| 工作濕度 | 95% or less (non-condensing) Bullet: 260.9 mm × 113.9 mm × 67.4 mm (10.3" × 4.5" × 2.7") Turret: Ø 124 mm × 119 mm (Ø 4.89" × 4.68") Bullet: 305 g (0.67 lb.) Turret: 290 g (0.6 lb.) |
|---|
| 焦距 | 2.8 mm Bullet: F1.6 Turret: F2.0 |
|---|
| 對焦 | Fixed Bullet: horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114° Turret: horizontal FOV 91.1°, vertical FOV 47.9°, diagonal FOV 110.8° Bullet: Up to 30 m Turret: White light distance: up to 15 m,IR distance: up to 20 m |
|---|
| 視頻壓縮 | H.265,H.264,MJPEG |
|---|
| H.264 類型 | Baseline Profile/Main Profile/High Profile |
|---|
| H.265 類型 | Main Profile |
|---|
| 視頻碼率 | 32 Kbps to 8 Mbps |
|---|
| 音訊壓縮 | G.711ulaw/AAC-LC |
|---|
| 音訊碼率 | 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC) |
|---|
| 音訊取樣率 | 8 kHz/16 kHz |
|---|
| 環境噪音過濾 | Yes |
|---|
| 最大解像度 | 4MP 50 Hz：25 fps （2560 × 1440 ，1920 × 1080 ，1280 × 720 ） 60 Hz：20 fps （2560 × 1440 ），24 fps （1920 × 1080 ，1280 × 720 ） 50 Hz: 25 fps (768 × 432) 60 Hz: 30 fps (768 × 432) Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
|---|
| 日夜模式 | Auto/Scheduled/Day/Night Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
|---|
| 網絡協議 | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv6, UDP, QoS, UPnP One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
|---|
| 通訊接口 | 1 RJ45 10M/100M self-adaptive Ethernet port |
|---|
| Reset Button | Yes |
|---|
| Camera Case Type | Bullet,Turret |
|---|
| 影像感測器 | 1/2.7" Progressive Scan CMOS Bullet：Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
|---|
| 最低照度 | Turret：Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0.005Lux @(F2.0, AGC ON), 0 Lux with |
|---|
| Day &Night | IR cut filter |
|---|
| WDR | DWDR Bullet: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° Turret: Pan: 0° to 350°,tilt: 0° to 75° Bullet：IP66 Turret：IP54 |
|---|
| 材質 | Plastic |
|---|
| Wi-Fi Support | Yes |
|---|
| IP 視頻輸入 | 4-ch |
|---|
| Incoming/Outgoing Bandwidth | 20 Mbps/20 Mbps |
|---|
| Video Resolution | 6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
|---|
| 同步回放 | 1-ch |
|---|
| 網絡接口 | 1, RJ45 10/100M Ethernet interface |
|---|
| Frequency Band | 2.4 GHz |
|---|
| Antenna Structure | High gain antenna |
|---|
| Transmission Speed | 150 Mbps |
|---|
| SD Card | 32G/64G/128G/256G/512G |
|---|
| 供電 | 12 VDC ≤ 6W |
|---|
| 工作溫度 | -10 °C to 55 °C (14 °F to 131 °F) |
|---|
| 尺寸 | 163 x 125 x 26 mm (6.4" × 4.9" × 1.0") |
|---|
| Weight (without hard disk) | ≤ 500g Kit Power cable: 2 × IPC power cables, 1 × NVS power cable Accessories Ethernet cable: RJ45, Cat5e UTP, 1 m |
|---|
| Certification | CB, CE |
|---|
| Weight (with package) | ≤ 2 kg (4.4 lb) |
|---|
