HANWHA SND-L5013 CCTV攝影機安裝・保養

Name: HANWHA SND-L5013 1.3Megapixel HD Network Dome Camera
Brand: hanwha
SKU: SND-L5013

產品簡介

hanwha SND-L5013 為1.3Megapixel HD Network Dome Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SND-L5013 香港價格連安裝報價。

Imaging Device：1/3" 1.37M CMOS
Total Pixels：1,312(H) x 1,069(V)
Effective Pixels：1,305(H) x 1,049(V)
Scanning System：Progressive Color : 0.085Lux (1/30sec, F1.8), 0.0008Lux (2s
Focal Length (Zoom Ratio)：3.6mm fixed

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

SND-L5013 hanwha 1.3Megapixel HD Network Dome Camera 產品圖片

詳細規格

Imaging Device	1/3" 1.37M CMOS
Total Pixels	1,312(H) x 1,069(V)
Effective Pixels	1,305(H) x 1,049(V)
Scanning System	Progressive Color : 0.085Lux (1/30sec, F1.8), 0.0008Lux (2sec, F1.8) Min. Illumination B/W : 0.085Lux (1/30sec, F1.8)
Focal Length (Zoom Ratio)	3.6mm fixed
Max. Aperture Ratio	F1.8
Angular Field of View	H : 74˚ / V : 58˚ / D : 97˚
Min. Object Distance	0.5m (1.64ft)
鏡頭類型	Fixed
Mount Type	Board type Pan / Tilt / Rotate
Pan / Tilt / Rotate Range	0° ~ 350° / 0° ~ 67° / 0° ~ 355° Operational
Camera Title	Off / On (Displayed up to 15 characters)
日夜切換	Electric Day & Night
Backlight Compensation	Off / BLC Contrast Enhancement (DWDR) SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction	SSNR (Off / On)
Motion Detection	Off / On (4ea rectangular zones)
Privacy Masking	Off / On (6ea rectangular zones)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor
Key Features	LDC (Lens Distortion Correction) Off / On (5 levels with min / max)
Electronic Shutter Speed	Minimum / Maximum / Anti flicker
Flip / Mirror	Flip / Mirror / Hallway view
• Max. 1.3M (1280 x 1024) resolution	Intelligent Video Analytics Motion detection with metadata, Tampering
• 16 : 9 HD (720P) resolution support	Alarm Triggers Motion detection, Tampering detection, SD card error, NAS error
Alarm Events	File upload via FTP and E-mail, Local storage recording at event, Notification via E-mail
• 3.6mm fixed lens	Network
Video Compression Format	H.264, MJPEG
• 30fps@all resolutions (H.264)	1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, Resolution H.264 : Max. 30fps at all resolutions
• Motion detection, Tampering, DWDR	Max. Framerate MJPEG : Max. 1fps at 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
• micro SD/SDHC memory slot, PoE	Max. 15fps at other resolution
Video Quality Adjustment	H.264 : Target bitrate level control, MJPEG : Quality level control
• Hallway view support (Rotate 90˚/270˚)	Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Audio I/O	Built-in mic G.711 u-law / G.726 selectable Audio Compression Format G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
尺寸	Unit : mm (inch)
Audio Communication	Uni-directional audio
IP	IPv4, IPv6 TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour HTTPS(SSL) login authentication, Digest login authentication Security IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	6 users at unicast mode 86.0(3.39") (3.39") micro SD/SDHC max. 32G, NAS
Storage	- Motion images recorded in the SD memory card can be downloaded 86.0 - Manual recording at local PC Application Programming Interface ONVIF Profile S, G, SUNAPI (HTTP API) English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Webpage Language	Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish
Ø110.0	(4.33") Ø110.0 (4.33") Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 35),
Web Viewer	Google Chrome (Ver. 15 ~ 40), Apple Safari (Ver. 8.0.2(Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7)
Accessories (Optional)	* Mac OS X only Central Management Software SmartViewer Environmental Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH Electrical
Input Voltage / Current	PoE (IEEE802.3af, Class2)
功耗	Max. 2.4W
Color / Material	Ivory / Plastic
Dimensions (WxH)	Ø110.0 x 86.0mm (Ø4.33" x 3.39") mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur when a memory card reaches end of life, which varies according to operational conditions. * The latest product information / specification can be found at www.samsungsecurity.com No guarantee is given against damage (including passive damage). 11-09-2015 ⓒ 2015 Hanwha
