| reliability and range. | Dimensions/weight (unit, excluding mount accessories): |
|---|
| • Supported data rates (Mbps): | • 15 cm (W) x 22.2 cm (D) x 7.5 cm (H) |
|---|
| - 802.11b: 1, 2, 5.5, 11 | 6” (W) x 8.5” (L) x 2.5” (H) |
|---|
| - 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 | • 1.225 kg/2.7 lbs - 802.11n (2.4GHz): 6.5 to 300 (MCS0 to MCS15) - 802.11n (5GHz): 6.5 to 600 (MCS0 to MCS31) - 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4 for VHT20/40/80, NSS = 1 to 2 for VHT160) VHT 20/40/80/160 ARUBA 318 SERIES RUGGEDIZED ACCESS POINTS |
|---|
| ENVIRONMENTAL | CERTIFICATIONS |
|---|
| • Operating Temperature: | • CB Scheme Safety, cTUVus - Temperature: -40° C to +60° C (-40° F to +140° F) • UL2043 plenum rating |
|---|
| - Humidity: 5% to 95% non-condensing | • Wi-Fi Alliance certified 802.11a/b/g/n |
|---|
| • Storage and transportation: | • WPA, WPA2 and WPA3 – Enterprise with CNSA option, - Temperature: -40° C to +70° C (-40° F to +158° F) Personal (SAE), Enhanced Open (OWE) |
|---|
| • Operating Altitude: 3,000 m | • Wi-Fi CERTIFIED™ ac (with Wave 2 features) • Water and Dust |
|---|
| - IP55 | WARRANTY • Limited lifetime warranty |
|---|
| • FCC/ISED | MINIMUM OPERATING SYSTEM SOFTWARE |
|---|
| • CE Marked | • ArubaOS & Aruba InstantOS 8.3.0.0 |
|---|
| • RED Directive 2014/53/EU | • ArubaOS 10.0.0.0 • EMC Directive 2014/30/EU • Low Voltage Directive 2014/35/EU • UL/IEC/EN 60950 • EN 60601-1-1, EN60601-1-2 • EN 50121-1 • EN 50121-3-2 • EN 50121-4 • EN-50155 • APIN0318 ARUBA 318 SERIES RUGGEDIZED ACCESS POINTS RF PERFORMANCE TABLE |
|---|
| Maximum transmit power (dBm) | Receiver sensitivity (dBm) |
|---|
| per transmit chain | per receive chain 802.11b 2.4 GHz 1 Mbps 22 -95 2 Mbps 22 -93 5.5 Mbps 22 -90 11 Mbps 22 -88 802.11g 2.4 GHz and 802.11a 5 GHz 2.4 GHz and 802.11a 5 GHz 6 Mbps 22 -93 54 Mbps 19 -75 802.11n HT20 2.4 GHz and 5 GHz |
|---|
| MCS0/8 | 22 -93 |
|---|
| MCS7/15 | 18 -71 802.11n HT40 2.4 GHz and 5 GHz |
|---|
| MCS0 | 22 -93 |
|---|
| MCS9 | 16 -68 802.11ac VHT40 5 GHz |
|---|
| Part Number | Description Aruba 318 Unified Hardened Access Points |
|---|
| JZ152A | Aruba AP-318 (RW) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ153A | Aruba AP-318 (US) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ149A | Aruba AP-318 (EG) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ150A | Aruba AP-318 (IL) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ151A | Aruba AP-318 (JP) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP Aruba 318 Unified Hardened Access Points TAA |
|---|
| JZ157A | Aruba AP-318 (RW) TAA 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ158A | Aruba AP-318 (US) TAA 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ154A | Aruba AP-318 (EG) TAA 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ155A | Aruba AP-318 (IL) TAA 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP |
|---|
| JZ156A | Aruba AP-318 (JP) TAA 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xRPSMA Connectors Indoor Hardened AP © Copyright 2023 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herei |
|---|
