| Camera | BLC Mode BLC / HLC / WDR |
|---|
| 影像感測器 | Three 1/2.8" 2MP STARVISTM CMOS WDR 120dB |
|---|
| Effective Pixels(Panorama) | 4K(3840x832)/4M(2560x554) Gain Control AGC |
|---|
| Scanning System | Progressive Noise Reduction 2D/3D |
|---|
| PAL:1/4s~1/100,000s | White Balance Auto / Manual Electronic Shutter Speed NTSC:1/3s~1/100,000s |
|---|
| Smart IR | Auto / Manual |
|---|
| Minimum Illumination | 0.005Lux/F1.8( Color), 30IRE,0Lux/F1.8(IR on) |
|---|
| S/N Ratio | More than 65dB Certifications CE (EN55032, EN55024, EN50130-4) |
|---|
| IR Distance | 20m |
|---|
| Certifications | FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|---|
| IR On/Off Control | Auto (ICR)/Color/B/W |
|---|
| IR LEDs | 6 |
|---|
| Alarm I/O | 2/1 |
|---|
| 鏡頭類型 | Fixed lens / Fixed iris Audio Interface 1-channel audio in(JACK) |
|---|
| Mount Type | Board-in |
|---|
| Test interface | 1-channel 2-pin CVBS video output |
|---|
| 焦距 | 3.6mm |
|---|
| Upgrade Interface | 1-channel 4-pin USB input |
|---|
| Max Aperture | F1.8 1 physical code switch(switch the preset video Code switcher |
|---|
| Angle of View | H: 180° source) |
|---|
| Focus Control | N/A Menu set 1 Five-direction button 500mm Close Focus Distance 19.7'' Eelectrical |
|---|
| 供電 | 12V DC ±25% DORI Distance |
|---|
| 功耗 | 22W Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the Environmental criteria for Detect, Observe, Recognize and Identify respectively. -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH Operating Condi |
|---|
| Definition | Storage Conditions -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH Ingress Protection & Vandal |
|---|
| Detect | 25px/m (8px/ft) 50m(163ft) IP67&IK10 Resistance |
|---|
| Observe | 63px/m (19px/ft) 20m(65ft) Construction |
|---|
| Casing | Aluminium |
|---|
| Recognize | 125px/m (38px/ft) 10m(33ft) |
|---|
| 尺寸 | 286mm x 119mmx 106mm(11.26"×4.68"×4.19") |
|---|
| Identify | 250px/m (76px/ft) 5m(16ft) |
|---|
| 淨重 | 2.05kg (4.5lb) |
|---|
| Pan / Tilt / Rotation | Gross Weight 2.43kg (5.36lb) Pan: 0° ~ 360° |
|---|
| Pan/Tilt/Rotation | Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
|---|
| 解像度 | 4K (3840X2160)/4MP(2560×1440) PAL:3840×2160@12.5fps,2560x1440@25fps; Frame Rate NTSC:3840×2160@15fps,2560x1440@25fps; 1-channel BNC HDCVI panoramic video output & Video Output 3-channels BNC 2MP HDCVI video output |
|---|
| Day/Night | Auto (Electronic) / Manual www.dahuasecurity.com |
|---|
| Ordering Information | Juncon Mount Pole Mount |
|---|
| PFA124-B | PFA124-B + PFA150 |
|---|
| 類型 | Part Number Description 4K multi-sensor Panoramic HDCVI DH-HAC-PFW3601P-A180 IR-Bullet Camera, PAL 8MP Camera 4K multi-sensor Panoramic HDCVI DH-HAC-PFW3601N-A180 IR-Bullet Camera, NTSC |
|---|
| PFA150 | Pole mount bracket |
|---|
| Accessories | PFA151 Coner mount bracket PFA124-B + PFA151 |
|---|
| PFM800-E | 1 Channel Passive HDCVI Balun |
|---|
| PFM320 | 12V 2A Power Adapter Dimensions (mm/inch) Optional: PFA124-B Dimensions (mm/inch) |
|---|
| Pole mount | Water-proof junction box Coner mount bracket |
|---|
| Passive HDCVI Balun | 12V 2A Power Adapter |
|---|
| Rev 001.001 | © 2017 Dahua®. All rights reserved. www.dahuasecurity.com |
|---|
