| Imaging Device | 1/2.8" 2.38M CMOS |
|---|
| Total / Effective Pixels | 1,952(H) x 1,116(V), 2.18M pixels / 1,944(H) x 1,104(V), 2.14M pixels |
|---|
| Scanning System | Progressive Color : 0.3Lux (1/30sec, F1.6, 50IRE, AGC high) , 0.005Lux (2sec, F1.6, 50IRE, AGC high) |
|---|
| 最低照度 | B/W : 0.03Lux (1/30sec, F1.6, 50IRE, AGC high), 0.0005Lux (2sec, F1.6, 50IRE, AGC high) Color : 0.15Lux (1/30sec, F1.6, 30IRE), 0.0025Lux (2sec, F1.6, 30IRE) B/W : 0.015Lux (1/30sec, F1.6, 30IRE), 0.00025Lux (2sec, F1.6, 30IRE) |
|---|
| S / N Ratio | 50dB |
|---|
| Video Output | CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation |
|---|
| Focal Length (Zoom Ratio) | 4.44 ~ 102.1mm (Optical 23x) |
|---|
| Max. Aperture Ratio | F1.6(Wide) / F3.63(Tele) |
|---|
| Angular Field of View | H : 62.8˚(Wide) ~ 3.14˚(Tele) / V : 36.8˚(Wide) ~ 1.76˚(Tele) |
|---|
| Min. Object Distance | Wide : 1.5m (4.92ft), Tele : 1.9m (6.23ft) Wide : 1.5m (4.92ft), Tele : 2m (6.56ft) |
|---|
| Focus Control | Auto / Manual / One push |
|---|
| Lens / Mount Type | DC auto iris / Board-in type Pan / Tilt / Rotate |
|---|
| Pan / Tilt Range | 360˚ Endless / 210˚ (-15˚ ~195˚ ) |
|---|
| Pan / Tilt Speed | Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec |
|---|
| Sequence | Preset (255ea), Swing, Group (6ea), Trace, Tour (1ea), Auto run, Schedule |
|---|
| Preset Accuracy | ±0.2˚ |
|---|
| Azimuth | Yes (E / W / S / N / NE / NW / SE / SW) Operational |
|---|
| Camera Title | Off / On (Displayed up to 45 characters) |
|---|
| SNP-L6233H | SNP-L6233 Day & Night Auto (ICR) / Color / B/W |
|---|
| Backlight Compensation | Off / BLC |
|---|
| 寬動態 WDR | 100dB |
|---|
| Contrast Enhancement | SSDR (Samsung Super Dynamic Range) (Off / On) |
|---|
| Digital Noise Reduction | SSNRIII (2D+3D noise filter) (Off / On) |
|---|
| Key Features | Digital Image Stabilization Defog Off / On Off / Auto / Manual |
|---|
| Motion Detection | Off / On (4ea rectangle zone) |
|---|
| • Max. 2M (1920 x 1080) resolution | Privacy Masking Off / On (32 zones of rectangle zone) with zoom threshold mosaic option |
|---|
| Gain Control | Off / Low / Middle / High |
|---|
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
|---|
| Flip / Mirror | Off / On |
|---|
| Alarm I/O | Input 4ea / Output 2ea (Relay) |
|---|
| RS-485 Protocol | Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE Alarm Triggers Video analytics, Alarm input, Network disconnection Alarm Events SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output |
|---|
| Ethernet | RJ-45 (10/100BASE-T) |
|---|
| 尺寸 | Unit : mm (inch) Video Compression Format H.264 (MPEG-4 part 10 / AVC), MJPEG |
|---|
| 解像度 | 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, (0.79") (0.79") |
|---|
| Ø223.4 | (8.8") |
|---|
| Ø223.4 (8.8") | 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 H.264 : Max. 30fps at all resolutions 20.0 20.0 |
|---|
| Max. Framerate | MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps 293.6(11.56") 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps (11.56") |
|---|
| Smart Codec | Yes |
|---|
| Video Quality Adjustment | H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control 293.6 |
|---|
| Bitrate Control Method | H.264 : CBR or VBR, MJPEG : VBR |
|---|
| Streaming Capability | Multiple streaming (Up to 10 profiles) |
|---|
| 音訊輸入 | Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
|---|
| Audio Out | Line out (3.5mm mono jack), Max output level : 1 Vrms |
|---|
| Audio Compression Format | G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, |
|---|
| Audio Communication | Bi-directional audio |
|---|
| IP | IPv4, IPv6 |
|---|
| Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour 27.6 (1.09") 27.6 (1.09") |
|---|
| Ø152.0 | (5.98") Ø152.0 (5.98") |
|---|
| 安全 | HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
|---|
| Streaming Method | Unicast / Multicast 218.0(8.58") |
|---|
| Max. User Access | 10 users at unicast mode (8.58") SD/SDHC/SDXC slot for supporting memory card |
|---|
| SNP-L6233 | Edge Storage Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded 218.0 NAS (Network Attached Storage) Application Programming Interface ONVIF profile S, SUNAPI (HTTP API), SVNP 1.2 English, French, German, Spanish, Italian, Chinese, Russian, Japanese, |
|---|
| Webpage Language | Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian Ø133.2 (5.24") |
|---|
| Ø133.2 | (5.24") Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 |
|---|
| Web Viewer | Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) |
|---|
| Accessories (Optional) | * Mac OS X only Central Management Software SmartViewer, SSM Environmental 24V AC : -50°C ~ +55°C (-58°F ~ +131°F) / |
|---|
| SBP-301HF SBP-300PM | SBP-301HM3 Operating Temperature / Less than ~ 90% RH -10°C ~ +55°C (+14°F ~ +131°F) / |
|---|
| Humidity | PoE+ : -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH Less than 90% RH Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
|---|
| 防護等級 | IP66 N/A |
|---|
| Vandal Resistance | IK10 IK10 (With SHP-3701H) Electrical (SNP-L6233) 24V AC : Max. 65W (24V AC heater on & PoE heater on) Max. 20W Power Consumption PoE+ : Max. 25W (24V AC heater off / PoE heater on) mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur Color / Material Ivory / Plastic + Metal when a memory card reaches end of life, which varies according to operational c |
|---|
