HIKVISION DS-3T3512P-H 網絡設備安裝・保養

Name: HIKVISION DS-3T3512P-H Industrial Full Managed PoE Switch
Brand: Hikvision
SKU: DS-3T3512P-H

產品簡介

Hikvision DS-3T3512P-H 為Industrial Full Managed PoE Switch，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DS-3T3512P-H 香港價格連安裝報價。

淨重：1.15 kg (2.54 lb)
毛重：1.45kg (3.2 lb)
尺寸：79 mm × 150 mm × 130 mm (0.259" ×0.492" × 0.427")
工作溫度：-40°C to 75°C (-40°F to 167°F)
儲存溫度：-40°C to 85°C (-40°F to 185°F)

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝WIFI、裝ROUTER、裝FIREWALL工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

DS-3T3512P-H Hikvision Industrial Full Managed PoE Switch 產品圖片

詳細規格

淨重	1.15 kg (2.54 lb)
毛重	1.45kg (3.2 lb)
尺寸	79 mm × 150 mm × 130 mm (0.259" ×0.492" × 0.427")
工作溫度	-40°C to 75°C (-40°F to 167°F)
儲存溫度	-40°C to 85°C (-40°F to 185°F)
工作濕度	5% to 95% (no condensation)
Storage Humidity	5% to 95% (no condensation) 52-57 V DC, 5A Redundant dual inputs
供電	48V~57V for PoE 52V~57V for PoE+
最大功耗	145W(PoE 125W)
機身	Metal material, IP40
MAC 位址表	8K 8 × Gigabit PoE port,2 × Gigabit fiber optical port,2 × 10G fiber optical port,2 × RS485 port Whole-Device Performance: 60 Gbps Port Performance: 60 Gbps Whole-Device Performance: 44.64 Mpps Port Performance: 44.64 Mpps
PoE 供電腳位	Ports 1 to 8: End-span: 1/2(+), 3/6(-) 4K VLAN Port-based VLAN Mac-based VLAN Protocol-based VLAN
VLAN	Based on the VLAN of the IP subnet QinQ, Flexible QinQ VLAN Mapping Voice VLAN MVRP Support STP/RSTP/MSTP Support EAPS/MEAPS Support MRD-Ring
Reliability	Support ERPS Support VRRP Support BFD for OSPF Support BFD for OSPF 802.1X Authentication/Centralized MAC Address Authentication Portal Authentication MAC address Authentication Guest VLAN RADIUS Authentication SSH 2.0 Port isolation Port security EAD
安全	DHCP Snooping, Prevent deception DHCP server Support dynamic ARP detection to prevent man-in-the-middle attacks and ARP denial of service. uRPF, Prevent IP source address spoofing to guard against viruses and attacks. IP/Port/MAC bind Support plaintext and MD5 ciphertext authentication for OSPF and RIPv2 messages. PKI(Public Key Infrastructure) Attack source tracing IP Source Guard DAI, ARP protec
Multicast	MVRP Multicast VLAN IGMP v1/v2/v3,MLD v1/v2 PIM-DM,PIM-SM,PIM-SSM MSDP,MSDP for IPv6 MBGP,MBGP for Ipv6 DHCP Client DHCP Snooping
DHCP	DHCP Relay DHCP Server DHCP Snooping option82/DHCP Relay option8 PMTU IPv6-Ping,IPv6-Tracert,IPv6-Telnet,IPv6-TFTP
IPv6	Tunnel 6to4 tunnel ISATAP tunnel GRE tunnel Support distributed device management, distributed link aggregation, distributed elastic routing. Support stacking through standard Ethernet interfaces Support local stacking and remote stacking Maximum stacking of 4 units
轉發方式	store-forward Automatic power down function for ports
Green Energy Saving	Port timing down function (Schedule job) EEE(802.3az) Standard for Energy Efficient Ethernet Support packet filtering functions from L2 (Layer 2) to L4 (Layer 4), providing traffic classification based on source MAC address, destination MAC address, source IP (IPv4/IPv6) address, destination IP (IPv4/IPv6) address, TCP/UDP port number, and VLAN. Time Range ACL Dual-directional ACL policy for inbou
Layer 2 Ring Network Protocol	BPDU Protection RRPP, ERPS, recovery time ≤ 30ms MRP(IEC62439-2), recovery time ≤ 20ms Static route RIPv1/v2, RIPng OSPFv1/v2, OSPFv3 BGP4, BGP4+ for IPv6
IP Routing	Support equal cost route, policy-based routing (PBR) VRRP/VRRPv3 BFD FOR VRRP BFD FOR IPv4 BFD FOR IPv6 OpenFlow 1.3 Supported multiple controllers (EQUAL mode, primary and standby mode)
OpenFlow	Supported multi-table pipelining Support Group table Support Meter Support for traffic mirroring Support for N:4 port mirroring Support for local and remote port mirroring Support for ERSPAN Support configuration via command line interface (CLI), Telnet, and console port. SNMPv1/v2/v3, WEB RMON (Remote Monitoring) Alarm, event, historical record iMC SmartMC Support syslog, hierarchical alarm, debu
Management and Maintenance	NTP Supported power alarm and temperature alarm Ping、Tracert VCT(Virtual Cable Test) DLDP LLDP Loopback-detection DDM(Digital Diagnostic Monitoring) Support GE port aggregation Support 10GE port aggregation
Port Aggregation	Support static aggregation Support dynamic aggregation Support cross-device aggregation Black hole mac-address MAC Address Table Port MAC address learning maximum number Support IEEE802.3x traffic control (full duplex) Support storm suppression based on port rate percentage Port Characteristics Support storm suppression based on PPS Support storm suppression based on bps Support for industrial pro
Jumbo Frame	Jumbo Frame
MFF	MFF(MAC-Forced Forwarding) CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3:
EMC	2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 28)
Safety	UL (UL 62368-1); CB (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2038)
Chemistry	CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2027) Key Component
Order Sap	Order Model Type Parameter AC/DC Power Supply, 240W, -30~70℃ AC/DC Power Supply, 75W , -30~70℃
No.	Indicator/ Port Description • Steady green: A link is present on the port. or sending data. • Off: No link is present on the port. • Steady green: Normal DC power input. • Off: Abnormal or no DC power input. • Steady green: Normal DC power input. • Off: Abnormal or no DC power input. • Steady green: Normal DC power input. • Off: Abnormal or no DC power input. • Steady green: The switch has started
Alarm input/output connection and	Provides DI/DO interfaces and two
RS485 ports	RS485 interfaces. Used to connect the power cable for providing DC power to the device The device supports dual DC inputs for 1+1 power redundancy. Used to connect the power cable for providing DC power to the device The device supports dual DC inputs for 1+1 power redundancy. USB2.0, 480 Mbps for uploading and downloading data • Provides connection to an ASCII terminal. • Provides connection to t
