| System | HDCVI Camera Input 4/8/16 Channel |
|---|
| Main Processor | Embedded Processor IP Camera Input 4+2/8+4/16+8 Channel, each channel up to 5MP |
|---|
| 操作系統 | Embedded LINUX Audio In/Out 4 Channel input,1 Channel output, RCA |
|---|
| Display | Two-way Talk Reuse audio in(channel 1)/out, RCA Recording |
|---|
| 接口 | 1 HDMI ,1 VGA |
|---|
| Compression | H.264+/H.264 |
|---|
| 解像度 | 1920×1080, 1280×1024, 1280×720, 1024×768 4CH: 1/4/6 Resolution 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
|---|
| Multi-screen Display | 8CH: 1/4/8/9/16 16CH: 1/4/8/9/16/25 Main stream: 1080P(1~15fps) 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF Camera title, Time, Video loss, Camera lock, Motion Record Rate |
|---|
| OSD | (1~25/30fps) detection, Recording Sub steram:D1/CIF/QCIF(1~15fps) Video Detection and Alarm |
|---|
| Bit Rate | 1Kbps ~ 6144Kbps Per Channel Recording, PTZ, Tour, Alarm Out, Video Push, Email, |
|---|
| Trigger Events | Manual, Schedule (Regular, Continuous), MD FTP, Snapshot, Buzzer and Screen Tips |
|---|
| Record Mode | (Video detection: Motion Detection, Video Loss, Motion Detection, MD Zones: 396 (22 × 18), Video Tampering), Alarm, Stop Video Detection Loss,Tampering and Diagnosis 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Record Interval |
|---|
| 警報輸入 | 4/8/16 Post-record: 10 ~ 300 sec |
|---|
| Relay Output | 3 Network 4CH/8CH: 1 RJ-45 Port (100M) |
|---|
| Playback and Backup | 16CH: 1 RJ-45 Port (1000M) HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, 4CH: 1/4 NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Network Function |
|---|
| Playback | 8CH: 1/4/9 Server, P2P,IP Search (Support Dahua IP camera, 16CH: 1/4/9/16 DVR, NVS, etc.) |
|---|
| Max. User Access | 128 users Time /Date, Alarm, MD and Exact Search (accurate Search Mode to second) |
|---|
| Smart Phone | iPhone, iPad, Android Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Interoperability ONVIF 2.42, CGI Conformant Playback Function Full Screen, Repeat, Shuffle, Backup Selection, |
|---|
| Digital Zoom | Electrical |
|---|
| Backup Mode | USB Device/Network Power Supply DC12V/4A |
|---|
| Storage | Power Consumption <15W (Without HDD) |
|---|
| Internal HDD | 2 SATA Ports, up to 8TB capacity for each disk Environmental |
|---|
| eSATA | N/A Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
|---|
| Auxiliary Interface | Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH 4/8CH:2 USB Ports (2 USB 2.0) USB 16CH:2 USB Ports (1 USB 2.0 , 1 USB 3.0) Construction |
|---|
| 尺寸 | 1U, 375mm×287mm×53mm (14.8" x 11.3" x 2.1") |
|---|
| RS232 | N/A |
|---|
| 淨重 | 2.35kg (5.2 lb) (without HDD) |
|---|
| RS485 | 1 Port, for PTZ Control |
|---|
| 毛重 | 3.2kg (7.05lb) Third-party Support |
|---|
| 安裝 | Desktop installation Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Third-party Support Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, Certifications and more FCC: Part 15 Subpart B ICES 003 Issue 6 CE: EN 55032: 2012+AC:2013 (Class B) |
|---|
| Certifications | EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 www.dahuasecurity.com |
|---|
| Ordering Information | Rear Panel |
|---|
| 類型 | Part Number Description DHI-HCVR5204A-S3 4 Channel Tribrid 1080P-Lite 1U Digital DHI-HCVR5204A-S3 Video Recorder 4/8/16 |
|---|
| Channel | 8 Channel Tribrid 1080P-Lite 1U Digital DHI-HCVR5208A-S3 |
|---|
| HCVR | Video Recorder DHI-HCVR5208A-S3 16 Channel Tribrid 1080P-Lite 1U Digital DHI-HCVR5216A-S3 Video Recorder DHI-HCVR5216A-S3 Dimensions (mm) |
|---|
| Rev 001.001 | © 2016 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
