| System | Interoperability ONVIF 16.12, CGI Conformant |
|---|
| Main Processor | Embedded processor Video Detection and Alarm |
|---|
| 操作系統 | Embedded linux Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Trigger Events Buzzer and Screen Tips |
|---|
| SMD Plus | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Video Detection Tampering and Diagnosis |
|---|
| Performance | 8 channels |
|---|
| 警報輸入 | N/A |
|---|
| AI Search | Search by target classification (Human, Vehicle) |
|---|
| Relay Output | N/A Playback and Backup |
|---|
| Analog Camera Input | 16 channels, BNC |
|---|
| Playback | 1/4/9/16 |
|---|
| HDCVI Camera | 1080p@ 25/30 fps, 720p@ 25/30 fps Time/Date, Alarm, MD and Exact Search (accurate to Search Mode second) |
|---|
| AHD Camera | 1080p@ 25/30 fps, 720p@25/30 fps Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; |
|---|
| TVI Camera | 1080p@25/30 fps, 720p@25/30fps Playback Function Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
|---|
| CVBS Camera | PAL/NTSC |
|---|
| Backup Mode | USB Device/Network |
|---|
| IP Camera Input | 16+2/16 channels, each channel up to 6MP Storage |
|---|
| Audio In/Out | 1/1, RCA |
|---|
| Internal HDD | 2 SATA ports, up to 10 TB capacity |
|---|
| Two-way Talk | Reuse audio in/out, RCA |
|---|
| eSATA | N/A |
|---|
| 視頻壓縮 | AI Coding/H.265+/H.265/H.264+/H.264 |
|---|
| USB | 2 USB ports (USB 2.0) |
|---|
| 解像度 | 1080N; 720p; 960H; D1; CIF |
|---|
| RS232 | N/A Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others RS485 1 port, for PTZ control |
|---|
| Record Rate | 1080N/720p (1 fps–15 fps); 960H/D1/CIF (1 fps–25/30 fps) |
|---|
| Sub steram: | Electrical CIF(1 fps–7 fps) |
|---|
| 供電 | DC 12V/4A |
|---|
| Bit Rate | 32 kbps–4096 kbps per channel Power Consumption Manual; Schedule (General, Continuous); MD (Video < 10W (without HDD) |
|---|
| Record Mode | detection: Motion Detection, Video Loss, Tampering); Alarm; Stop Construction 1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, |
|---|
| Record Interval | 1U, 375.0 mm × 289.4 mm × 53.0 mm |
|---|
| Post-record: 10 sec–300 sec | Dimensions (14.76" × 11.39" × 2.09") |
|---|
| 音訊壓縮 | G.711A, G.711U, PCM Net Weight 1.61 kg (3.55 lb) (without HDD) |
|---|
| Audio Sample Rate | 8 KHz, 16 bit per channel |
|---|
| 毛重 | 2.86 kg(6.30 lb) |
|---|
| 音訊碼率 | 64 kbps per channel |
|---|
| 安裝 | Desktop installation Environmental |
|---|
| 接口 | 1 HDMI; 1 VGA |
|---|
| Operating Conditions | -10°C to +55°C (+14°F to +131°F), 10%–90% (RH) |
|---|
| 儲存環境 | -20°C to +70°C (-4°F to +158°F) , 0%–90% (RH) When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16 Third-party Support Camera title; Time; Video loss; Camera lock; Motion Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP |
|---|
| detection; Recording | Third-party Support Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more Certifications |
|---|
| DVR, NVS, etc.) | EN 55024 |
|---|
| Max. User Access | 128 users UL: UL 60950-1 www.dahuasecurity.com |
|---|
| Ordering Information | Panels |
|---|
| 類型 | Part Number Description 1 3 10 11 16 Channel 16 Channel Penta-brid 720p 1U DH-XVR4216AN-I |
|---|
| WizSense XVR | WizSense Digital Video Recorder Dimensions (mm[inch]) <> 2 4 5 6 7 89 1 Ground 2 Video In 3 Audio In 4 Audio Out <> 5 HDMI Port 6 USB Port 7 Network Port 8 RS–485 Port 9 DC 12V Power Input 10 VGA Port 11 Power Switch <> <> Installation Standard Cabinet 1U Device Rack Mount Tray |
|---|
| Rev 001.001 | © 2021 Dahua. All rights reserved. Design and specifications are subject to change without notice. Pictures in the document are for reference only, and the actual product shall prevail. www.dahuasecurity.com |
|---|
