| Name | Video Alarm Control Panel detector, 3 door/window detector, 2 remote control, 2 panic button, 1 IPC-A35, 1 IPC-C35 Main Processor High-performance industrial embedded microcontroller |
|---|
| D1 | 4CH Remote |
|---|
| 操作系統 | Embedded LINUX |
|---|
| In and Out | Power Video Audio TCP/IP PSTN |
|---|
| Wired Zones | 2 on-board zones 28 wireless detectors, 2-way communication, Wireless Zones |
|---|
| transmission range up to 150m open space | Network Interface 1 RJ-45 Port(10/100Mbps) |
|---|
| 警報輸出 | 1-ch relay output |
|---|
| RS485 | 1 Port |
|---|
| Tamper Funtion | 1 tamper switch 2 groups PSTN, support Contact ID standard PSTN protocol alarm |
|---|
| Remote Keyfob | 8 wireless keyfobs |
|---|
| Wired Siren | 1 wired siren(12V/0.5A) |
|---|
| Siren | 4 wireless sirens + 1 wired siren |
|---|
| Auxiliary Power Output | 1 auxiliary power output(12V/0.5A) Max 128GB micro SD card for video recording, USB Storage |
|---|
| device to backup video | Reset Insert two ends of cable into the holes to reset |
|---|
| ID Card | RFID reader(arm/disarm) |
|---|
| USB | 1 USB 2.0 port to record or upgrade Audio and Video TCP/IP, DHCP, WIFI, P2P, IP Search(Support Dahua Network Function |
|---|
| IP camera), DMSS | IP Camera Channel 4 Channel |
|---|
| Compression | H.264 www.dahuasecurity.com |
|---|
| 解像度 | D1 ARD1611-W |
|---|
| LCD Screen | 4.3 inch TFT screen, 480*272 resolution Name Wireless Curtain PIR Detector |
|---|
| 音訊輸入 | 1 ch audio in for 30s voice message Detection Passive infrared |
|---|
| Audio Out | 1 ch audio out for voice and alarm broadcast Detection Range 10m/15° |
|---|
| 升級方式 | Alarm prompt Notification LED light, can be set to switch off |
|---|
| Remote Upgrade | USB disk or ConfigTool to remotely upgrade Sensitivity Two level (jumper switch) |
|---|
| General Parameters | Wireless Frequency 433/868MHz |
|---|
| Main Power | DC12V/2A Transmit power 10dBm |
|---|
| Backup Battery | 3.7V/1900mAh, Li-ion Transmit distance 150m, open area/no interference |
|---|
| 功耗 | ≤5W Resistance light 6500LUX |
|---|
| 工作溫度 | -10℃ ~ +55℃ Tamper Unit protection and leaving-wall protection |
|---|
| Humidity | 10% ~ 90% Power 1xCR123A battery |
|---|
| Device Dimensions | 216*118*28mm Working environment -10°C~+50°C, humidity <95° |
|---|
| Device Weight | ＜1kg Overall dimensions/weight 99mmx52mmx35mm/0.1kg |
|---|
| 安裝 | Wall mounting Installation height Ceiling/Wall mount, 2.2-2.5m |
|---|
| ARD1231-W | Installation height Wall mount, 2.2-2.5m |
|---|
| Detection | Passive infrared Name Wireless door sensor |
|---|
| Detection Range | 12m×12m, 90° Motion distance 25-40mm |
|---|
| Alarm prompt | Red LED, can be set to switch off Alarm prompt Notification LED light, can be set to switch off |
|---|
| 靈敏度 | Two level (jumper) Wireless Frequency 433/868MHz |
|---|
| Wireless Frequency | 433/868MHz Transmit Power 10dBm |
|---|
| Transmit power | 10dBm Transmit Distance 150m(open area/no interference) |
|---|
| Transmit distance | 150m open area/no interference Tamper Front cover and rear cover protection |
|---|
| Pet immunity | ≤18Kg Power 1xCR123A battery |
|---|
| Resistance light | 6500LUX Installation Way Screw and glue |
|---|
| Working environment | -10°C~+50°C, humidity <95° Dimensions 84*39*22mm |
|---|
| Overall dimensions/weight | 105mmx62mmx41.3mm/0.1kg Weight 0.1kg |
|---|
| 防拆 | Unit protection and leaving-wall protection Temperature -10°C~50°C |
|---|
| 供電 | 1xCR123A battery Humidity < 95% |
|---|
| Installation height | Wall mount, 2.2-2.5m Installation Screw or glue to mount www.dahuasecurity.com |
|---|
| ARD800-W | Ordering Information |
|---|
| Trigger Alarm | Button pressed down DHI-ART-ARC5402A-GW-10-A35-C35(868) Alarm Security Kit, 868MHz Alarm success: green LED on Alarm prompt Alarm failure: red LED on |
|---|
| Transmit Power | 10dBm 150 meters(open area/no interference) Transmit Distance Indoor 30 meters, 1 wall capability |
|---|
| 尺寸 | 42*43.8*13mm |
|---|
| 重量 | 0.05kg |
|---|
| Temperature | -10°C~55°C |
|---|
| Working Voltage | DC3.0V |
|---|
| Frequency | 433/868MHz |
|---|
| Key | Away Arm/Stay Arm/Disarm/SOS |
|---|
| 防護等級 | IP20 |
|---|
