| Camera | Motion detection, video tampering, scene changing, |
|---|
| Event Trigger | network disconnection, IP address conflict, illegal |
|---|
| 影像感測器 | 1/2.8" CMOS access, and storage anomaly. |
|---|
| Pixel | 2MP IVS Tripwire, intrusion, object abandoned/missing |
|---|
| 最大解像度 | 1920 (H) × 1080 (V) Video H.265; H.264 Baseline Profile; H.264 Main Profile; |
|---|
| ROM | 128 MB Compression H.264 High Profile |
|---|
| RAM | 256 MB Streaming Capability 3 streams 1080P (1920 × 1080); 960P (1280 × 960); 720P (1280 |
|---|
| Electronic Shutter Speed | 1/1 s–1/30000 s Resolution × 720) |
|---|
| Scanning System | Progressive Main stream: 1080P/720P (1–25/30 fps) |
|---|
| Frame Rate | Sub stream 1: D1/CIF (1–25/30 fps) |
|---|
| Color: 0.05 Lux@F1.5 | Sub stream 2: 720P/D1/CIF (1–25/30 fps) |
|---|
| 最低照度 | B/W: 0.005 Lux@F1.5 0Lux (IR or laser on) Bit Rate Control Variable/Constant |
|---|
| Illumination Distance | 100 m (328.08 ft) H.264: 1792 Kbps–8192 Kbps Bit Rate H.265: 768 Kbps–4608 Kbps |
|---|
| Illuminator On/Off Control | Zoom Prio/Manual/SmartIR/Off |
|---|
| Day/Night | Auto (ICR)/Color/B/W |
|---|
| Illuminator Number | 4 |
|---|
| BLC | Support |
|---|
| WDR | DWDR |
|---|
| 焦距 | 5 mm–80 mm |
|---|
| HLC | Support |
|---|
| Max. Aperture | F1.5–F2.7 Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/ White Balance |
|---|
| Field of View | H: 57.7°–4.5°; V:32.7°–2.6°; D: 65.2°–5.2° Natural/Street lamp |
|---|
| Gain Control | Auto/Manual |
|---|
| Optical Zoom | 16x |
|---|
| Noise Reduction | 2D/3D |
|---|
| Focus Control | Auto/Semi-Auto/Manual |
|---|
| Motion Detection | Support |
|---|
| Close Focus Distance | 0.1 m–0.5 m (0.33 ft–1.64 ft) |
|---|
| 感興趣區域 ROI | Support |
|---|
| Iris Control | Auto/Manual |
|---|
| Image Stabilization (EIS) | Electronic |
|---|
| Detect | Observe Recognize Identify |
|---|
| DORI Distance | Defog Electronic 1343 m 530 m 268 m 134 m (4406.17 ft) (1738.85 ft) (879.27 ft) (439.63 ft) Digital Zoom 16x |
|---|
| PTZ | Flip 180° |
|---|
| Pan/Tilt Range | Pan: 0°–360°; Tilt: -15°–+90° Privacy Masking Up to 24 areas |
|---|
| Manual Control Speed | Pan: 0.1°/s–200°/s; Tilt: 0.1°/s–120°/s Audio |
|---|
| Preset Speed | Pan: 240°/s; Tilt: 200°/s G.711a; G.711Mu; G.726; AAC; G7221; G726; G729; Compression MP2L2 |
|---|
| 預置位 | 300 |
|---|
| Tour | 8 (up to 32 presets per tour) |
|---|
| Ethernet | RJ-45 (10/100Base-T) |
|---|
| Pattern | 5 IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; |
|---|
| Scan | 5 UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; SNMPv1/v2c/ |
|---|
| Speed Adjustment | Support v3(MIB-2); RTCP; RTMP |
|---|
| 斷電記憶 | Support Interoperability ONVIF Profile S&G; CGI |
|---|
| Idle Motion | Preset/Tour/Pattern/Scanning Streaming Method Unicast/Multicast DH-SD |
|---|
| Protocol | User/Host 20 (total bandwidth 48 MB) Pelco-P/D (auto recognition) www.dahuasecurity.com |
|---|
| Storage | FTP; Micro SD card (256 GB); NAS Accessories |
|---|
| IE7 and later versions | Included: Chrome 42 and earlier versions Browser Firefox 52 and earlier versions Safari |
|---|
| Management Software | Smart PSS; DSS; DMSS; Easy4ip; IVSS |
|---|
| Mobile Phone | IOS, Android PFB305W Wall Mount Bracket CE: EN55032/EN55024/EN50130-4 |
|---|
| Certifications | FCC: Part15 subpartB,ANSI C63.4-2014 Optional: UL: UL62368-1+CAN/CSA C22.2, No. 62368-1 Port |
|---|
| 音訊輸入 | 1 (LINE IN; bare wire) |
|---|
| 音訊輸出 | 1 (LINE OUT; bare wire) DC12V/5A PFA111 PFA150 |
|---|
| 供電 | Mount Adapter Pole Mount Bracket |
|---|
| Alarm I/O | 2/1 Power |
|---|
| 工作溫度 | –40°C to +70°C (–40°F to +158°F) |
|---|
| 工作濕度 | ≤ 95%RH |
|---|
| 防護等級 | IP66; TVS 6000V lightning protection; surge protection Structure |
|---|
| 尺寸 | 295 mm × Φ160 mm (11.61" × Φ6.30") |
|---|
| 淨重 | 3.0 kg (6.61 lb) |
|---|
| 毛重 | 4.4 kg (9.70 lb) Ordering Information |
|---|
| 類型 | Model Description |
|---|
| DH-SD49216UE-HN | 2MP 16x Starlight IR PTZ Network Camera, PAL |
|---|
| DH-SD49216UEN-HN | 2MP 16x Starlight IR PTZ Network Camera, NTSC |
|---|
| SD49216UE-HN | 2MP 16x Starlight IR PTZ Network Camera, PAL |
|---|
| SD49216UEN-HN | 2MP 16x Starlight IR PTZ Network Camera, NTSC |
|---|
| PFB305W | Wall Mount Bracket |
|---|
| DC12V/5A | Power Adapter |
|---|
| PFA111 | Mount Adapter |
|---|
| PFA150 | Pole Mount Bracket |
|---|
| PFA151 | Corner Mount Bracket |
|---|
| PFB300C | Ceiling Mount Bracket Dimensions (mm[inch]) |
|---|
