| 操作系統 | Windows Server 2022 IoT |
|---|
| Memory | 32GB (2x16GB) DDR5, RDIMM 4800 MT/s |
|---|
| Storage | M.2 SSD 2x480GB On RAID 1 (1) Intel Xeon Silver 4410Y Scalable Processors (12Core, 24 Threads, Base Frequency 2.00GHz, Processor Turbo Frequency 3.90Ghz) |
|---|
| Networking | (2) 1GbE RJ45 Ports, (2)10/25Gb SFP28 OCP NIC 3.0 |
|---|
| PCIe | 1 PCIe slots (1 x16 Gen4) |
|---|
| Ports | 1 x USB 2.0, 1 x USB 3.0, 1 x VGA |
|---|
| Video Outputs | 1xVGA |
|---|
| Remote Management | iDRAC9 Storage |
|---|
| Hard Drive Bays | (24) 3.5" Hot Swappable Bays, (2) M.2 SSD Slots |
|---|
| Maximum Storage | up to 480TB of RAW Storage (20TB) |
|---|
| Hard Drive Supported | PCIe NVMe, SSD, SAS & SATA |
|---|
| RAID | RAID 0, 1, 5, 6, 10 |
|---|
| RAID Controller | PERC H755 Controller with 8Gb NVME Cache Recording Rate Throughput 128Channel - Up to 700Mbps, 256Channel – Up to 1.5Gbps |
|---|
| Recording Rate | 384Channel – Up to 2Gbps, *512Channel – Up to 2.7Gbps * The calculation is based upon these parameters: 1080p @ 30fps, 5Mbps/Channel H.264 * Compatible with other Third-party VMS (for more details please contact our sales team) |
|---|
| Form Factor | 2U |
|---|
| 供電 | 2x1100W (100-240VAC) Platinum |
|---|
| 工作溫度 | (Min) 50°F - (Max) 95° F, (Min) 10°C - (Max) 35° C |
|---|
| 工作濕度 | 10 ~ 80% (non-condensing) |
|---|
| Heat Dissipation | 4125 Max BTU/hr |
|---|
| Dimensions (WxDxH) | 18.97” (482mm) x 34.36” (872.74mm) x 3.39” (86.8mm) |
|---|
| Max. Weight | 102.07 lbs. (46.3Kg) |
|---|
| Warranty | 5 Years On-Site, Next Business Day, Keep your Hard Drive Warranty Models PRO-224-252-12 |
|---|
| PRO-1-224-252-12 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-252-12 | 32GB RAM, (21)x12TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-252-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-252-12 PRO-224-264-12 |
|---|
| PRO-1-224-264-12 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-264-12 | 32GB RAM, (22)x12TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-264-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-264-12 PRO-224-276-12 |
|---|
| PRO-1-224-276-12 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-276-12 | 32GB RAM, (23)x12TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-276-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-276-12 PRO-224-288-12 |
|---|
| PRO-1-224-288-12 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-288-12 | 32GB RAM, (24)x12TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-288-12 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-288-12 PRO-224-208-16 |
|---|
| PRO-1-224-208-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-208-16 | 32GB RAM, (13)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-208-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-208-16 PRO-224-224-16 |
|---|
| PRO-1-224-224-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-224-16 | 32GB RAM, (14)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-224-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-224-16 PRO-224-240-16 |
|---|
| PRO-1-224-240-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-240-16 | 32GB RAM, (15)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-240-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-240-16 PRO-224-256-16 |
|---|
| PRO-1-224-256-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-256-16 | 32GB RAM, (16)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-256-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-256-16 PRO-224-272-16 |
|---|
| PRO-1-224-272-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-272-16 | 32GB RAM, (17)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-272-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-272-16 PRO-224-288-16 |
|---|
| PRO-1-224-288-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-288-16 | 32GB RAM, (18)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-288-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-288-16 Models PRO-224-304-16 |
|---|
| PRO-1-224-304-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-304-16 | 32GB RAM, (19)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-304-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-304-16 PRO-224-320-16 |
|---|
| PRO-1-224-320-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-320-16 | 32GB RAM, (20)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-320-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-320-16 PRO-224-336-16 |
|---|
| PRO-1-224-336-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-336-16 | 32GB RAM, (21)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-336-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-336-16 PRO-224-352-16 |
|---|
| PRO-1-224-352-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-352-16 | 32GB RAM, (22)x16TB HDD (2)1GbE, (2) 10/25Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-352-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-352-16 PRO-224-368-16 |
|---|
| PRO-1-224-368-16 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-368-16 | 32GB RAM, (23)x16TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-368-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-368-16 PRO-224-384-16 |
|---|
| PRO-1-224-384-16 | 2U 24bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-384-16 | 32GB RAM, (24)x16TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-384-16 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-384-16 PRO-224-260-20 |
|---|
| PRO-1-224-260-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-260-20 | 32GB RAM, (13)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-260-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-260-20 PRO-224-280-20 |
|---|
| PRO-1-224-280-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-280-20 | 32GB RAM, (14)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-280-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-280-20 PRO-224-300-20 |
|---|
| PRO-1-224-300-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-300-20 | 32GB RAM, (15)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-300-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-300-20 PRO-224-320-20 |
|---|
| PRO-1-224-320-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-320-20 | 32GB RAM, (16)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-320-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-320-20 Models PRO-224-340-20 |
|---|
| PRO-1-224-340-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-340-20 | 32GB RAM, (17)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-340-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-340-20 PRO-224-360-20 |
|---|
| PRO-1-224-360-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-360-20 | 32GB RAM, (18)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-360-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-360-20 PRO-224-380-20 |
|---|
| PRO-1-224-380-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-380-20 | 32GB RAM, (19)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-380-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-380-20 PRO-224-400-20 |
|---|
| PRO-1-224-400-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-400-20 | 32GB RAM, (20)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-400-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-400-20 PRO-224-420-20 |
|---|
| PRO-1-224-420-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-420-20 | 32GB RAM, (21)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-420-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-420-20 PRO-224-440-20 |
|---|
| PRO-1-224-440-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-440-20 | 32GB RAM, (22)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-440-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-440-20 PRO-224-460-20 |
|---|
| PRO-1-224-460-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-460-20 | 32GB RAM, (23)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-460-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-460-20 PRO-224-480-20 |
|---|
| PRO-1-224-480-20 | 2U 24 bay, (1) Intel Xeon Silver 4410 Scalable Processor, 12Core, 2x480GB M.2 Boss Card on RAID 1 for OS, |
|---|
| PRO-2-224-480-20 | 32GB RAM, (24)x20TB HDD (2)1GbE, (2) 10Gb SFP, PERC H755 8GB NV Cache RAID Controller, iDRAC |
|---|
| PRO-3-224-480-20 | Enterprise 16G, (2) 800W PSU, Windows Server 2022 IoT, 5Yrs Warranty with KYHD. PRO-4-224-480-20 |
|---|
