Hikvision DS-2XC3686G0H-LIZSU-PA 為8 MP Smart Hybrid Light Varifocal Dome Polymer Anti-Corrosion Network Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DS-2XC3686G0H-LIZSU-PA 香港價格連安裝報價。
| 影像感測器 | 1/1.8" Progressive Scan CMOS |
|---|---|
| 最大解像度 | 3840 × 2160 |
| 最低照度 | Color: 0.0008 Lux @ (F1.2, AGC ON),0 Lux with light |
| 快門速度 | 1/3 s to 1/100,000 s |
| 日夜切換 | IR cut filter |
| 角度調節 | Pan: 0° to 90°,tilt: 0° to 360°,rotate: 0° to 360° |
| 鏡頭類型 | Varifocal lens, motorized lens, 2.7 to 13.5 mm and 7 to 35 mm optional 2.7 to 13.5 mm, horizontal FOV 112.3 to 41.2°, vertical FOV 58.1° to 23.1°, diagonal FOV 137.4°to 47.3° 7 to 35 mm： horizontal FOV 41.8to 15°, vertical FOV 22.9° to 8.5°, diagonal FOV 48.7° to 17.1° |
| 對焦 | Auto,Semi-auto,Manual |
| 光圈類型 | DC iris 2.7 to 13.5 mm: max F1.2, 7 to 35 mm: max F1.7 |
| Depth of Field | 1 m to ∞ 2.7 to 13.5 mm: Wide: D: 89.2m, O: 35.4 m, R: 17.8 m, I: 8.9 m Tele: D: 220.0 m, O: 87.3 m, R: 44.0 m, I: 22.0 m 7 to 35 mm: Wide: D: 218.0 m, O: 86.5 m, R: 43.6 m, I: 21.8 m Tele: D: 580.0 m, O: 230.2 m, R: 116.0 m, I: 58.0 m |
| 補光類型 | IR,White Light |
| 補光距離 | Up to 50 m |
| 智能補光 | Yes |
| 紅外波長 | 850 nm Memory: 60 MB, |
| Open Resources | Smart RAM: 371 MB, eMMC: 2 GB |
| Computing Power | 1.5 TOPS HEOP 2.0 OpendevSDK, Basic service, basic media capability, deep learning reasoning acceleration capability |
| Deep Learning Structure | Caffe,PyTorch,TensorFlow,PaddlePaddle,ONNX |
| Programming Language | C,C++,Go 50 Hz: 20 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (704 × 480, 640 × 480) 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) |
| 第三碼流 | 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) *Third stream is supported under certain settings. 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) |
| Fourth Stream | 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under certain settings. Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, |
| 視頻壓縮 | Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, *Third stream and fourth stream are supported under certain settings. |
| 視頻碼率 | 32 Kbps to 16 Mbps |
| H.264 類型 | Baseline Profile,Main Profile,High Profile |
| H.265 類型 | Main Profile |
| 碼率控制 | CBR,VBR |
| SVC 分級編碼 | H.264 and H.265 encoding |
| 感興趣區域 ROI | 5 fixed regions for main stream |
| Target Cropping | Yes |
| 音訊壓縮 | -U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| 音訊取樣率 | -U: 8 kHz/16 kHz/32 kHz/48 kHz |
| 環境噪音過濾 | -U: Yes TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, |
| 網絡協議 | IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP |
| 同時取流 | Up to 20 channels |
| API | ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP Up to 32 users 3 user levels: administrator, operator, and user Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest |
| 安全 | authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), |
| 網絡儲存 | Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| 客戶端 | iVMS-4200,Hik-Connect,Hik-Central |
| 瀏覽器 | Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+, Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+ |
| 圖像參數切換 | Yes Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| 日夜模式 | Day,Night,Auto,Schedule,Alarm Trigger |
| 寬動態 WDR | 130 dB |
| 影像增強 | BLC,HLC,3D DNR,Defog |
| 信噪比 SNR | ≥ 52 dB |
| 隱私遮蔽 | 4 programmable polygon privacy masks |
| 網絡接口 | 1 RJ45 10 M/100 M self-adaptive Ethernet port Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB, *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. The memory card needs to be installed before leaving the factory. |
| 內置麥克風 | -U: Yes,1 built-in microphone -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium -S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| 警報 | -S: 1 input, 1 output (max. 12 VDC, 0.1 A) |
| RS-485 | -S: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| 重設鍵 | Yes Motion detection (support alarm triggering by specified target types (human and |
| 基本事件 | vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) unattended baggage detection,object removal detection,scene change detection,audio exception detection,defocus detection Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,-S: trigger alarm output Line crossin |
| 材質 | Body: SMC+ 30% GF, Bracket: PA66+ 15% GF, Junction Box: Anodized ADC12 |
| 尺寸 | 294.27 mm × 120.8 mm × 121.36 mm (11.59" × 4.76" × 4.77") |
| 包裝尺寸 | 395 mm × 195 mm × 158 mm (15.55" × 7.68" × 6.22") |
| 重量 | Approx. 1480 g (3.26 lb.) |
| 連包裝重量 | Approx. 2035 g (4.49 lb.) |
| 儲存環境 | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Language Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chi nese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| EMC | RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 CE-RoHS: 2011/65/EU, |
| Environment | WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| 防護等級 | IP68: IEC 60529-2013,IK10: IEC 62262:2002 NEMA 4X: NEMA 250-2018 C5-M: 720H neutral salt spray, 480H water condensation; Exterior environments: industrial areas with high humidity and aggressive atmosphere Anti-Corrosion Protection and coastal areas with high salinity; Interior environments: buildings or areas with almost permanent condensation and with high pollution. |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →
294.27 mm × 120.8 mm × 121.36 mm (11.59" × 4.76" × 4.77")｜重量 Approx. 1480 g (3.26 lb.)｜Unit: mm
DS-2XC3686G0H-LIZSU-PA Hikvision 8 MP Smart Hybrid Light Varifocal Dome Polymer Anti-Corrosion Network Camera亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，DS-2XC3686G0H-LIZSU-PA 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 Hik-Connect App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：影像感測器方面，DS-2XC3686G0H-LIZSU-PA 係 1/1.8" Progressive Scan CMOS，DS-2DF8425IXG1-ELWY 係 1/1.8" progressive scan CMOS；最大解像度方面，DS-2XC3686G0H-LIZSU-PA 係 3840 × 2160，DS-2DF8425IXG1-ELWY 係 2688 × 1520；快門速度方面，DS-2XC3686G0H-LIZSU-PA 係 1/3 s to 1/100,000 s，DS-2DF8425IXG1-ELWY 係 1/1 s to 1/30,000 s。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 DS-2DF8425IXG1-ELWY 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
