DAHUA KTP04 CCTV攝影機安裝・保養

Name: DAHUA KTP04 DHI-KTP04
Brand: dahua
SKU: KTP04

產品簡介

dahua KTP04 為DHI-KTP04，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 KTP04 香港價格連安裝報價。

Main Processor：Embedded processor
操作系統：Embedded Linux Operation System IP65
Button Type：Mechanical
Interoperability：ONVIF; CGI Day/Night Auto (ICR) SIP; P2P; IPv4; UPnP; SNMP;
音訊輸入：1 channel Basic

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

Main Processor	Embedded processor
操作系統	Embedded Linux Operation System IP65
Button Type	Mechanical
Interoperability	ONVIF; CGI Day/Night Auto (ICR) SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; Audio Compression G.711a; G.711u; PCM Network Protocol UDP
音訊輸入	1 channel Basic
音訊輸出	Built-in speaker
Camera	1/2.9" 2MP CMOS Low Illumination HD Colorful Camera
Audio Mode	2-way voice communication
Field of View	Horizontal: 138.6°; vertical: 79.6; diagonal:159°
Audio Enhancement	Echo suppression/digital noise reduction
焦距	2.0 mm
音訊碼率	16 kHz, 16 Bit
WDR	120 dB
Status Indicator Light	3
Noise Reduction	3D NR Port
視頻壓縮	H.265
RS-485 Port	1 50Hz: Main Stream (720P@25 fps), sub stream (1080P@25 fps) Alarm Output 1 Video Resolution 60Hz: Main Stream (720P@30 fps), sub stream (1080P@30 fps) Power Output 1-ch 12 VDC 100 mA
Video Frame Rate	25 fps Exit Button 1
視頻碼率	256 kbps to 8 Mbps Door Status Detection 1
Light Compensation	Auto IR Lock Control 1 www.dahuasecurity.com
Network Port	One RJ45 10M/100M network port Leave Videos Yes (SD card inserted in VTH is needed)
General	Storage Micro SD, Max 64 GB
Appearance color	Silver Port Power Supply 24 VDC, 1 A RS-485 1 Standard PoE
警報輸入	6
Power Adapter	Optional
警報輸出	1
安裝	Flush mount
電源輸出	1.12 V/100 mA
Certifications	CE; FCC; UL
Door Bell	Yes, reusing any alarm input port
Product Dimensions	130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12")
防護等級	IK07; IP65
工作溫度	–30°C to +60°C (–22°F to 140°F)
Casing	PC + ABS
工作濕度	10%–90% (RH, non-condensing)
Operating Altitude	0 m–3,000 m 12 VDC, 1 A Power Supply Standard Poe
功耗	≤8W
淨重	0.35 kg (0.77 lb)
毛重	0.4 kg (0.88 lb)
DHI-VTH5421HW	Alarm ribbon cable (standard)
System	Product Dimensions 189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06")
網絡協議	SIP; IPv4; RTSP; RTP; TCP; UDP
ROM	128 MB
RAM	128 MB
CPU	Dual-core 1.2 GHz PFS3006-4ET-36
Basic	General
Screen Type	Capacitive 4 PoE ports with 10/100 Mbps Base-TX Network Port 2 uplink ports with 10/100Mbps Base-TX
Display Screen	7-inch TFT
解像度	1024 × 600
供電	100–240 VAC
音訊壓縮	G.711a; G.711u; PCM
PoE Budget	Port1-4 ≤30 W, whole PoE budget ≤36 W
Communication Mode	Full digital
Relevant Products	Dimensions (mm[inch]) DHI-KTP04(S)
DHI-VTO2201F-P	VTM115(Surface mounted) DHI-KTP04(F)
VTM114	VTM114 DHI-VTO2201F-P (Flush mounted, Front) (Flush mounted, Back)
Rev 002.000	© 2022 Dahua. All rights reserved. Design and specifications are subject to change without notice. The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. www.dahuasecurity.com
