| 影像感測器 | 1/1.8" Progressive Scan CMOS |
|---|
| 最大解像度 | 3840 × 2160 |
|---|
| 最低照度 | Color: 0.003 Lux @ (F1.6, AGC ON),0 Lux with light |
|---|
| 快門速度 | 1/3 s to 1/100,000 s |
|---|
| 日夜切換 | IR cut filter 2.8 mm, horizontal FOV 101.8°, vertical FOV 50.8°, diagonal FOV 124.4° |
|---|
| 鏡頭及視場角 | 4 mm, horizontal FOV 87.6°, vertical FOV 46.0°, diagonal FOV 103.5° 6 mm, horizontal FOV 60°, vertical FOV 34.8°, diagonal FOV 67.8° |
|---|
| 光圈 | F1.6 |
|---|
| 補光類型 | IR,White Light IR: up to 30 m White Light: up to 30 m |
|---|
| 紅外波長 | 850 nm 50 Hz: 12.5 fps (3840 × 2160) 60 Hz: 12.5 fps (3840 × 2160) 50 Hz: 12.5 fps (640 × 480, 640 × 360) 60 Hz: 12.5 fps (640 × 480, 640 × 360) 50 Hz: 1 fps (1280 × 720, 640 × 360) 60 Hz: 1 fps (1280 × 720, 640 × 360) Main stream: H.265+/H.265/H.264+/H.264, |
|---|
| 視頻壓縮 | Sub-stream: H.265/H.264/MJPEG Third Stream：H.265/H.264 |
|---|
| 視頻碼率 | 32 Kbps to 16 Mbps |
|---|
| H.264 類型 | Baseline Profile,Main Profile,High Profile |
|---|
| H.265 類型 | Main Profile |
|---|
| SVC 分級編碼 | H.264 and H.265 encoding |
|---|
| 感興趣區域 ROI | 1 fixed region for main stream |
|---|
| 音訊壓縮 | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
|---|
| 音訊取樣率 | 8 kHz/16 kHz |
|---|
| 環境噪音過濾 | Yes SSL/TLS, RTSP, TCP/IP, RTP, HTTP, QoS, PPPoE, ICMP, DDNS, UDP, UPnP, IGMP, DHCP, DNS, SNMP, IPv4, IPv6, FTP, HTTPS, 802.1X, NTP |
|---|
| 同時取流 | Up to 6 channels |
|---|
| API | ONVIF (Profile S, Profile G),ISAPI,SDK,ISUP Up to 32 users 3 user levels: administrator, operator, and user |
|---|
| 安全 | (EAP-MD5), WSSE and digest authentication for ONVIF,basic and digest authentication for HTTP/HTTPSF, RTP/RTSP over HTTPS, security audit log, control timeout settings |
|---|
| 客戶端 | iVMS-4200, Hik-Connect, Hik-Central |
|---|
| 瀏覽器 | Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+ Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
|---|
| 日夜模式 | Day,Night,Auto,Schedule |
|---|
| 寬動態 WDR | 120 dB |
|---|
| 影像增強 | BLC, HLC, 3D DNR |
|---|
| 隱私遮蔽 | 4 programmable polygon privacy masks |
|---|
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
|---|
| 網絡接口 | 1 RJ45 10 M/100 M self-adaptive Ethernet port Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB, *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interf |
|---|
| 警報 | 1 input, 1 output (max. 5 VDC, 0.1 A) Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),alarm input and output Line crossing detection, intrusion detection, region entrance detection, region exiting |
|---|
| 智能事件 | detection, unattended baggage detection, object removal detection,scene change detection, audio exception detection Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning 100 VAC to 240 VAC, 0.2 A, max. 7 W, |
|---|
| 供電 | three-core terminal block, PoE: IEEE 802.3af, Class 3, max. 7 W |
|---|
| 材質 | Anodized ADC12 |
|---|
| 尺寸 | 243.6 mm × 194.8 mm × 184 mm (9.6" × 7.7" × 7.2") |
|---|
| 包裝尺寸 | 430 mm × 250 mm × 275 mm (16.93" × 9.84" × 10.83") |
|---|
| 重量 | Approx. 3300 g (7.28 lb.) |
|---|
| 連包裝重量 | Approx. 4400 g (9.70 lb.) -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) 9 languages: English, Italian, French, Portuguese, Spanish, Russian, Japanese, Korean, Thai |
|---|
| 一般功能 | Heartbeat, mirror, flash log, password reset via e-mail, pixel counter, anti -banding |
|---|
| Cable Length | 1.3 m or 5 m (4.26 ft. or 16.40 ft.) CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, |
|---|
| EMC | RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1 |
|---|
| 防護等級 | IP68: IEC 60529-2013,IK10: IEC 62262:2002 ATEX: Ex II 2 G D Ex db IIC T6 Gb/Ex tb IIIC T80 °C Db IP68 IECEx: Ex db IIC T6 Gb/Ex tb IIIC T80 °C Db IP68 For explosive gas atmospheres, the maximum surface temperature is 85 °C; Explosion-Proof Protection For flammable dust atmospheres, the maximum surface temperature is 80 °C; IIC: for explosive gas atmospheres other than mines susceptible to firedamp |
|---|
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
|---|
