| Standard Operating Temperature | -40°F to 151°F (-40°C to 66°C) |
|---|
| Humidity Range | 10 to 93% non-condensing (indoor products) |
|---|
| Nominal Voltage | Regulated 120 VAC |
|---|
| Operating Voltage Range | 96–132 VAC |
|---|
| Current Draw From AC Line | 150 mA max. L-Series Bezels The System Sensor L-Series bezels are for installation with strobes, horns, chimes, horn strobes, chime strobes, and speaker strobes. Bezels are offered in red and white for both wall and ceiling devices. Lettering choices: FIRE, ALERT, EVAC, AGENT, FEU, FOGO, FUEGO, FUEGO/FIRE, and Plain (no marking). Operating temperature shall be -40°F to 151°F (-40°C to 66°C). |
|---|
| Installation to Wall-Mount Strobe | Installation to Ceiling-Mount Strobe AVDS882-03 • 10/02/2020 • Page 3 |
|---|
| Part No. | Description Part No. Description |
|---|
| Surface Mount Back Box | Colored Lenses |
|---|
| SBBRL | Red, wall-mount, compatible with horns, strobes, LENS-B2 Wall-mount, blue |
|---|
| horn strobes, chimes and chime strobes | LENS-R2 Wall-mount, red |
|---|
| SBBWL | White, wall-mount, compatible with horns, strobes, LENS-G2 Wall-mount, green horn strobes, chimes and chime strobes |
|---|
| LENS-A2 | Wall-mount, amber |
|---|
| SBBSPRL | Red, wall-mount, compatible with speakers and |
|---|
| speaker strobes | LENS-BC2 Ceiling-mount, blue |
|---|
| SBBSPWL | White, wall-mount, compatible with speakers and LENS-RC2 Ceiling-mount, red |
|---|
| SBBCRL | Red, ceiling-mount compatible with horns, strobe, LENS-AC2 Ceiling-mount, amber horn strobes, chimes, chime strobes, speakers and Retrofit Plates speaker strobes (For use with horn strobe & speaker strobe devices) |
|---|
| SBBCWL | White, ceiling-mount, compatible with horns, strobe, |
|---|
| RFPW | 9.5" x 7" (24.13 cm x 17.78 cm) white horn strobes, chimes, chime strobes, speakers and |
|---|
| SBBGRL | Red, wall-mount, compatible with compact horns, Mounting Plate |
|---|
| strobes, horn strobes | MP120KLA 120 VAC Adapter Mounting Plate |
|---|
| SBBGWL | White, wall-mount, compatible with compact horns, Sync Modules strobes, horn strobes |
|---|
| MDL3WA | White, 12/24 volt Sync-Circuit module |
|---|
| MDL3RA | Red, 12/24 volt Sync-Circuit module |
|---|
| BZR | Wall Red Bezel Kit Trim Rings |
|---|
| BZW | Wall White Bezel Kit |
|---|
| TR-2 | Universal wall trim ring, red, 6.3” x 8.2” (16 cm x |
|---|
| BZGR | Compact Wall Red Bezel Kit 20.83 cm) (5-pack) |
|---|
| BZGW | Compact Wall White Bezel Kit TRC-2 Universal ceiling trim ring, red, diameter 8.5” |
|---|
| BZRC | Horn Strobe Ceiling Red Bezel Kit (21.59 cm) (5-pack) |
|---|
| BZWC | Horn Strobe Ceiling White Bezel Kit TR-2W Universal wall trim ring, white, 6.3” x 8.2” (16 cm x 20.83 cm) (5-pack) |
|---|
| BZSPR | Speaker Strobe Wall Red Bezel Kit |
|---|
| TRC-2W | Universal ceiling trim ring, white, diameter 8.5” |
|---|
| BZSPW | Speaker Strobe Wall White Bezel Kit (21.59 cm) (5-pack) |
|---|
| BZSPRC | Speaker Strobe and Low-Frequency Ceiling Red |
|---|
| TRCWLA-10 | Ceiling trim ring, white, diameter 7.0” (17.78 cm) Bezel Kit (10-pack) |
|---|
| BZSPWC | Speaker Strobe and Low-Frequency Ceiling White |
|---|
| TCRLA-10 | Ceiling trim ring, red, diameter 7.0” (17.78 cm) Bezel Kit (10-pack) 3333 Unity Drive, Mississauga, ON L5L 3S6x ©2020 System Sensor. |
|---|
| Phone: 800-SENSOR2 • Fax: 905-812-0771 | Product specifications subject to change without notice. Visit systemsensor.ca for current product information, including the latest version of this data sheet. |
|---|
| www.systemsensor.ca | AVDS882-03 • 10/02/2020 |
|---|
