| Camera | BLC Mode BLC / HLC / DWDR |
|---|
| 影像感測器 | 1/2.7" CMOS WDR DWDR |
|---|
| Effective Pixels | 1920(H)×1080(V), 2MP Gain Control AGC |
|---|
| Scanning System | Progressive Noise Reduction 2D |
|---|
| PAL: 1/4~1/100000s | White Balance Auto / Manual Electronic Shutter Speed NTSC: 1/3~1/100000s |
|---|
| Smart IR | Auto / Manual |
|---|
| Minimum Illumination | 0.02Lux/F2.0(Color), 30IRE, 0Lux IR on |
|---|
| S/N Ratio | More than 65dB PIR |
|---|
| IR Distance | Up to 20m (66feet) Detection Passive infrared |
|---|
| IR On/Off Control | Auto / Manual Detection Range 10m, 110° |
|---|
| IR LEDs | 1 Alarm prompt Red led |
|---|
| 鏡頭 | Installation height Defualt bracket, wall mount, 2.2-2.5m |
|---|
| 鏡頭類型 | Fixed lens / Fixed iris Certifications |
|---|
| Mount Type | Board-in CE (EN55032, EN55024, EN50130-4) |
|---|
| Certifications | FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
|---|
| 焦距 | 2.8mm UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|---|
| Max Aperture | F2.0 |
|---|
| Angle of View | H: 112° |
|---|
| Audio Interface | N/A |
|---|
| Focus Control | N/A Eelectrical 500mm Close Focus Distance 19.7'' Power Supply 12V DC ±30% |
|---|
| DORI Distance | Power Consumption Max 4.1W (12V DC, IR on) Note: The DORI distance is a “general proximity” of distance which makes it easy to Environmental pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH Operating Conditions criteria for Detect, O |
|---|
| Distance | Storage Conditions -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH Definition 25px/m Ingress Protection &Vandal |
|---|
| Detect | 2.8mm: 40m(131ft) IP67 (8px/ft) Resistance Observe 63px/m 2.8mm: 16m(52ft) Construction (19px/ft) |
|---|
| Casing | Aluminium (Front cover) + Plastic (Rear Barrel) 125px/m |
|---|
| Recognize | 2.8mm: 8m(26ft) (38px/ft) |
|---|
| 尺寸 | 146.6mm×72.4mm×83mm (5.77"×2.85"×3.27") 250ppm |
|---|
| Identify | 2.8mm: 4m(13ft) Net Weight 0.23kg (0.51lb) (76px/ft) |
|---|
| Pan / Tilt / Rotation | Gross Weight 0.30kg (0.66lb) Pan: 0° ~ 360° |
|---|
| Pan/Tilt/Rotation | Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
|---|
| 解像度 | 1080P (1920×1080) |
|---|
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P 1-channel BNC high definition video output / CVBS Video Output video output (Can switch) |
|---|
| Day/Night | Auto (ICR) / Manual www.dahuasecurity.com |
|---|
| Ordering Information | Juncon Mount Pole Mount |
|---|
| PFA134 | PFA134 + PFA152-E |
|---|
| 類型 | Part Number Description |
|---|
| DH-HAC-ME1200BP-PIR 2.8mm | 2MP HDCVI MotionEye Camera, PAL 2MP Camera |
|---|
| DH-HAC-ME1200BN-PIR 2.8mm | 2MP HDCVI MotionEye Camera, NTSC Junction box (For use alone or with PFA134 PFA152-E pole mount) Pole mount (For use with PFA134 PFA152-E junction box) |
|---|
| PFM800-E | Passive HDCVI Balun Accessories |
|---|
| PFM800-4MP | Passive HDCVI Balun |
|---|
| PFM801-4MP | Passive HDCVI Balun with Power |
|---|
| PFM321 | 12V 1A Power Adapter |
|---|
| PFM320D-015 | 12V 1.5A Power Adapter Accessories Optional: Dimensions (mm/inch) |
|---|
| Junction box | Pole mount Passive HDCVI Balun |
|---|
| Passive HDCVI Balun | Passive HDCVI Balun 12V 1A Power |
|---|
| With Power | Adapter PFM320D-015 Power Adapter |
|---|
| Rev 001.001 | © 2017 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
