| Radio | 224 x 82 x 48 mm (8.82 x 3.23 x 1.89") |
|---|
| Box | 261 x 107 x 107 mm (10.28 x 4.21 x 4.21") |
|---|
| GPS Antenna | External, Magnetic Base |
|---|
| 供電 | 24V, 1A PoE Gigabit Adapter (Included) Passive Power over Ethernet Pins 1, 2, 4, 5 (+) and Pins 7, 8, 3, 6 (-) |
|---|
| 最大功耗 | 17W @ Max. Power/Duty Cycle |
|---|
| Supported Voltage Range | 19-29VDC, +48VDC Input Yes airFiber X Mount (Rocket Mount Compatible) GPS Pole Mount (Included) |
|---|
| Certifications | CE, FCC, IC |
|---|
| 工作溫度 | -40 to 55° C (-40 to 131° F) AF-2X Networking Interface |
|---|
| Data Port | (1) 10/100/1000 Ethernet Port |
|---|
| Management Port | (1) 10/100 Ethernet Port AF-2X System |
|---|
| 處理器 | INVICTUS IC |
|---|
| Maximum Throughput | 687 Mbps* |
|---|
| Maximum Range | 200+ km* |
|---|
| Packets per Second | 1+ Million |
|---|
| Encryption | 128-bit AES |
|---|
| OS | airOS F |
|---|
| Wireless Modes | Master/Slave |
|---|
| Half Duplex Mode | < 2 ms at Full Throughput Up to 9600 * Throughput and range values may vary depending on the environmental conditions. AF-2X Radio |
|---|
| Frequency Range | 2300-2700 MHz (Dependent on Regulatory Region)1 30 dBm1 Max. Conducted TX Power (Dependent on Regulatory Region) ± 2.5 ppm without GPS Synchronization Frequency Accuracy ± 0.2 ppm with GPS Synchronization 3.5/5/7/10/14/20/28/30/40/50/56 MHz Selectable2 |
|---|
| Channel Bandwidth | Programmable Uplink and Downlink Duty Cycles Independently Programmable TX and RX Frequencies 1 For region-specific details, refer to the Compliance chapter of the airFiber X User Guide at www.ubnt.com/download/airfiber 2 Channel widths may vary according to country/region regulations. AF-2X Suggested Max. TX Power 8x 23 - 24 dBm 6x 25 - 26 dBm 4x 27 - 28 dBm 2x 30 dBm 1x 30 dBm AF-2X Receive Sens |
|---|
| 靈敏度 | Sensitivity Sensitivity Sensitivity Sensitivity |
|---|
| Rate | Modulation (10 MHz) (20 MHz) (30 MHz) (40 MHz) (50 MHz) 8x 256QAM MIMO -66 dBm -64 dBm -62 dBm -61 dBm -60 dBm 6x 64QAM MIMO -74 dBm -71 dBm -69 dBm -68 dBm -67 dBm 4x 16QAM MIMO -81 dBm -78 dBm -76 dBm -75 dBm -74 dBm 2x QPSK MIMO -88 dBm -85 dBm -83 dBm -82 dBm -81 dBm 1x ½ Rate QPSK xRT -90 dBm -87 dBm -85 dBm -84 dBm -83 dBm AF-2X Capacity (Mbps) Channel Width (MHz) |
|---|
| FCC 15.407 | 5150 - 5350 MHz, 5470 - 5850 MHz |
|---|
| IC RSS-210 | 5470 - 5600 MHz, 5650 - 5850 MHz |
|---|
| ETSI EN 301 893, EN 302 502 | 5470 - 5875 MHz |
|---|
| Other Regions | 5150 - 5950 MHz* 26 dBm* Max. Conducted TX Power (Dependent on Regulatory Region) ± 2.5 ppm without GPS Synchronization Frequency Accuracy ± 0.2 ppm with GPS Synchronization 10/20/30/40/50 MHz Selectable Channel Bandwidth Programmable Uplink and Downlink Duty Cycles * For region-specific details, refer to the Compliance chapter of the airFiber X User Guide at www.ubnt.com/download/airfiber AF-5X S |
|---|
