| Standard Model Numbers | ST8000VX004 ST6000VX001 ST4000VX016 ST4000VX013 ST4000VX007 |
|---|
| SkyHawk ™ Health Management Included | Yes Yes Yes Yes Yes |
|---|
| 接口 | SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s SATA 6Gb/s |
|---|
| Recording Technology | CMR CMR CMR SMR CMR |
|---|
| Drive Design | Air Air Air Air Air Features and Performance |
|---|
| Drive Bays Supported | Up to 16 Up to 16 Up to 16 Up to 16 Up to 16 |
|---|
| Cameras Supported | Up to 64 Up to 64 Up to 64 Up to 64 Up to 64 |
|---|
| RV Sensors | Yes Yes Yes Yes Yes |
|---|
| Max Sustained Transfer Rate OD (MB/s) | 210MB/s 180MB/s 180MB/s 180MB/s 190MB/s |
|---|
| Cache (MB) | 256 256 256 256 64 Reliability/Data Integrity |
|---|
| Tarnish Resistant | Yes Yes Yes Yes Yes |
|---|
| Load/Unload Cycles | 600,000 600,000 600,000 600,000 300,000 |
|---|
| Nonrecoverable Read Errors Rate, Max | 1 per 10E15 1 per 10E14 1 per 10E14 1 per 10E14 1 per 10E14 |
|---|
| Power-On Hours per year | 8760 8760 8760 8760 8760 1 180 180 180 180 180 Workload Rate Limit (WRL) |
|---|
| Mean Time Between Failures (MTBF) (hours) | 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr |
|---|
| Warranty, Limited (years)2 | 3 3 3 3 3 3 3 3 3 3 3 Rescue Data Recovery Services (years) Power Management |
|---|
| Startup Current, Typical (12V, A) | 1.8 1.8 1.8 1.8 1.8 |
|---|
| Average Operating Power (W) | 8.73W 5.0W 3.7W 3.7W 5.5W |
|---|
| Idle Average (W) | 7.06W 3.4W 2.5W 2.5W 3.2W |
|---|
| Standby Mode/Sleep Mode, Typical (W) | 0.96/0.96 0.25/0.25 0.25/0.25 0.25/0.25 0.25/0.25 |
|---|
| Voltage Tolerance (5V) | +10/-5% ±5% ±5% ±5% ±5% |
|---|
| Voltage Tolerance (12V) | ±10% ±10% ±10% ±10% ±10% Environmental/Temperature |
|---|
| Operating (ambient, min °C) | 5 0 0 0 0 |
|---|
| Operating (drive reported, max °C)4 | 70 70 65 70 70 |
|---|
| Nonoperating (ambient, min °C) | -40 -40 -40 -40 -40 Physical |
|---|
| Height (mm/in, max) | 26.11mm/1.028in 26.11mm/1.028in 20.20mm/0.795in 20.20mm/0.795in 26.11mm/1.028in |
|---|
| Width (mm/in, max) | 101.85mm/4.010in 101.85mm/4.01in 101.85mm/4.010in 101.85mm/4.010in 101.85mm/4.01in |
|---|
| Depth (mm/in, max) | 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in 146.99mm/5.787in |
|---|
| Weight (g/lb, typical) | 716g/1.579lb 610g/1.345lb 490g/1.08lb 490g/1.08lb 608g/1.34lb |
|---|
| Carton Unit Quantity | 20 20 25 25 20 |
|---|
| Cartons per Pallet/Cartons per Layer | 40/8 40/8 40/8 40/8 40/8 |
|---|
| Specifications | 3TB 3TB 2TB 2TB 1TB |
|---|
