0.005 Lux@(F1.6, AGC ON), 0 Lux with IR PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
Day ＆ Night
IR cut filter
角度調節
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Signal System
PAL/NTSC
鏡頭類型
2.7 mm to 13.5 mm
Focal Length ＆ FOV
102° to 31°
鏡頭接口
Φ 14
圖像參數切換
STD/HIGH-SAT
圖像設定
Brightness, Sharpness, 3D DNR, Mirror, Smart IR PAL: 1080p@25fps NTSC: 1080p@30fps
Day/Night Mode
Auto/Color/BW (Black and White)
寬動態 WDR
≥ 120 dB
影像增強
Yes
White Balance
ATW/MWB
AGC
High/Medium/Low
Video Output
TVI/AHD/CVI/CVBS
材質
Main body: Plastic Bracket: Metal
尺寸
84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10") Approx. 648 g (1.43 lb.) -A: Approx. 695 g (1.53 lb.)
工作環境
‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Communication
Up the coax, Protocol: HIKVISION-C (TVI output)
語言
English 12 VDC ±25% -A: 24 VAC ±15%, 12 VDC ±20% *You are recommended to use one power adapter to supply the power for one camera. Max. 7.7 W -A: Max. 9.7 W
