| 類型 | Left pedestal Middle pedestal Right pedestal |
|---|
| Motor | Brushless DC motor 16 pairs of infrared sensors: 8 pairs on the upper level, 6 pairs on the lower level, and 2 pairs on the support columns. |
|---|
| Steel plate thickness | Chassis: 1.2 mm, cover: 1.5 mm thick, 304 brushed stainless steel |
|---|
| Card reader panel | Exit Direction Bi-directional Entrance Direction |
|---|
| 功耗 | Standby: approx. 35 W, Normal operation: approx. 45 W, Maximum: approx. 136 W |
|---|
| Ambient temperature | -40°C to 60°C（A heating module is required below -20 °C.） |
|---|
| 工作濕度 | 5% to 80% |
|---|
| Operating voltage | 100V to 240AC input; 24 V DC/17 A output Standard installation hole(s) for smart recognition terminal and decorative cover: one on each side pedestal, two on each middle pedestal |
|---|
| 材質 | Acrylic or stainless steel |
|---|
| Compatible lane width | Acrylic: 650 mm to 1050 mm(Customization for a width of 1050 mm is supported.) Stainless steel: 650 mm to 1050 mm (Customization for a width of 1050 mm is supported.) |
|---|
| 重量 | 54KG 58.3KG 56.2KG |
|---|
| Operating environment | Indoor, outdoor |
|---|
| 尺寸 | 1506.9 x 970 x 190 mm |
|---|
| 供電 | 24V RS485 x 1, alarm input x 1, alarm output x 3, fire alarm interface x 1, IO port x 2, remote controller interface × 2 |
|---|
| 卡容量 | Duress card: 1,000 Other types of cards: 100 |
|---|
| 記錄容量 | 200,000 |
|---|
| Communication | Wired communication, Wi-Fi communication |
|---|
| Permission groups | 16 |
|---|
| Time templates | 256 |
|---|
| Holiday templates | 256 |
|---|
| Anti-passback | Single-lane anti-passback, multi-lane cross-controller anti-passback |
|---|
| Custom audio | Supports custom modification of default audio Supports abnormal cover opening alarm LAN x 2, RS485 × 2, USB × 2, alarm output x 4, exit button input × 2, fire alarm input × 2; Wiegand × |
|---|
| Anti-pinch | IR anti-pinch, electric current anti-pinch 5CM tailgating detection |
|---|
| Anti-reverse passing | Reverse intrusion detection |
|---|
| Power-off State | Fail-safe (automatically unlocks and opens upon power loss) |
|---|
| Alarm event | Sound and light alarm |
|---|
| OEP-YP65 | OEP-YP75 OEP-YP85 |
|---|
| OEP-YP95 | OEP-YP110 OEP-YS65 |
|---|
| OEP-YS75 | OEP-YS85 OEP-YS95 |
|---|
| OEP-YS110 | OEP-YS120 OEP-YS130 OEP-YS140 Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
