HONEYWELL DOC-02-200 防盜報警安裝・保養

Name: HONEYWELL DOC-02-200 Visual Alarm Devices (VAD)
Brand: honeywell
SKU: DOC-02-200

產品簡介

honeywell DOC-02-200 為Visual Alarm Devices (VAD)，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DOC-02-200 香港價格連安裝報價。

Excellent System Performance：Faster Installation • High efficiency piezo disk and horn pr
generate excellent sound output：• Rear or surface cable entry
• High output LED technology and superior：• Loop continuity spring lens design optimize light output •
• Positive “poke yoke” engagement：• Low current draw enables more devices on
• Address tag for clear indication：loop

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝ALARM、裝防盜、裝警鐘工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

DOC-02-200 honeywell Visual Alarm Devices (VAD) 產品圖片

詳細規格

Excellent System Performance	Faster Installation • High efficiency piezo disk and horn profile • Large cable access
generate excellent sound output	• Rear or surface cable entry
• High output LED technology and superior	• Loop continuity spring lens design optimize light output • Automatic synchronisation of sounder and beacon Reduced Install Error & Easy Fault Finding Flexible Installation
• Positive “poke yoke” engagement	• Low current draw enables more devices on
• Address tag for clear indication	loop
• Anti-tamper feature	• Adjustable volume control (on device or from panel) • In-built loop isolator • Intense beacon output • Simple familiar rotary wheel address controls • Deep and high IP base options • A variety of body and lens colours
Reduced Full Life Costs	Reduced Inventory Count • High quality robust materials for longer life • CLIP Protocol • UV stable materials • Global 32 tone set (selectable from device or • Robust construction for added impact from panel) resistance
SUPPLY VOLTAGE	15 - 29 VDC (Isolation)
STANDBY CURRENT	120 μA (Non-Isolation) 225 μA (Isolation)
MAXIMUM CURRENT CONSUMPTION	14.5 mA (High Volume Tone 11 @15V) SOUNDER AND BEACON 97dB(A) +/-3dB @1metre (High Volume, Tone 8 @24V) MAXIMUM SOUND OUTPUT [Tone Dependant - Figure stated is based on high volume 970Hz continuous @24VDC]
BEACON FLASH RATE	1 Hz
MAXIMUM DEVICES PER LOOP	27
工作溫度	-25 °C to +70 °C
相對濕度	Up to 95% non condensing IP21C (with low profile base)
防護等級	IP44 (with surface mount base) IP65 (Waterproof base)
BODY COLOUR	Pure White
LENS COLOUR	Clear*
FLASH COLOUR	Red
WEIGHT NET/ GROSS	238 g
CABLE TERMINAL SIZE	0.5-2.5 mm 2 max
NUMBER OF TONES	32
VOLUME SETTING	High, Medium, Low
MOUNTING OPTIONS	Low Profile, Surface or High IP * Alternate lens colours might be available on demand, only devices with clear lens colour are approved to AS ISO 7240.23. Wiring and Dimension Ordering Notifier CLIP pure white Sounder Beacon red flash, clear lens, with WSS-PC-I02 Isolator
B501-AP	AV-device base, pure white for Intelligent range
WPW	Waterproof AV-device base, pure white for Intelligent range Agency Listings and Approvals The listings and approvals below apply to the devices specified in this document. In some cases, certain devices or applications may not be listed by certain approval agencies, or listing may be in process. Consult NOTIFIER for latest listing status. • AS ISO 7240.3:2014 • AS ISO 7240.23:2014; SAI Global cert
www.notifier.co.nz	ISO9001 FS 520324
© 2020 Honeywell International Inc.	DOC-02-200 / 09/20 \| Rev B ENGINEERING & MANUFACTURING QUALITY SYSTEMS
