| 影像感測器 | 1/2.8" Progressive Scan CMOS |
|---|
| 最低照度 | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
|---|
| 最大解像度 | 1920 × 1080 |
|---|
| 快門速度 | 1/3 s to 1/100,000 s |
|---|
| 日夜切換 | IR cut filter |
|---|
| 鏡頭類型 | Fixed focal lens, 2.8 and 4 mm optional 2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89° |
|---|
| 光圈 | F1.6 |
|---|
| 光圈類型 | Fixed |
|---|
| 鏡頭接口 | M12 2.8 mm: 1.5 m to ∞ 4 mm: 2 m to ∞ 2.8 mm, D: 42 m, O: 17 m, R: 9 m, I: 4 m 4 mm, D: 52 m, O: 21 m, R: 11 m, I: 5 m |
|---|
| 補光類型 | IR |
|---|
| 補光距離 | Up to 30 m |
|---|
| 智能補光 | Yes |
|---|
| 紅外波長 | 850 nm 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) 50 Hz: 25 fps (768 × 432, 512 × 288) 60 Hz: 30 fps (768 × 432, 512 × 288) Main stream: H.264/H.265 Sub-stream: H.264/H.265 |
|---|
| 視頻碼率 | Up to 1 Mbps |
|---|
| H.264 類型 | Baseline Profile/Main Profile/High Profile |
|---|
| 音訊壓縮 | G.711/AAC-LC |
|---|
| 音訊碼率 | 64 Kbps (G.711)/16 to 64 Kbps (AAC-LC) |
|---|
| 音訊取樣率 | 8 kHz/16 kHz |
|---|
| 環境噪音過濾 | Yes TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS |
|---|
| 同時取流 | Up to 4 channels |
|---|
| API | ONVIF, SDK |
|---|
| 用戶管理 | administrator authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface |
|---|
| 客戶端 | iVMS-4200, HiLookVision, Hik-Partner-Pro |
|---|
| Wi-Fi Protocol | IEEE802.11b, IEEE802.11g, IEEE802.11n |
|---|
| Frequency Range | 2.412 GHz to 2.472 GHz |
|---|
| Channel Bandwidth | 20 MHz |
|---|
| Modulation | 802.11b: CCK, QPSK, BPSK, 802.11g: OFDM, 802.11n: OFDM |
|---|
| Transfer Rate | 11b: up to 54 Mbps, 11g: up to 54 Mbps, 11n: up to 150 Mbps Up to 120 m (The performance varies based on actual environment) |
|---|
| Antenna | 2 Antennas Saturation, brightness, contrast, sharpness adjustable by client software or web browser |
|---|
| 日夜模式 | Auto, Schedule, Day, Night |
|---|
| 寬動態 WDR | Digital WDR |
|---|
| 隱私遮蔽 | 4 programmable polygon privacy masks |
|---|
| 內置麥克風 | Yes, 1 built-in microphone |
|---|
| Built-in Speaker | Yes, 1 built-in speaker |
|---|
| 機身儲存 | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
|---|
| 重設鍵 | Yes |
|---|
| 網絡接口 | 1 RJ45 10 M/100 M self-adaptive Ethernet port Motion detection (support alarm triggering by specified target types (human and vehicle)), exception Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite Line crossing, intrusion, region entrance, region exiting Support alarm triggered by specified target types (human and vehicle) |
|---|
| 供電 | 12 VDC ± 10%, 1 A, max. 10 W, Ø 2 mm coaxial power plug, reverse polarity protection |
|---|
| 儲存環境 | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|---|
| 一般功能 | Heartbeat, mirror -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|---|
| 材質 | Base: metal, front cover: polycarbonate, back cover: polycarbonate |
|---|
| 尺寸 | 120 mm × 120 mm × 95 mm (4.7" × 4.7" × 3.7") |
|---|
| 包裝尺寸 | 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
|---|
| 重量 | Approx. 593 g (1.3 lb.) |
|---|
| 連包裝重量 | Approx. 886 g (1.95 lb.) CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)) CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014 CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU |
|---|
| 防護等級 | IP66: IEC 60529-2013 |
|---|
