Hikvision DS-2SF8C425MXG1-ELWY 為4 MP 25 × Speed Dome，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 DS-2SF8C425MXG1-ELWY 香港價格連安裝報價。
| 快門速度 | 1 s to 1/30000 s |
|---|---|
| 慢快門 | Yes |
| 日夜切換 | [Panoramic channel] Day,Night,Schedule,Auto, [PTZ channel] Day,Night,Schedule,Auto |
| 變焦 | [PTZ channel] 25 × optical, 16 × digital |
| 最大解像度 | [Panoramic channel] 3680 × 1656, [PTZ channel] 2688 × 1520 [Panoramic channel] horizontal field of view: 190°± 5°°, vertical field of view: 80° ± 5°, |
| 視場角 FOV | [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 65.8° to 3.5° |
| 對焦 | Auto,semi-auto,manual |
| 變焦速度 | [Panoramic channel] No, [PTZ channel] approx. 5.6 s |
| 焦距 | [Panoramic channel] 2.8 mm, [PTZ channel] 6 to 150 mm |
| 光圈 | [Panoramic channel] F1.0, [PTZ channel] F1.6 |
| 補光距離 | [Panoramic channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m |
| 智能補光 | Yes |
| 水平旋轉 | 360° endless |
| 垂直旋轉 | [Panoramic channel] 12°to 24°, [PTZ channel] -20° to 90° |
| 水平速度 | [PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s [PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s,[Panoramic channel] tilt speed configurable |
| 比例變倍 | [Panoramic channel] No, [PTZ channel] Yes |
| 預置位 | 300 |
| 巡航掃描 | 8 patrols, up to 32 presets for each patrol |
| 花樣掃描 | 4 pattern scans, record time over 10 minutes for each scan |
| 斷電記憶 | Yes Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan |
| PTZ 狀態顯示 | Yes |
| 預置位凍結 | Yes Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output [Panoramic channel] 50 Hz: 25 fps (3680 × 1656 ，3632 × 1632), 60 Hz: 30 fps (3680 × 1656 ，3632 × 1632) |
| 主碼流 | [PTZ channel] 50 Hz: 50 fps (2688 × 1520, 2560 × 1440), 100 fps (1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 60 fps (2688 × 1520, 2560 × 1440), 120 fps (1920 × 1080, 1280 × 960, 1280 × 720) *High frame rate is supported under monitoring mode only. [PTZ channel] 50 Hz: 25 fps (704 × 576,640 × 480,352 × 288), 60 Hz: 30 fps (704 × |
| 子碼流 | 480,640 × 480,352 × 240),[Panoramic channel] 50 Hz: 25 fps (1200 × 536 、960x432), 60 Hz: 30 fps (1200 × 536,960 × 432) [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × |
| 第三碼流 | 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),[Panoramic channel] No Main stream: H.265+/H.265/H.264+/H.264, |
| 視頻壓縮 | Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG |
| 視頻碼率 | 32 Kbps to 16 Mbps |
| H.264 類型 | Baseline profile,Main profile,High profile |
| H.265 類型 | Main profile |
| SVC 分級編碼 | H.264 and H.265 encoding |
| 感興趣區域 ROI | 8 fixed regions for each stream |
| 音訊壓縮 | G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3 32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),64 Kbps (G.711),16 Kbps (G.726),16 Kbps (G.722.1),8-48 Kbps (PCM) |
| 音訊取樣率 | 8 kHz,16 kHz,32 kHz,48 kHz |
| 環境噪音過濾 | Yes |
| API | ONVIF (Profile S, Profile G, Profile T, Profile M),ISUP,ISAPI,SDK,OTAP Password protection,complicated password,HTTPS encryption,IP address filter,802.1X |
| 安全 | authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,host authentication (MAC address),TPM 2.0 (FIPS 140-2 level 2) |
| 網絡儲存 | NAS (NFS, SMB/CIFS),auto network replenishment (ANR) IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,T CP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP |
| 同時取流 | Up to 20 channels |
| 用戶管理 | Up to 32 users. 3 user levels: administrator, operator, and user |
| 客戶端 | iVMS-4200,HikCentral Pro,Hik-Connect Plug-in required live view: IE8+ |
| 瀏覽器 | Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
| 寬動態 WDR | [Bullet channel] 120 dB, [PTZ channel] 150 dB |
| 日夜模式 | Day,night,auto,schedule programmable polygon privacy masks; mask color or mosaic configurable |
| 影像增強 | HLC,3D DNR |
| 除霧 | Digital defog |
| 防抖 | EIS (Built-in gyroscope to improve EIS performance) |
| Regional Exposure | Yes |
| Regional Focus | [Panoramic channel] No, [PTZ channel] Yes Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| 圖像參數切換 | Yes |
| 信噪比 SNR | ≥ 52 dB |
| Satellite Positioning | No |
| Gyroscope | Yes |
| Compass | No |
| 機身儲存 | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB . |
| Built-in Speaker | 1 built-in speaker |
| 網絡接口 | 1 RJ45 100M self-adaptive Ethernet port |
| 警報 | 7 input(s), 2 output(s) 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| 重設 | Yes [PTZ channel & panoramic channel] alarm input and output, exception,[PTZ channel] video tampering alarm Line crossing detection,intrusion detection,region entrance detection,region exiting |
| 智能事件 | detection,unattended baggage detection,object removal detection,loitering detection,people gathering detection,fast moving detection,parking detection [Panoramic channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, |
| 聯動方式 | [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Smart Linkage | Manual tracking, tracking takeover, linked tracking capture Detects up to 30 faces simultaneously, Uploads face with background and closed-up face pictures Up to 10 face libraries. 30000 faces for each library. 150000 faces in total, Recognizes face identity via face modeling, grading and comparing to those in face library, Supports face library encryption Support license plate recognition of vehi |
| Smart Tracking | Manual tracking, auto-tracking 3.0 Support person arming. When the device detects the armed face or human body in the monitoring scene, it triggers alarms, and tracks and captures the target. During the tracking, the target location and other related information are uploaded.Support vehicle arming. When the device detects the armed vehicles in the monitoring scene, it triggers alarms, and tracks a |
| 一般功能 | mirror,password protection |
| 供電 | 36V, 2.5 A, PoE(802.3 bt), 42.5 to 57 V, 1.76 A -40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F) |
| Wiper | Yes |
| 材質 | ADC12 |
| 尺寸 | Ø 290 mm × 453.2 mm (Ø 11.42" × 17.84") |
| 重量 | Approx. 10.5 kg ( 23.15 lb.) 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Dani sh, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian CE-EMC (EN 55032: 2015, EN 6 |
| Safety | CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017) |
| Environment | CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006) IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage Protection transient protection,IK10 (IEC 62262:2002, excluding glass window) |
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
| DORI 偵測距離 | Detect Observe Recognize Identify |
| Definition | 25 px/m 63 px/m 125 px/m 250 px/m 77.0m 30.5m 15.4m 7.7m 2965.5m 1176.8m 593.1m 296.6m |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →
Ø 290 mm × 453.2 mm (Ø 11.42" × 17.84")｜重量 Approx. 10.5 kg ( 23.15 lb.) 33 languages: English, Russian, Estonian, Bulgar
DS-2SF8C425MXG1-ELWY Hikvision 4 MP 25 × Speed Dome亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，DS-2SF8C425MXG1-ELWY 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 Hik-Connect App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：快門速度方面，DS-2SF8C425MXG1-ELWY 係 1 s to 1/30000 s，DS-2XE6885G0-ILZHS 係 1 s to 1/100,000 s；對焦方面，DS-2SF8C425MXG1-ELWY 係 Auto,semi-auto,manual，DS-2XE6885G0-ILZHS 係 Auto；H.265 類型方面，DS-2SF8C425MXG1-ELWY 係 Main profile，DS-2XE6885G0-ILZHS 係 Main Profile。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 DS-2XE6885G0-ILZHS 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 DS-2SF8C425MXG1-ELWY 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
HKEZIT 於全港各區提供 DS-2SF8C425MXG1-ELWY Hikvision 4 MP 25 × Speed Dome供貨連專業安裝服務（裝CAM、裝CCTV、裝監控），熱門地區包括：沙田CCTV 閉路電視安裝、油麻地CCTV 閉路電視安裝、深水埗CCTV 閉路電視安裝、灣仔CCTV 閉路電視安裝、筲箕灣CCTV 閉路電視安裝、紅磡CCTV 閉路電視安裝、荃灣CCTV 閉路電視安裝、葵涌CCTV 閉路電視安裝。港島、九龍、新界全港 32 區均有上門安裝，歡迎聯絡我們查詢 DS-2SF8C425MXG1-ELWY 香港價格連安裝報價。
DS-2SF8C425MXG1-ELWY Hikvision 4 MP 25 × Speed Dome適合多種場景使用，以下為部分常見安裝場景，歡迎查詢是否適合您的現場環境。
車房裝 CCTV 監控工場及客戶車輛停泊區、防盜防爭議、記錄維修過程取證。車房閉路電視出入口車牌識別管理進出車輛、保障客戶愛車。免費上門勘察、按工場規模報價，觀塘、將軍澳車房維修中心即約。專業團隊免費上門評估，
WhatsApp 查詢 →工廈單位裝 CCTV 守護迷你倉、共享辦公空間防盜，24小時無人值守時段遠端監控更安心。工商大廈閉路電視配門禁聯動記錄進出、保障租戶財物。免費上門勘察、按單位數報價，港島、新界工廈單位迷你倉即約。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →超市便利店裝 CCTV 全店覆蓋收銀、貨架防盜防搶、客流分析優化陳列，星光夜視守護 24 小時營業時段。零售店閉路電視防內鬼防偷竊、釐清顧客糾紛。明碼實價報價、免費上門勘察，香港、旺角便利店超市即日約期。上門度尺不收費、即日出報價，
WhatsApp 查詢 →凍房食品廠裝 CCTV 防潮防凍規格攝像頭、溫濕度監控聯動，貨物進出記錄追溯食安責任。冷庫閉路電視配火焰偵測守護低溫環境安全。防潮特殊規格、免費上門評估，沙田、旺角凍房食品廠即約報價。免費上門評估、快速出方案報價，
WhatsApp 查詢 →律師樓會計師樓裝 CCTV 監控文件室與會議室、高保安防盜防外洩，出入口錄影保障客戶機密與員工安全。專業服務所閉路電視私隱合規佈點、錄影權限分級管理。高保安方案、免費上門勘察，將軍澳、中環專業服務所即約報價。持牌團隊免費勘察、明碼報價，香港、新界一帶即日上門。
WhatsApp 查詢 →藥房中醫館裝 CCTV 監控藥櫃與收銀防盜、藥物管理記錄追溯，私隱合規張貼告示保障顧客。中醫館閉路電視配星光夜視覆蓋晚診時段。免費上門勘察、合規建議，新界、九龍藥房中醫館即約報價。免費上門度尺、報價一目了然，
WhatsApp 查詢 →查看更多CCTV 監控適用場景，請參閱 CCTV 監控安裝工程。
如需整套CCTV 監控方案，請參閱 CCTV 監控安裝工程。
