DAHUA IPC-HDPW1230R1-ZS-S5 CCTV攝影機安裝・保養

Name: DAHUA IPC-HDPW1230R1-ZS-S5 DH-IPC-HDPW1230R1-ZS-S5
Brand: dahua
SKU: IPC-HDPW1230R1-ZS-S5

產品簡介

dahua IPC-HDPW1230R1-ZS-S5 為DH-IPC-HDPW1230R1-ZS-S5，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 IPC-HDPW1230R1-ZS-S5 香港價格連安裝報價。

Camera：White Balance Auto; natural; street lamp; outdoor; manual; r
影像感測器：1/2.8" CMOS
Gain Control：Auto; manual
最大解像度：1920 (H) × 1080 (V)
Noise Reduction：3D NR

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

IPC-HDPW1230R1-ZS-S5 dahua DH-IPC-HDPW1230R1-ZS-S5 產品圖片

詳細規格

Camera	White Balance Auto; natural; street lamp; outdoor; manual; regional custom
影像感測器	1/2.8" CMOS
Gain Control	Auto; manual
最大解像度	1920 (H) × 1080 (V)
Noise Reduction	3D NR
ROM	16 MB
Motion Detection	OFF/ON (4 areas, rectangular)
RAM	128 MB
感興趣區域 ROI	Yes (4 areas)
Scanning System	Progressive
Smart Illumination	Yes
Electronic Shutter Speed	Auto/Manual 1/3 s–1/100,000 s 0°/90°/180°/270° (Support 90°/270° with 1080p Image Rotation resolution and lower) 0.008 Lux@F1.7 (Color, 30 IRE)
最低照度	0.0008 Lux@F1.7 (B/W, 30 IRE) Mirror Yes 0 Lux (Illuminator on)
Privacy Masking	4 areas
S/N Ratio	> 56 dB
Illumination Distance	40 m (131.23 ft) (IR) Alarm No SD card; SD card full; SD card error; network
Illuminator On/Off Control	Auto; Manual disconnection; IP conflict; illegal access; motion Alarm Event detection; video tampering; security exception; defocus
Illuminator Number	2 (IR) detection Pan: 0°–355°
Pan/Tilt/Rotation Range	Tilt: 0°–75° Network Rotation: 0°–355°
Network Port	RJ-45 (10/100 Base-T)
SDK and API	Yes
鏡頭類型	Motorized vari-focal Video encryption; configuration encryption; Digest;
鏡頭接口	φ14 WSSE; account lockout; security logs; generation and Cyber Security importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
焦距	2.8 mm–12 mm IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP;
Max. Aperture	F1.7 Network Protocol FTP; DHCP; DNS; NTP; Multicast; DDNS Horizontal: 101°–33.5°; Vertical: 52.5°–19°; Interoperability ONVIF (Profile S/Profile T); CGI; P2P; Milestone Field of View Diagonal: 125°–38.5°
用戶管理	6 (Total bandwidth: 36 M)
Iris Control	Fixed
Storage	FTP; Micro SD card (Support max. 256 G)
Close Focus Distance	0.8m (2.6 lb)
鏡頭	Detect Observe Recognize Identify Browser Chrome Firefox
DORI 偵測距離	48 m 19 m 10 m 5m
Distance	(157.48 ft) (62.34 ft) ( 32.81 ft) (16.40 ft)
Management Software	Smart PSS; DSS; DMSS 131 m 52 m 26 m 13m
T	Mobile Client IOS; Android (429.79 ft) (170.60 ft) ( 85.30 ft) (42.65 ft)
Video	Certification H.265; H.264; H.264B; MJPEG (Only supported by the CE-LVD: EN62368-1 Video Compression
sub stream)	CE-EMC: Electromagnetic Compatibility Directive Certifications 2014/30/EU
Smart Codec	Smart H.265+; Smart H.264+ FCC: 47 CFR FCC Part 15, Subpart B Main stream:1920 × 1080@1–25/30 fps Sub stream: 704 × 576@1–25 fps/704 × 480@1–30 fps Power
Video Frame Rate	*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding Power Supply 12V DC/PoE (802.3af) capacity. Basic: 1.8W (12 V DC); 2.4 W (PoE)
碼率控制	CBR/VBR Power Consumption Max. (H.265+ICR+IR intensity): 4.2 W (12V DC); 5.1 W (PoE) H.264: 32 kbps–6144 kbps Video Bit Rate H.265: 12 kbps–6144 kbps
Day/Night	Auto(ICR)/Color/B/W
工作溫度	–30 °C to +60 °C (–22 °F to 140 °F)
BLC	Yes
工作濕度	≤95%
HLC	Yes
防護等級	IP67 www.dahuasecurity.com
Strorage Conditions	–40°C to +60°C (–40°F to +140°F) Structure
Casing	Plastic
Product Dimensions	98.1 mm × Ø122 mm (3.86" × Ø4.80")
淨重	0.38 kg (0.84 lb)
毛重	0.56 kg (1.23 lb) Ordering Information
類型	Model Description 2MP 2MP Entry IR Vari-focal Dome DH-IPC-HDPW1230R1-ZS-S5
PFA137	Junction Mount Bracket
PFB203W	Wall Mount Bracket Dimensions (mm[inch])
PFB203W+PFA152-E	In-Ceiling Mount Bracket
PFA106+PFB220C	Ceiling Mount Bracket Accessories (Optional) PFM321D Pole Mount Bracket
LR1002-1ET/1EC	DC12V1A Power Adapter Single-port Long Reach Ethernet over PFM900-E Coax Extender
PFM114	Integrated Mount Tester Accessories Optional：
Junction Mount Bracket	Wall Mount Bracket Pole Mount Bracket
Ceiling Mount Bracket	DC12V1A Power Adapter Single-port Long Reach Ethernet over Coax Extender
PFM900-E	PFM114
Integrated Mount Tester	TLC SD Card
Rev 001.001	© 2021 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com

* 規格以原廠最新 Datasheet 為準。

規格書連結更新中，如需完整PDF請WhatsApp查詢

外形尺寸

詳見圖示｜Unit: mm

CCTV 監控安裝工程服務

HKEZIT 專營裝CAM、裝CCTV、裝監控工程，IPC-HDPW1230R1-ZS-S5 由我們供貨、安裝、調試到使用教學一站式完成。無論裝CAM、裝CCTV或裝監控，均由自家工程團隊上門施工，品質有保證。

裝CAM 裝CCTV 裝監控

CCTV 監控適合邊類專業客戶

IPC-HDPW1230R1-ZS-S5 dahua DH-IPC-HDPW1230R1-ZS-S5亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。

律師事務所

客戶機密文件與會議記錄保安需求高，門禁分級、CCTV存證、通話錄音缺一不可。

WhatsApp 查詢 →

私人銀行／財富管理

貴賓客戶室高保安等級佈點，配合監管合規存證，出入口身份記錄嚴謹。

WhatsApp 查詢 →

牙科診所

診症室私隱合規佈點、X光及貴重牙科儀器防盜，配合預約系統減少候診糾紛。

WhatsApp 查詢 →

獸醫診所

手術室同住院動物籠舍監控，主人可遠端查看住院寵物，醒晚更觀察狀態。

WhatsApp 查詢 →

保險經紀行

客戶會面室簽單過程存證，減少銷售爭議，配合保監局合規要求。

WhatsApp 查詢 →

兒科診所

候診區同診症室監控兼顧家長安心同私隱，貴重醫療儀器防盜。

WhatsApp 查詢 →

常見問題

IPC-HDPW1230R1-ZS-S5 香港哪裡有代理？

HKEZIT 提供原廠行貨連保養，IPC-HDPW1230R1-ZS-S5 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。

此型號如何供電及駁線？

支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。

錄影可以儲存多久、如何遠程監看？

儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 gDMSS/DMSS App 可隨時遠程實時監看及回放，無需固定 IP。

IPC-HDPW1230R1-ZS-S5 定 IPC-HDBW3541R-ZAS 邊個好？

兩者主要規格分別：影像感測器方面，IPC-HDPW1230R1-ZS-S5 係 1/2.8" CMOS，IPC-HDBW3541R-ZAS 係 1/2.7”5Megapixel progressive CMOS；最大解像度方面，IPC-HDPW1230R1-ZS-S5 係 1920 (H) × 1080 (V)，IPC-HDBW3541R-ZAS 係 2592 (H) ×1944 (V)；Noise Reduction方面，IPC-HDPW1230R1-ZS-S5 係 3D NR，IPC-HDBW3541R-ZAS 係 3D DNR 0 Lux (Illuminator on)。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 IPC-HDBW3541R-ZAS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
