| FortiGate 100D | FortiGate 140D 1 2 3 4 5 6 7 8 9 10 1 2 3 4 6 7 8 |
|---|
| Shared | CP8 1U 32GB |
|---|
| CP8 | 1U Media 32GB |
|---|
| Interfaces | Interfaces 1. USB Management Port 6. 1x GE RJ45 DMZ Port 1. USB Management Port 5. 1x GE RJ45 HA Port 2. 2x USB Ports 7. 2x GE RJ45 HA Ports 2. USB Port 6. 1x GE RJ45 Management Port 3. Console Port 8. 14x GE RJ45 Switch Ports 3. Console Port 7. 36x GE RJ45 Switch Ports 4. 2x GE RJ45 WAN Ports 9. 2x GE RJ45 Shared Ports 4. 2x GE RJ45 WAN Ports 8. 2x GE SFP DMZ Ports 5. 1x GE RJ45 Management Port 1 |
|---|
| Powered by SPU CP8 | and configure FortiGate platforms with easy-to-follow instructions. |
|---|
| §§ Providing high-speed cryptography for | The application runs on Windows, Mac OS X desktops and laptops |
|---|
| encryption and decryption | as well as popular mobile devices. Simply connect to the appropriate USB port on the appliance, and be fully protected in minutes. §§ Accelerates signature-based content |
|---|
| inspection services such as AV and IPS | Power up with PoE Interfaces The FortiGate 140D-POE include PoE interfaces that allow you to plug in compatible wireless access points and IP phones out of the box, providing ease of deployment and lower TCO. |
|---|
| generation security platform. | AV Comparatives and ICSA validated security and performance. §§ Control thousands of applications, block the latest exploits, and filter web traffic based on millions of real-time URL ratings. §§ Detect, contain and block advanced attacks automatically in minutes with integrated advanced threat protection framework. §§ Solve your networking needs with extensive routing, switching, WiFi, LAN and WA |
|---|
| FortiGuard™ Security Services | FortiCare™ Support Services |
|---|
| enforcement agencies: | §§ Comprehensive Support — For customers who need around- security intelligence, distributed via Fortinet Distributed Network hardware replacement. |
|---|
| to all Fortinet platforms. | §§ Advanced Services — For global or regional customers who 170 unique zero-day vulnerabilities to date, totaling millions of service level agreements, extended software support, priority |
|---|
| automated signature updates monthly. | escalation, on-site visits and more. intelligence, Fortinet’s network security platform is tested and security implementations that require architecture and design validated by the world’s leading third-party testing labs and services, implementation and deployment services, operational |
|---|
| customers globally. | services and more. Enterprise Bundle FortiGuard Labs delivers a number of security intelligence services to augment the FortiGate firewall platform. You can easily optimize the protection capabilities of your FortiGate with the FortiGuard Enterprise Bundle. This bundle contains the full set of FortiGuard security services plus FortiCare service and support offering the most flexibility and broades |
|---|
| FORTIGATE 100D | FORTIGATE 140D FORTIGATE 140D-POE Hardware Specifications |
|---|
| GE RJ45 Ports | 20 40 24 |
|---|
| GE RJ45 PoE Ports | – – 16 |
|---|
| GE SFP or RJ45 Shared Ports | 2 – – |
|---|
| GE SFP Ports | – 2 2 |
|---|
| USB Ports (Client / Server) | 1/2 1/1 1/1 |
|---|
| T1 Port | – – – |
|---|
| Console Port | 1 1 1 |
|---|
| Internal Storage | 32 GB 32 GB 32 GB |
|---|
| Included Transceivers | NA 0 0 System Performance |
|---|
| Firewall Throughput | 2.5 Gbps |
|---|
| Firewall Latency (64 byte UDP packets) | 37 μs 46 μs 46 μs |
|---|
| Firewall Throughput (Packets Per Second) | 300 Kpps |
|---|
| Concurrent Sessions (TCP) | 2 Million |
|---|
| New Sessions/Second (TCP) | 22,000 |
|---|
| Firewall Policies | 10,000 |
|---|
| IPsec VPN Throughput (512 byte packets) | 450 Mbps |
|---|
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
|---|
| Client-to-Gateway IPsec VPN Tunnels | 5,000 |
|---|
| SSL-VPN Throughput | 300 Mbps Concurrent SSL-VPN Users (Recommended Maximum) 300 |
|---|
| IPS Throughput (HTTP / Enterprise Mix) 1 | 950 / 310 Mbps |
|---|
| SSL Inspection Throughput 2 | 260 Mbps |
|---|
| Application Control Throughput 3 | 320 Mbps |
|---|
| NGFW Throughput 4 | 220 Mbps |
|---|
| Threat Protection Throughput 5 | 200 Mbps |
|---|
| CAPWAP Throughput 6 | 1.2 Gbps |
|---|
| Virtual Domains (Default / Maximum) | 10 / 10 Maximum Number of FortiAPs (Total / Tunnel Mode) 64 / 32 |
|---|
| Maximum Number of FortiTokens | 1,000 |
|---|
| Maximum Number of Registered FortiClients | 600 |
|---|
| High Availability Configurations | Active / Active, Active / Passive, Clustering Dimensions |
|---|
| Height x Width x Length (inches) | 1.75 x 17.01 x 11.73 1.75 x 17.01 x 12.28 1.75 x 17.01 x 12.28 |
|---|
| Height x Width x Length (mm) | 44 x 432 x 298 44 x 432 x 312 44 x 432 x 312 |
|---|
| Form Factor | Rack Mount, 1 RU Rack Mount, 1 RU Rack Mount, 1 RU |
|---|
| 重量 | 9.5 lbs (4.3 kg) 11.5 lbs (5.2 kg) 11.5 lbs (5.2 kg) |
|---|
| Power Required | 100–240V AC, 50–60 Hz |
|---|
| Maximum Current | 110 V / 3 A, 220 V / 1.5 A 110 V / 2 A, 220 V / 1 A 110 V / 4 A, 220 V / 2 A |
|---|
| Total Available PoE Power Budget* | – – 270 W |
|---|
| Power Consumption (Average / Maximum) | 52.6 W / 63.1 W 44.8 W / 58.7 W 193.4 W / 337.1 W |
|---|
| Heat Dissipation | 215.3 BTU/h 200.3 BTU/h 1150.2 BTU/h |
|---|
| Operating / Storage Temperature | 32–104°F (0–40°C) / -31–158°F (-35–70°C) |
|---|
| Operating Altitude | Up to 7,400 ft (2,250 m) |
|---|
| Humidity | 10–90% non-condensing Compliance FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 measured with IPS enabled and HTTP traffic, using TLS v1.2 with AES256-SHA. 3. Application Control performance is measured with 64 Kbytes HTTP traffic. 4. NGFW performance is measured with IPS and Application Control enabled, based on Ent |
|---|
| Product | SKU Description |
|---|
| FortiGate 140D | FG-140D 40x GE RJ45 (including 36x switch ports, 2x Mgmt/HA ports, 2x WAN ports), 2x GE SFP DMZ slots, 32 GB onboard storage. Maximum managed FortiAPs (Total / Tunnel) 64 / 32. |
|---|
| FortiGate 140D-POE | FG-140D-POE 40x GE RJ45 (including 16x PoE ports, 20x switch ports, 2x Mgmt/HA ports, 2x WAN ports), 2x GE SFP DMZ slots, 32 GB onboard storage. Maximum managed FortiAPs (Total / Tunnel) 64 / 32. |
|---|
