HILOOK IPC-D660HA-LZU 安裝、保養、維修

Name: HILOOK IPC-D660HA-LZU 6MP電動變焦紅外半球網絡攝影機
Brand: HiLook
SKU: IPC-D660HA-LZU

產品簡介

HiLook IPC-D660HA-LZU 為6MP電動變焦紅外半球網絡攝影機，配備2.8-12mm電動變焦鏡頭，適合需要更高畫質同遠距離拉近嘅停車場、大範圍空地等場景。6MP解像度令細節更清晰，紅外同白光雙補光切換，內置咪高峰收音。HKEZIT提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務，歡迎查詢 IPC-D660HA-LZU 香港價格連安裝報價。

6MP超高清畫質：2.8-12mm電動變焦鏡頭，遠近範圍任你拉近
30米紅外+白光雙補光：夜晚黑白紅外或全彩模式任切換
120dB寬動態(WDR)：逆光位置一樣清晰
支援人車分類偵測：減少誤報，警報更精準
內置咪高峰：畫面聲音同步紀錄
支援microSD卡最大512GB：斷網都可以本地儲存

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

詳細規格

影像感測器	1/2.4" Progressive Scan CMOS
最大解像度	3200 × 1800
最低照度	Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
快門速度	1/3 s to 1/100,000 s
日夜切換	IR cut filter
角度調節	Pan: 0° to 355°,tilt: 0° to 70°,rotate: 0° to 355°
鏡頭類型	Varifocal lens, motorized lens, 2.8 to 12 mm 2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to 20°, diagonal FOV 127.4° to 40.8°
鏡頭接口	Ø 14
光圈類型	Fixed
光圈	F1.6
DORI 偵測距離	D: 68 to 200 m, O: 27 to 79 m, R: 13.6 to 40 m, I: 6.8 to 20 m
補光類型	IR,White Light
補光距離	Up to 30 m
智能補光	Yes
紅外波長	850 nm 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
視頻碼率	32 Kbps to 16 Mbps
H.264 類型	Baseline Profile,Main Profile,High Profile
H.265 類型	Main Profile
感興趣區域 ROI	1 fixed region for main stream
碼率控制	CBR,VBR
SVC 分級編碼	H.264 and H.265 encoding
Audio Type	Mono sound
音訊壓縮	G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
音訊取樣率	8 kHz/16 kHz
環境噪音過濾	Yes TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
同時取流	Up to 6 channels
API	Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK Up to 32 users 3 user levels: administrator, operator, and user
客戶端	iVMS-4200,HiLookVision Password protection, complicated password, watermark, basic and digest
安全	authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
日夜模式	Day,Night,Auto,Schedule
寬動態 WDR	120 dB
影像增強	BLC,HLC,3D DNR
信噪比 SNR	≥ 52 dB
隱私遮蔽	4 programmable polygon privacy masks
網絡接口	1 RJ45 10 M/100 M self-adaptive Ethernet port Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
重設鍵	Yes
內置麥克風	Yes Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Upload to FTP/memory card,notify surveillance center,send email,trigger recording,trigger capture 12 VDC ± 25%, 0.8 A, max. 9.6 W,Ø 5.5 mm coaxial power plug,reverse polari ty protection,PoE: IEEE 802.3af, Class 3, max. 12 W
材質	Metal & Plastic
