| 尺寸 | 779 x 664 x 383 mm (30.7 x 26.1 x 15.1") |
|---|
| 重量 | Without mount: 8.6 kg (19 lb) With mount: 13 kg (28.7 lb) |
|---|
| Enclosure materials | UV stabilized polycarbonate, steel |
|---|
| Mount material | Galvanized steel |
|---|
| Mounting | Precision alignment kit (included) Pole compatibility: Ø40 to 80 mm (Ø1.5 to 3.15") on pipe outer diameter |
|---|
| Wind loading | 422 N at 200 km/h (94.86 lbf at 125 mph) |
|---|
| Weatherproo ng | IPX6 |
|---|
| 處理器 | Quad-core ARM® Cortex®-A53 at 1.4 GHz |
|---|
| Memory | DDR3L 1GB |
|---|
| Networking interface | (1) GbE RJ45 port (1) 1/10G SFP+ port |
|---|
| 最大功耗 | 24W |
|---|
| Power method | Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or 2-pairs (4, 5+; 7, 8-) |
|---|
| 供電 | 48VDC, 0.65A gigabit PoE adapter (included) |
|---|
| RF connections | Internal |
|---|
| 按鈕 | Factory reset |
|---|
| LEDs | Power, Ethernet, GPS, link |
|---|
| 工作溫度 | -40 to 55° C (-40 to 131° F) |
|---|
| 工作濕度 | 5 to 95% noncondensing |
|---|
| Certi cations | FCC, IC, CE |
|---|
| OS | airOS® |
|---|
| Operating mode | PtP only |
|---|
| Ubiquiti speci c features | Integrated 60 GHz radio, discovery protocol, Wave technology |
|---|
| Services | UISP, ping watchdog, NTP client, device discovery |
|---|
| Tools | Antenna alignment, discovery utility, ping, trace route, speed test |
|---|
| Network | Bridge mode |
|---|
| Software management | Bluetooth management for easy setup over UISP app WEB UI |
|---|
| Minimum software requirements | Any modern web browser/iOS™ or Android™ based smartphone 2 of 3 |
|---|
| Maximum throughput | 2.5+ Gbps |
|---|
| Maximum range | 15+ km |
|---|
| Encryption | WPA2-PSK (AES) |
|---|
| Operating frequency* | 57 to 71 GHz* * Depends on regulatory region. |
|---|
| Channel bandwidth | 2160, 1080 MHz |
|---|
| Operating channels* | 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120 MHz * Depends on regulatory region. |
|---|
| Modulation | 16QAM, BPSK, QPSK |
|---|
| Beamwidth | Azimuth: ± 1° Elevation: ± 1° |
|---|
| Management radio | 2400 to 2483.5 MHz |
|---|
| Electrical downtilt | 0° |
|---|
| U-NII-3 | 5725 - 5850 MHz |
|---|
| Worldwide | 5150 - 5875 MHz * Depends on regulatory region. |
|---|
| 天線增益 | 26 dBi |
|---|
| Cross-pol isolation | 14 dB |
|---|
| Ethernet | Flashing blue: Ethernet traf c detected |
|---|
| GPS | Blue: receiving at least (4) GPS satellite signals |
|---|
| Link | Blue: 5GHz link Blue: 60GHz link Specific ations are subjec t to c hange. Ubiquiti produc ts are s old with a limited warranty desc ribed at: www.ui.c om/support/warranty ©2022 Ubiquiti Inc . All rights res erv ed. Ubiquiti, the Ubiquiti U logo, airOS, airFiber, UISP, and Wav e are trademark s or registered trademarks of Ubiquiti Inc . in the United States and in other countries . Android is a tra |
|---|
