HIKVISION DS-2CD6D54G1-ZS CCTV攝影機安裝・保養

Name: HIKVISION DS-2CD6D54G1-ZS Quad-Directional Varifocal PanoVu Camera
Brand: Hikvision
SKU: DS-2CD6D54G1-ZS

產品簡介

Hikvision DS-2CD6D54G1-ZS 為Quad-Directional Varifocal PanoVu Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DS-2CD6D54G1-ZS 香港價格連安裝報價。

DORI 偵測距離：Detect Observe Recognize Identify
Distance (Wide)：60 m 23 m 12 m 6m
Distance (Tele)：120 m 47 m 24 m 12 m
影像感測器：1/2.7" Progressive Scan CMOS Color: 0.0125 Lux @(F1.9, AGC O
快門速度：1 s to 1/100,000 s

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

DS-2CD6D54G1-ZS Hikvision Quad-Directional Varifocal PanoVu Camera 產品圖片

詳細規格

DORI 偵測距離	Detect Observe Recognize Identify
Distance (Wide)	60 m 23 m 12 m 6m
Distance (Tele)	120 m 47 m 24 m 12 m
影像感測器	1/2.7" Progressive Scan CMOS Color: 0.0125 Lux @(F1.9, AGC ON) B/W: 0.0025 Lux @(F1.9, AGC ON)
快門速度	1 s to 1/100,000 s
慢快門	Yes
Day &Night	IR cut filter
角度調節	Pan: -60° to 60°, tilt: 10° to 90°, rotate: 0° to 350°
WDR	120 dB
光圈	F1.9
對焦	Manual, semi-auto
視場角 FOV	Horizontal FOV 100° to 49°, vertical FOV 72° to 36.4°, diagonal FOV 134.4° to 61.4°
鏡頭接口	Ø 14
鏡頭類型	Varifocal lens, 2.8 to 8 mm
最大解像度	2560 × 1920
Video Stream	3 defined streams 50 Hz: 25 fps (2560 × 1920, 2048 × 1536, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2560 × 1920, 2048 × 1536, 1920 × 1080, 1280 × 720) 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 24 fps (704 × 480, 640 × 480) 50 Hz: 6 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 8 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Main stream: H.265+/H.265/H.264+/H.264
視頻壓縮	Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 類型	Baseline Profile/Main Profile/High Profile
H.265 類型	Main Profile
視頻碼率	32 Kbps to 16 Mbps
SVC	H.264 encoding
H.264+	Main stream support
H.265+	Main stream support
音訊壓縮	G.711/G.722.1/G.726/MP2L2/PCM
音訊碼率	64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)
環境噪音過濾	Yes
音訊取樣率	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable Region entrance detection, up to 4 regions configurable
智能事件	Region exiting detection, up to 4 regions configurable Unattended baggage detection, up to 4 regions configurable Object removal detection, up to 4 regions configurable Scene change detection, audio exception detection, defocus detection Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region of Interest	4 fixed regions for each stream output, trigger recording, trigger capture
影像增強	BLC, HLC, 3D DNR, Defog, EIS Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping	Yes
日夜模式	Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay	LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
信噪比 SNR	≥52 dB
網絡儲存	microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS,SMB/CIFS), ANR TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API	Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome Password protection, complicated password, HTTPS encryption, 802.1X authentication
安全	(EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/ HTTPS, WSSE and digest authentication for Open Network Video Interface
同時取流	Up to 20 channels
用戶管理	Up to 32 users. 3 user levels: administrator, operator and user
客戶端	iVMS-4200, Hik-Connect, Hik-Central
瀏覽器	IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11 1 RJ45 10M/100M/1000M Ethernet port
通訊接口	built-in RS-232 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self- adaptive)
Audio	1 input (line in), 1 output (line out), 3.5 mm three-contact
警報	2 inputs, 2 outputs (max. 24 VDC, 1A)
機身儲存	Built-in microSD/SDHC/SDXC slot, up to 128 GB 47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,
EMC	EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015 UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry	2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
防護等級	IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
韌體版本	V5.5.32 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
介面語言	French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
一般功能	Anti- flicker, 3 streams, heartbeat, mirror, privacy masks
重設	Reset via reset button on camera body, web browser and client software -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
儲存環境	-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
供電	24 VAC ± 20%; PoE (802.3af, class 0) 12 VDC, 1.2 A, 14 W Power Consumption and 24 VAC, 1 A, 14 W Current PoE (802.3af, 36 to 57 VDC), 0.36 A to 0.22 A, 13 W, class 0
材質	Bubble: plastic, camera: metal Camera: Ø255 × 95.9 mm (10″ × 3.8″) Dimensions With package: 312 × 311 × 163 mm (13.2″ × 10.3″ × 11.5″) Camera: 2.1 kg (4.7 lb.) Weight With package: 3.4 kg (7.5 lb.)
