| Camera | IVS Tripwire, Intrusion, Abandoned/Missing |
|---|
| 影像感測器 | 1/1.8" CMOS Advanced Intelligent Functions Face Detection, Heat Map |
|---|
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels Video |
|---|
| RAM/ROM | 1024M/64M Compression H.264 / MJPEG |
|---|
| Scanning System | Progressive Streaming Capability 3 Streams |
|---|
| Electronic Shutter Speed | 1/1s~1/30,000s 1080P(1920×1080)/720P(1280×720)/D1(704×576/ Resolution 704×480)/CIF(352×288/352×240) Color: 0.002Lux@F1.5; B/W: 0.0002Lux@F1.5; Minimum Illumination 0Lux@F1.5 (IR on) Main stream: 1080P(1~25/30fps), 720P(1~50/60fps) |
|---|
| IR Distance | Distance up to 500m (1640ft) |
|---|
| Frame Rate | Sub stream1: D1/CIF(1 ~ 25/30fps) |
|---|
| IR On/Off Control | Auto/Manual Sub stream2: 1080P/720P/D1/CIF (1 ~ 25/30fps) |
|---|
| IR LEDs | Laser module |
|---|
| 碼率控制 | CBR/VBR |
|---|
| Wiper | Support |
|---|
| Bit Rate | H.264: 448K~8192Kbps, MJPEG: 4096K~20480Kbps |
|---|
| Day/Night | Auto(ICR) / Color / B/W |
|---|
| 焦距 | 6mm~180mm |
|---|
| Backlight Compensation | BLC / HLC / WDR(120dB) |
|---|
| Max. Aperture | F1.5~ F4.3 |
|---|
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
|---|
| Angle of View | H: 61.2° ~ 2.1° |
|---|
| Gain Control | Auto / Manual |
|---|
| Optical Zoom | 30x |
|---|
| Noise Reduction | Ultra DNR (2D/3D) |
|---|
| Focus Control | Auto/Manual |
|---|
| Motion Detection | Support |
|---|
| Close Focus Distance | 100mm~ 1000mm |
|---|
| Region of Interest | Support DORI Distance Electronic Image Stabilization *Note: The DORI distance is a “general proximity” of distance which makes it easy to Support (EIS) pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the Defog Support criteria for Detect, Observe, Recognize and Identify respectively. |
|---|
| Detect | Observe Recognize Identify Digital Zoom 16x 1920m(6299ft) 768m(2520ft) 384m(1260ft) 192m(630ft) Flip 180° |
|---|
| PTZ | Privacy Masking Up to 24 areas |
|---|
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -20° ~ 90°,auto flip 180° Audio |
|---|
| Manual Control Speed | Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s Compression G.711a/G.711mu/G.726/AAC |
|---|
| Preset Speed | Pan: 240° /s; Tilt: 200° /s Network |
|---|
| 預置位 | 300 Ethernet RJ-45 (10Base-T/100Base-TX) |
|---|
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan ,Auto Scan IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, |
|---|
| Protocol | ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, |
|---|
| Speed Setup | Human-oriented focal Length/ speed adaptation DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x Auto restore to previous PTZ and lens status after Interoperability ONVIF Profile S&G, API Power up Action power failure Activate Preset/ Scan/ Tour/ Pattern if there is no Streaming Method Unicast / Multicast Idle Motion command in the specified period |
|---|
| Max. User Access | 20 users |
|---|
| Edge Storage | Local PC for instant recording, Micro SD card 128GB Intelligence |
|---|
| Motion detection, Video tampering , Scene | Web Viewer IE, Chrome, Firefox, Safari |
|---|
| Event Trigger | changing, Network disconnection, IP address |
|---|
| conflict, Illegal Access, Storage anomaly | Management Software Smart PSS, DSS, DMSS |
|---|
| Smart Phone | IOS, Android www.dahuasecurity.com |
|---|
| Certifications | Accessories Certifications |
|---|
| CE: EN55032/EN55024/EN50130-4 | Included: FCC: Part15 subpartB,ANSI C63.4- 2014 |
|---|
| Video Interface | 1 port(BNC, 1.0V[p-p], 75Ω) |
|---|
| RS485 | 1 |
|---|
| PFB303W | PFA111 AC24V/3A |
|---|
| Audio I/O | 1/1 Wall Mount Mount Adapter Power Adapter |
|---|
| Alarm I/O | 7/2 Optional： Electrical |
|---|
| 供電 | AC24V/3A(±25%), Hi-PoE |
|---|
| 功耗 | 24W, 38W (IR on) Environmental |
|---|
| PFA140 | PFB300C PFA120 |
|---|
| Power Box | Ceiling Mount Junction Box |
|---|
| Operating Conditions | -40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH |
|---|
| 防護等級 | IP67 |
|---|
| Vandal Resistance | N/A Construction |
|---|
| PFA150 | PFA151 PFB303S |
|---|
| Casing | Metal Pole Mount Corner Mount Parapet Mount |
|---|
| 尺寸 | Φ240(mm) x 357(mm) |
|---|
| Ceiling Mount | Juncon Mount |
|---|
| 淨重 | 6.75kg(14.88lb) PFA111 + PFB300C PFA111 + PFB303W + PFA120 |
|---|
| 毛重 | 10.5kg(23.15lb) |
|---|
| 類型 | Part Number Description 2MP 30x Starlight Laser PTZ DH-SD6AL230F-HNI Network Camera, WDR, PAL 2MP 30x Starlight Laser PTZ Power Box Mount Pole Mount DH-SD6AL230FN-HNI |
|---|
| PFA111 | Mount Adapter |
|---|
| AC24V/3A | Power Adapter Corner Mount Parapet Mount |
|---|
| PFA111 + PFB303W + PFA151 | PFA111+ PFB303S |
|---|
| Accessories | PFB300C Ceiling Mount |
|---|
| PFA120 | Junction Box |
|---|
| PFA151 | Corner Mount |
|---|
| PFB303S | Parapet Mount www.dahuasecurity.com Dimensions (mm) |
|---|
| Rev 001.001 | © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com |
|---|
