| Camera | Gain Control Auto/Manual |
|---|
| 影像感測器 | 1/2.8”2Megapixel progressive scan CMOS Noise Reduction 3D DNR |
|---|
| Effective Pixels | 1920(H)x1080(V) Motion Detetion Off / On (4 Zone, Rectangle) |
|---|
| RAM/ROM | 1024MB/128MB Region of Interest Off / On (4 Zone) |
|---|
| Scanning System | Progressive Electronic Image Stabilization Support (EIS) |
|---|
| Minimum Illumination | 0.005Lux/F1.4( Color), 0Lux/F1.4(IR on) |
|---|
| Smart IR | Support |
|---|
| S/N Ratio | More than 50dB |
|---|
| 除霧 | Support |
|---|
| IR Distance | Distance up to 100m(328ft) |
|---|
| Digital Zoom | 16x |
|---|
| IR On/Off Control | Auto/ Manual |
|---|
| Flip | 0°/90°/180°/270° |
|---|
| IR LEDs | 4 |
|---|
| Mirror | Off / On |
|---|
| Privacy Masking | Off / On (4 Area, Rectangle) |
|---|
| 鏡頭類型 | Motorized /Auto Iris(HALL) |
|---|
| Mount Type | Board-in |
|---|
| Compression | G.711a/G.711Mu/AAC/ G.726 |
|---|
| 焦距 | 7~35mm motorized |
|---|
| Max. Aperture | F1.4 |
|---|
| Ethernet | RJ-45 (100/1000Base-T) |
|---|
| Angle of View | H: 35°~12°, V:19°~7° HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; |
|---|
| Optical Zoom | 5x Protocol DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP |
|---|
| Focus Control | Motorized |
|---|
| Interoperability | ONVIF, PSIA, CGI |
|---|
| Close Focus Distance | 0.3m(0.98ft) |
|---|
| Streaming Method | Unicast / Multicast Pan/Tilt/Rotation |
|---|
| Max. User Access | 10 Users/20 Users |
|---|
| Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ NAS |
|---|
| Intelligence | Edge Storage Local PC for instant recording Mirco SD card 128GB |
|---|
| IVS (optional) | Tripwire, Intrusion, Object Abandoned/Missing |
|---|
| Web Viewer | IE, Chrome, Firefox, Safari Advanced Intelligent Functions Face Detection, People Counting, Heat Map |
|---|
| Management Software | Smart PSS, DSS, Easy4ip |
|---|
| Video | Smart Phone IOS, Android |
|---|
| Streaming Capability | 3 Streams CE (EN 60950:2000) |
|---|
| Certifications | UL:UL60950-1 1080P(1920×1080)/ 1.3M(1280x960)/ FCC: FCC Part 15 Subpart B |
|---|
| 解像度 | 720P(1280x720)/ D1(704×576/704x480) / |
|---|
| VGA(640x480)/ CIF(352×288/342x240) | Interface |
|---|
| Main Stream: 1080P(1~50/60fps) | Video Interface N/A |
|---|
| Frame Rate | Sub Stream: D1 (1 ~ 50/60fps) Audio Interface 1/1 channel In/Out |
|---|
| Third Stream: 1080P(1~50/60fps) | RS485 N/A |
|---|
| 碼率控制 | CBR/VBR Alarm 2/1 channel In/Out Bit Rate |
|---|
| H.264: 24~ 10240Kbps | Electrical H.265: 14~ 6144Kbps |
|---|
| 供電 | DC12V, PoE+ (802.3at)(Class 4) |
|---|
| Day/Night | Auto(ICR) / Color / B/W |
|---|
| 功耗 | <13W |
|---|
| BLC Mode | BLC / HLC / WDR(140dB)/ SSA www.dahuasecurity.com |
|---|
| Environmental | Accessories |
|---|
| Operating Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH Optional: |
|---|
| Strorage Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
|---|
| 防護等級 | IP67 |
|---|
| Vandal Resistance | IK10 Construction |
|---|
| Casing | Metal |
|---|
| 尺寸 | 273.2mm×95.0mm×96.4mm (10.76”×3.74”×3.79”) PFA121 PFA152 |
|---|
| 淨重 | 1.12Kg (2.47lb) Juncon box Pole mount |
|---|
| 毛重 | 1.52Kg (3.35lb) |
|---|
| Juncon Mount | Pole Mount |
|---|
| PFA121 | PFB121 + PFA152 Ordering Information |
|---|
| 類型 | Part Number Description DH-IPC- 2MP WDR IR Bullet Network Camera,PAL HFW8231EP-Z5 DH-IPC- 2MP WDR IR Bullet Network Camera,NTSC HFW8231EN-Z5 2MP camera IPC- 2MP WDR IR Bullet Network Camera,PAL HFW8231EP-Z5 IPC- 2MP WDR IR Bullet Network Camera,NTSC HFW8231EN-Z5 |
|---|
| PFA152 | Pole Mount Dimensions (mm/inch) www.dahuasecurity.com |
|---|
