 10E15 1 per 10E15 1 per 10E15 1 per 10E15 1 per 10E14 |
|---|
| Power-On Hours | 8760 8760 8760 8760 8760 |
|---|
| Workload Rate Limit (WRL) | 180 180 180 180 180 |
|---|
| Mean Time Between Failures (MTBF, hours) | 1,000,000 1,000,000 1,000,000 1,000,000 1,000,000 |
|---|
| Limited Warranty (years) | 3 3 3 3 3 Power Management |
|---|
| Startup Current, Typical (12V, A) | 1.8 1.8 1.8 1.8 1.8 |
|---|
| Average Operating Power (W) | 7.8W 7.8W 8.8W 8.1W 4.80W |
|---|
| Idle Average (W) | 5.0W 5.0W 7.6W 7.2W 3.95W |
|---|
| Standby Mode/Sleep Mode, Typical (W) | 0.8/0.8 0.80/0.80 0.6/0.6 0.6/0.6 0.5/0.5 |
|---|
| Voltage Tolerance, Inc. Noise (5V) | ±5% ±5% ±5% ±5% ±5% |
|---|
| Voltage Tolerance, Inc. Noise (12V) | ±10% ±10% ±10% ±10% ±10% Environmental/Temperature |
|---|
| Operating (ambient, min °C) | 5 5 5 5 5 2 70 70 70 70 70 Operating (drive case, max °C) |
|---|
| Nonoperating (ambient, min °C) | -40 -40 -40 -40 -40 |
|---|
| Nonoperating (ambient, max °C) | 70 70 70 70 70 |
|---|
| Halogen Free | Yes Yes Yes Yes Yes Environmental/Shock |
|---|
| Shock, Operating/Nonoperating: 2ms (max) | 70Gs/250Gs 70Gs/250Gs 70Gs/250Gs 70Gs/250Gs 80Gs/300Gs Environmental/Acoustics |
|---|
| Idle (typical)3 | 2.8bels 2.8bels 2.7bels 2.7bels 2.3bels |
|---|
| Operating (typical) | 3.2bels 3.2bels 2.8bels 2.8bels 2.5bels Physical |
|---|
| Height (mm/in) | 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in |
|---|
| Width (mm/in, max) | 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in |
|---|
| Depth (mm/in, max) | 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in |
|---|
| Weight (g/lb, typical) | 705g/1.55lb 705g/1.55lb 780g/1.72lb 705g/1.55lb 610g/1.345lb |
|---|
| Carton Unit Quantity | 20 20 20 20 20 |
|---|
| Cartons per Pallet/Cartons per Layer | 40/8 40/8 40/8 40/8 40/8 |
|---|
| Specifications | 3TB 2TB 1TB |
|---|
