| Focal Length (Zoom Ratio) | 3 ~ 8.5mm (2.8x) Motorized vari-focal |
|---|
| Max. Aperture Ratio | F1.2 |
|---|
| Angular Field of View | H : 100°(Wide) ~ 35.3°(Tele), V : 74.6°(Wide) ~ 26°(Tele) |
|---|
| Min. Object Distance | 0.5m (1.64ft) |
|---|
| Focus Control | Remote control via network (Manual, One-shot AF) |
|---|
| 鏡頭類型 | DC Auto Iris PAN / TILT / ROTATE |
|---|
| Pan Range | 0° ~ 355° |
|---|
| Tilt Range | 0° ~ 90° |
|---|
| Rotate Range | 0° ~ 355° OPERATIONAL |
|---|
| Camera Title | Off / On (Displayed up to 15 characters) |
|---|
| 日夜切換 | Auto (ICR) / Color / B/W / External B/W |
|---|
| Backlight Compensation | Off / BLC / HLC / WDR |
|---|
| 寬動態 WDR | Off / On (Full HD WDR), 52dB |
|---|
| Contrast Enhancement | SSDR (Samsung Super Dynamic Range) (Off / On) |
|---|
| SND-7080 | SND-7080F |
|---|
| Digital Noise Reduction | SSNRIII (2D+3D noise filter) (Off / On) |
|---|
| Motion Detection | Off / On (4 programmable zones) |
|---|
| Privacy Masking | Off / On (1ea 4 point polygonal + 16ea rectangular zones) |
|---|
| Sens-up (Frame Integration) | Off / Auto (2x ~ 60x) Gain Control |
|---|
| Key Features | White Balance Off / Low / Medium / High ATW / AWC / Manual / Indoor / Outdoor |
|---|
| Electronic Shutter Speed | Auto / A.FLK / Manual (1/30 ~ 30,000sec) |
|---|
| • Max. 3M (2048 x 1536) resolution | Flip / Mirror Off / On |
|---|
| • 16:9 Full HD (1080p) resolution support | Intelligent Video Analytics Scene Change, Virtual Line, Enter / Exit, Appear / Disappear |
|---|
| Alarm I/O | Input 1ea / Output 1ea (Relay) |
|---|
| • 3~8.5mm (2.8x) motorized varifocal lens | Remote Control Interface RS-485 |
|---|
| • H.264 / MJPEG multiple codecs | RS-485 Protocol Samsung-T/E, Pelco-P/D, Sungjin |
|---|
| • Full HD WDR | NETWORK |
|---|
| Ethernet | RJ-45 (10/100BASE-T) |
|---|
| • Smart Compression (ROI encoding) | Video Compression Format H.265/H.264: Main/Baseline/High, MJPEG 3M mode : 2048 x 1536, 1920 x 1080P (Full HD), 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, |
|---|
| 解像度 | 320 x 240, 320 x 180 2M mode : 1920 x 1080P (Full HD), 1280 x 1024, 1280 x 960, 1280 x 720P (HD), 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 3M mode : * H.264 : Max 20fps at all resolutions * MJPEG : 800 x 600 ~ 320 x 180 - 20 fps, 1280 x 1024 ~1600 x 1200 - 15 fps, |
|---|
| Max. Framerate | 1920x1080 ~ 2048 x 1536 - 10 fps 2M mode : * H.264 : Max 30fps at all resolutions (When WDR ON, Max. framerate is Max 15fps.) * MJPEG : 800 x 600 ~ 320 x 180 - 30 fp, 1280 x 1024 ~ 1920 x 1080 : 15 fps |
|---|
| Smart Codec | Yes (Area Based Method, Face Detection Method) |
|---|
| 尺寸 | Unit : mm (inch) |
|---|
| Video Quality Adjustment | H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
|---|
| Bitrate Control Method | H.264 : CBR or VBR, MJPEG : VBR |
|---|
| Streaming Capability | Multiple streaming (Up to 6 profiles) |
|---|
| Audio I/O | Mic / Line in, Line out Audio Compression Format G.711 u-law |
|---|
| Audio Communication | 2-Way 129.4 (5.09") |
|---|
| IP | IPv4, IPv6 |
|---|
| Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS |
|---|
| 安全 | HTTPS(SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1x authentication |
|---|
| Streaming Method | Unicast / Multicast |
|---|
| Max. User Access | 10 users at unicast mode |
|---|
| Ø133 (5.24") | Ø133 (5.24") Memory Slot SD/SDHC memory slot English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, |
|---|
| Web Viewer | Supported OS : Windows XP / VISTA / 7, MAC OS, Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari Central Management Software NET-i viewer |
|---|
| Ø159.9 (6.3") | ENVIRONMENTAL Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / 20% ~ 80% RH ELECTRICAL |
|---|
| Input Voltage / Current | 12V DC, 24V AC, PoE (IEEE802.3af) 125.0 (4.92") |
|---|
| 功耗 | Max. 6W (DC 12V), Max. 7W (AC 24V, PoE (DC 48V)) |
|---|
| Color / Material | Ivory / Plastic |
|---|
| Dimensions (WxH) | SND-7080 : Ø133.0 x 129.4mm (Ø5.24" x 5.09"), SND-7080F : Ø159.9 x 125.0mm (Ø6.3" x 4.92") (Flush mounting type) |
|---|
| 重量 | SND-7080 : 700g (1.54 lb), SND-7080F : 800g (1.76 lb) * You can find applicable models with accessory selector www.hanwha-security.com/en/products/accessory-selector/ |
|---|
| SND-7080F | * The lastest product information / specification can be found at hanwha-security.com * Design and specifications are subject to change without notice. * Wisenet is the proprietary brand of Hanwha Techwin formerly known as Samsung Techwin. REVISED EDITION 02-2020 © 2020 Hanwha Techwin Co., Ltd. All rights reserved. |
|---|
