| NetVR 120 | NetVR 125 Video Management |
|---|
| IP Camera Streams | Up to 64 Up to 64 |
|---|
| IP Camera Resolution | IP camera dependent IP camera dependent |
|---|
| IP Camera Frame Rate | IP camera dependent IP camera dependent |
|---|
| Compression Type | H.264 or H.265 H.264 or H.265 (camera dependent) (camera dependent) Appliance |
|---|
| Video Storage | 48TB maximum capacity using 4TB, 8TB or 48TB maximum capacity using 4TB, 8TB, or 12TB removable 3.5in drives; 4 HDD slots 12TB hot swappable 3.5in drives; 4 HDD slots |
|---|
| Storage Configuration | JBOD RAID 5; optional hot spare |
|---|
| 處理器 | Intel® Xeon® E Intel® Xeon® E |
|---|
| Memory (RAM) | 8GB 8GB |
|---|
| 操作系統 | Ubuntu Linux Ubuntu Linux |
|---|
| OS/Application Storage | 240GB SSD 240GB SSD |
|---|
| Ethernet Ports | 2 2 |
|---|
| Max Video Throughput | 400 Mbps 400 Mbps (Aggregate Inbound) |
|---|
| MTBF | 51,700 hours 45,600 hours |
|---|
| Chassis | Standard 1U rack mount, Standard 1U rack mount, |
|---|
| Appliance (continued) | rail kit included rail kit included |
|---|
| Dimensions (H, W, D) | 1.68in x 19.0in x 21.9in 1.68in x 19.0in x 21.9in (43mm x 482mm x 556mm) (43mm x 482mm x 556mm) |
|---|
| 重量 | 30 lbs (13.6 kg) maximum 30 lbs (13.6 kg) maximum |
|---|
| 工作溫度 | 50° – 95°F (10° – 35°C) 50° – 95°F (10° – 35°C) |
|---|
| 儲存溫度 | -40° – 149°F (-40° – 65°C) -40° – 149°F (-40° – 65°C) |
|---|
| Operating Environment | Humidity 80%, Humidity 80%, |
|---|
| non-condensing 84°F (29°C) | non-condensing 84°F (29°C) |
|---|
| AC Input | 100 – 240 VAC, 50/60 Hz, 5A/3A 100 – 240 VAC, 50/60 Hz, 5A/3A |
|---|
| BTU Maximum | 1,356 per hour 1,356 per hour |
|---|
| Regulatory Approvals | UL, CE, FCC, RoHS UL, CE, FCC, RoHS |
|---|
| Warranty | 3 years, hardware; 3 years, hardware; 1 year, software 1 year, software Client Requirements |
|---|
| Windows 10 (64 bit), macOS High Sierra | Windows 10 (64 bit), macOS High Sierra Operating System |
|---|
| and later | and later |
|---|
| Hard Drive | 100GB minimum 100GB minimum Part Numbers |
|---|
| S2-NETVR120-G2: NetVR 120 appliance | S2-NETVR125-G2: NetVR 125 appliance |
|---|
| S2-NETVR-1C: Single IP camera license, | S2-NETVR-1C: Single IP camera license, |
|---|
| expandable up to 64 IP cameras | expandable up to 64 IP cameras |
|---|
| S2-4TB-HDD-G2: 4TB storage hard drive | S2-4TB-HDD-G2: 4TB storage hard drive |
|---|
| S2-8TB-HDD-G2: 8TB storage hard drive | S2-8TB-HDD-G2: 8TB storage hard drive |
|---|
| S2-12TB-HDD-G2: 12TB storage hard drive | S2-12TB-HDD-G2: 12TB storage hard drive S2-RAID5: RAID 5 configuration for video management server S2-NETVR-RAID-HS: Hot spare configuration |
|---|
| Remote | Internet/ Web Brow serr VPN LenelS2TM Mo bile Apps Magic Monitor® NetBoxTM Gl obal |
|---|
| Node | WAN |
|---|
| LenelS2 | NetVRTM |
|---|
| Mobile | 100 Ser |
|---|
| Apps | ies Local |
|---|
| Web Brow | Magic ser Monitor LAN Node NetBox NetVR 10 0 Series Schematic only. Not a network diagram. |
|---|
