| Resolution -- main camera | 3MP |
|---|
| Resolution -- sub camera | 2MP Horizontal: 116° |
|---|
| FOV -- main camera | Vertical: 82.5° Diagonal: 131° Horizontal: 96.8° |
|---|
| FOV -- sub camera | Vertical: 52.6° Diagonal: 109.9° |
|---|
| power kit | 240 mAH rechargeable lithium battery (for mechanical chime) |
|---|
| Charge temperature | 0 °C to 45 °C |
|---|
| Motion detection alarm | Support |
|---|
| UMD alarm | Supports human body detection alarm |
|---|
| Package detection alarm | Support |
|---|
| Operating frequency band | 2.4 GHz and 5G Hz |
|---|
| BLE function | Compatible, integrated BLE, supports network connection via Bluetooth |
|---|
| Antenna type | Built-in omnidirectional antenna |
|---|
| WLAN | 802.11 b/g/n/ax |
|---|
| Encryption | WPA-PSK/WPA2-PSK/WPA3-personal |
|---|
| 藍牙 | Support, integrated in Wi-Fi chip |
|---|
| SUB-1G | Supported, for chime connection |
|---|
| Chimes | Max. 3 wireless chimes or 1 mechanical chime |
|---|
| Mechanical Chime Lis | LA11WH-1、C210-W |
|---|
| Reset button | 1 micro switch for both pairing and reset |
|---|
| Built-in Mic | Support |
|---|
| Built-in speaker | Support |
|---|
| Interface protocol | UNV private protocol |
|---|
| 網絡協議 | TCP/IP, IPv4, HTTP, RTP, RTSP, NTP |
|---|
| Illumination scheme | IR + white light IR: 5 meters White light: 2 meters |
|---|
| 最低照度 | 0.02 lux |
|---|
| 尺寸 | 55.8 mm × 156.5 mm × 27.9 mm Net weight: 142g Gross weight: 295g With bracket installation, the power cable is installed on the bracket, and the doorbell is connected to the bracket through the contacts. |
|---|
| 按鈕 | One call button Wireless Chime: 12VAC----12VA 24VAC----12VA Mechanical Chime: 24VAC----26VA (Please ensure the mechanical chime is connected before operating the doorbell. Pressing the button without a connected chime may cause irreversible harm to the device.) |
|---|
| 工作溫度 | -30 °C to 60 °C |
|---|
| 防護等級 | IP65 |
|---|
| WDR | Supports DWDR, main camera 80dB, sub camera 58dB |
|---|
| 視頻壓縮 | H.265, H.264 |
|---|
| 音訊碼率 | 128 Kbps |
|---|
| 音訊取樣率 | 8K |
|---|
| 音訊壓縮 | G711, MP3, PCM |
|---|
| Certification | CB, CE LVD, CE EMC, CE RED, FCC SDOC, FCC ID |
|---|
| NDAA Compliant | Support Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
