| plan graphics. | n IP Video Server: Delivers real-time and recorded video to client |
|---|
| n | Access Control Integration: Integrates with NetBox access real-time monitoring displays, with single or multi-camera views |
|---|
| Remote | Internet/ Web Brow serr VPN LenelS2TM Mo bile Apps Magic Monitor® NetBoxTM Gl obal Networ |
|---|
| k Node | WAN |
|---|
| LenelS2 | VRxTM 25 |
|---|
| Mobile | 0 Apps Local |
|---|
| Web Brow | Magic ser Monitor LAN Networ k Node NetBox VRx 250 Schematic only. Not a network diagram. |
|---|
| Video Management | Appliance (continued) |
|---|
| IP Camera Streams | Up to 16 Weight 12 lbs (5.4 kg) maximum |
|---|
| IP Camera Resolution | Camera dependent, up to 4K Operating Temperature 50° – 95°F (10° – 35°C) |
|---|
| IP Camera Frame Rate | Camera dependent Storage Temperature -40° – 158°F (-40° – 70°C) |
|---|
| Compression Type | H.264 or H.265 Operating Environment Humidity 85%, (camera dependent) non-condensing 35°C |
|---|
| Appliance | AC Input 100 – 240 VAC, 50/60 Hz, 6A/3A |
|---|
| Video Storage | 2TB or 4TB HDD |
|---|
| Storage Configuration | JBOD BTU Maximum 938 per hour |
|---|
| 處理器 | Intel Core i3 |
|---|
| ® | TM Regulatory Approvals UL, CE, FCC, RoHS |
|---|
| Memory (RAM) | 8GB Warranty 3 years, hardware; 3 years, software |
|---|
| 操作系統 | Ubuntu Linux |
|---|
| OS/Application Storage | 80GB SSD minimum Client Requirements |
|---|
| Ethernet Ports | 2 Operating System Windows 10 (64 bit), macOS High Sierra and later |
|---|
| Max Video Throughput | 100 Mbps (Aggregate Inbound + Processor Intel Core i3 or higher |
|---|
| Outbound) | Memory (RAM) 4GB minimum |
|---|
| MTBF | 107,071 hours Hard Drive 100GB minimum |
|---|
| Chassis | Standard 2U rack mount Part Numbers Surface mount |
|---|
| S2-VRX250-2TB | IP camera licenses expandable |
|---|
| Dimensions (H, W, D) | 3.5in x 19.0in x 14.58in up to 8 IP cameras; 2TB HDD (89mm x 483mm x 370mm) |
|---|
| S2-VRX250-4TB | IP camera licenses expandable up to 16 IP cameras; 4TB HDD |
|---|
| S2-VRX-1C | Single camera license |
|---|
