| 影像感測器 | 1/1.8" Progressive Scan CMOS Color: 0.003 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with 3840 × 2160 (only for captured pictures), 8 MP only for captured pictures, 4 MP maximum for video |
|---|
| 快門速度 | 1 s to 1/100,000 s |
|---|
| 日夜切換 | -I: IR cut filter, -L: 24/7 color imaging 2.8 mm, horizontal FOV 108.1°, vertical FOV 53.2°, diagonal FOV 132.7° 4 mm, horizontal FOV 87.6°°, vertical FOV 46.0°, diagonal FOV 103.5° |
|---|
| 光圈 | F1.6 |
|---|
| 鏡頭接口 | M12 2.8 mm: D: 97.4 m, O: 38.7 m, R: 19.5 m, I: 9.7 m 4 mm: D: 111.2 m, O: 44.1 m, R: 22.2 m, I: 11.1 m |
|---|
| 補光類型 | -I: IR, -L: White Light |
|---|
| 補光距離 | Up to 15 m |
|---|
| 紅外波長 | -I: 850 nm |
|---|
| 智能補光 | Yes 50 Hz: 12.5 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 15 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
|---|
| 視頻壓縮 | Main stream: H.265 |
|---|
| 視頻碼率 | 32 Kbps to 8 Mbps |
|---|
| H.265 類型 | Baseline Profile,Main Profile,High Profile |
|---|
| 碼率控制 | CBR,VBR |
|---|
| SVC 分級編碼 | H.265 |
|---|
| 環境噪音過濾 | Yes |
|---|
| 音訊取樣率 | 8 kHz/16 kHz/32 kHz/48 kHz |
|---|
| 音訊壓縮 | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
|---|
| Audio Type | Mono sound |
|---|
| 同時取流 | Up to 6 channels |
|---|
| API | ISAPI,SDK,ISUP TCP/IP, IPv6, DDNS, RTSP, HTTPS, HTTP, FTP, QoS, Bonjour, SNMP, WebSocket, WebSockets Up to 32 users 3 user levels: administrator, operator, and user |
|---|
| 網絡儲存 | Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
|---|
| 客戶端 | iVMS-4200,Hik-Connect Plug-in required live view: IE 10, IE 11, |
|---|
| 瀏覽器 | Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Safari 13+, Edge 89+ LTE-TDD Band 38/40/41 LTE-FDD Band 1/3/5/7/8/20/28 WCDMA Band 1/5/8 GSM 850/900/1800MHz |
|---|
| 標準 | LTE-TDD/LTE-FDD/WCDMA/GSM |
|---|
| 日夜模式 | Day,Night,Auto,Schedule |
|---|
| 寬動態 WDR | 120 dB |
|---|
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
|---|
| 影像增強 | BLC,HLC,Defog,3D DNR |
|---|
| 圖像參數切換 | Yes Saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser |
|---|
| 信噪比 SNR | ≥ 52 dB |
|---|
| Transducer Type | PIR |
|---|
| Detection Range | Up to 15 m 2.8 mm: Horizontal: 90° ± 5°, vertical: 25° ± 5°; 4 mm: Horizontal: 50° ± 5°, vertical: 20° ± 5° |
|---|
| Satellite Positioning Detection | Support GPS and searching longitude and latitude of the device |
|---|
| 內置麥克風 | 1 built-in microphone |
|---|
| 機身儲存 | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB 1 six-core 1.25 mm interface (it can be transferred as 1 12 VDC coaxial interface and 1 RJ 45 10 m/100 m self-adaptive Ethernet port) Yes, |
|---|
| 重設鍵 | Press to switch between performance mode and proactive mode. Hold the button for 10 sec to restore to defaults. |
|---|
| 基本事件 | Exception,PIR Alarm Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording |
|---|
| 供電 | 6 to 15 VDC, 1.03 to 0.73 A, max. 6.2 W Heartbeat,one-key reset,anti-banding,password protection,watermark, IP address filter |
|---|
| 材質 | Plastic |
|---|
