Name: HONEYWELL 600VSEC-DATA-SHEET Unimode 600ND
Brand: Honeywell
SKU: 600VSEC-DATA-SHEET

詳細規格

SBUS Out	Programming Port SBUS In Flexput Circuits
Chassis	Battery
Mounting	Connections Nuts Figure 3-3 Model Unimode 600 Assembly Figure 3-3 shows the circuit boards, metal housing and annunciator that attach the Unimode 600 assembly to the cabinet. If you should need to remove the board assembly for repair, remove the four mounting nuts which hold the assembly in the cabinet. Then lift the entire assembly out of the cabinet. Do not attempt to remove the circuit boards f
LS10090-001TY-E	Before You Begin Installation 3.6 Calculating Current Draw and Standby Battery This section is for helping you determine the current draw and standby battery needs for your installation. 3.6.1 Current Draw Worksheet Requirements The following steps must be taken when determining Unimode 600 current draw and standby battery requirements. 1. You will use the Current Draw Worksheet to determine curre
Standby	Alarm
Device	# of Devices Current per Device
Current	Current
For each device use this formula:	This column X This column = Current per number of devices.
Fire Panel (Battery current draw)	Standby: 290 mA 290 mA
警報	570 mA 570 mA Addressable SLC Devices
SD355 Photo	Standby: .30 mA6 mA mA
SD355-T Photo W/Heat	mA mA
CP355 Ion	mA mA
H355 Heat	mA mA
H355HT Heat High Temp	mA mA
AD355 Acclimate	mA mA
H355R Heat Rate of Rise	mA mA
BEAM355 (without integral test)	SLC Standby/Alarm: 2 mA mA mA
Aux. Pwr	Standby: 2 mA mA
BEAM355S5 (with integral test)	SLC Standby/Alarm: 2 mA mA mA
D355PL Duct (non-relay)	None, included with IDP-PhotoR 6
SD355CO CO Smoke	SLC Standby: .30 mA mA
MMF-301 Mini Monitor	(159 max/loop Standby/Alarm 0.375mA mA mA
MMF-300 Monitor	& 636 max/ mA mA
ADT-BG-12LX Pull Station	panel)1 mA mA
MDF-300 Dual Monitor	Standby/Alarm: 0.75 mA mA mA
MMF-300-10 Monitor-10	Standby/Alarm: 3.5 mA mA mA
CMF-300 Control	SLC Standby 0.375mA mA
Aux Pwr	Standby 1.7mA mA
CMF-300-6 Control-6	SLC Standby 2.25 mA mA
CRF-300 Relay	Standby/Alarm: 0.255 mA mA mA
CRF-300-6 Relay-6	Standby/Alarm: 1.45 mA mA mA
CDRM-300 Dual Relay/Monitor	Standby: 1.3 mA mA Module
MMF-302 Zone	Aux Pwr Standby 12 mA mA (159 max/loop Alarm: 90 mA mA
& 636 max/	SLC Standby/Alarm .27 mA mA mA
MMF-302-6 Zone-6	panel)1 Aux Pwr Standby 50 mA mA
SLC	Standby/Alarm 2 mA mA mA SLC Accessories
B200SR Sounder Base	Aux Pwr Standby: .5 mA mA
B200S Intelligent Sounder Base	(159 max/loop Aux Pwr Standby: .5 mA mA
panel)	SLC Standby .3 mA mA
B224RB Relay Base	Standby/Alarm: .5 mA mA mA
RT151/151 KEY	Alarm: 7.5 mA mA
RA100Z	Alarm: 10 mA mA SLC Isolator Devices
I300 Isolator Module	(318 max/loop Standby/Alarm: 0.45 mA mA mA
B224BI Isolator Base	& 636 max/ Standby/Alarm: 0.5 mA mA mA panel) Accessories Modules 5815XL SLC Expander Standby: 55 mA mA (63 max)4
Unimode 600ANN Remote Fire	Standby: 25 mA mA
Alarm Annunciator	(63 max)4
Alarm: (22 mA/relay)	220 mA mA
ECS-VCM Voice Control Module	Standby: 70 mA mA (1 max)
ECS-SW24 Switch Expander	Standby: 10 mA mA (32 max)
VIP-50 or VIP-125 Audio Amplifier	Standby: 10 mA mA
with/without VIP-CE4	(16 max)
Unimode 600RM Remote Voice	Standby: 70 mA mA
Module	(15 max)
ESC-50W or ECS-125W Audio	(16 max) Standby 10 mA mA
Amplifier with/without ECS-CE4	Alarm 10 mA mA
IFP-RPT-FO Network Repeater	Standby: 24 mA mA (1 max)
IFP-RPT-UTP Network Repeater	Alarm: 24 mA mA
ECS-DUAL50W	(16 max) Standby/Alarm: 10 mA mA mA
ECS-50WBU	(16 max) Standby/Alarm: 10 mA mA mA
A	Total System Current
Auxiliary Devices2	Refer to devices manual for current rating.
Alarm/Standby:	mA mA mA
B	Auxiliary Devices Current
Notification Appliance Circuits	Refer to device manual for current rating.
C	Notification Appliances Current mA
D	Total current ratings of all devices in system (line A + line B + C) mA mA
E	Total current ratings converted to amperes (line D x .001): A A
F	Number of standby hours H
G	Multiply lines E and F. Total standby AH AH
H	Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
I	Multiply lines E and H. Total alarm AH AH
J	Add lines G and I. 3 Total ampere hours AH required 1. Total does not include isolator devices or accessory bases. 2. If using door holders, you do not need to consider door holder current for alarm/battery standby, because power is removed during that time. However, during normal operation, door holders draw current and must be included in the 9.0A total current that can be drawn from the panel.
Rechargeable	24 hr Standby, 24 hr Standby, 24 hr Standby,
Battery Size	5 mins. Alarm 15 min alarm 20 min alarm 17AH 535 mA 473mA 442mA 18AH 569mA 506mA 475mA 24AH 769 mA 706mA 675mA 33AH 1.07A 1.01A 975mA 35AH 1.14A 1.07A 1.04A 40AH 1.30A 1.24A 1.21A 55AH 1.80A 1.74A 1.71A Table 3-3: Maximum Battery Standby Loads for 90 Hour Standby*
Mount the control panel cabinet.	4.1
Connect AC.	4.2
Connect phone lines.	4.11
Install 5815XL SLC expander modules.	4.6 Install Unimode 600ANN Remote Fire Alarm Annunciator modules. 4.5
Install 5865 or LED Annunciator modules.	4.9
Install 5880 LED I/O modules.	4.8
Install notification appliances.	4.12.1
Install auxiliary power devices.	4.12.5 Install 5824 Serial/Parallel Printer Interface Module. 4.7
Connect batteries (typically last step).	4.3 SLC Device Hardware Installation Perform these steps before running JumpStart AutoProgramming. 7.4 Connect device bases to the loop. 7.5 Set device addresses. Physically connect detectors to their bases. Connect relay and contact monitor 7.3 & see device
modules.	install instructions JumpStart AutoProgramming JumpStart AutoProgramming searches for expanders and SLC devices connected to the panel but not programmed into the system. JumpStart AutoProgramming automatically selects some options for SLC devices. See “Input Point (SLC Device) Configuration” section of this chart for other options. 8.2 & 9.7 JumpStart AutoProgramming makes selections for the foll
Select options for phone lines.	9.6.2 3-13
Assign output points to a group.	9.5 Assign a name (or description) for a group. 9.4.1.1 Select “group properties” (see below). Select options for activation with system switches. 9.4.1.2 3-14 See Section Task (for more info.) Emergency Communication System
Edit Lockout and Relinquish Timers.	6.5.1
Edit Auto Reset for ECS events.	6.5.1.2
Edit Voice Commands for events.	6.5.2 Edit VCM/RVM properties, including name, switch expanders, associating keypads, 11.2 and priorities. Creating an LOC. Edit amp properties, including name, voltage, and circuit expander. 11.5.2 3-15 Caution! To avoid the risk of electrical shock and damage to the unit, power should be OFF to the control panel while installing or servicing. 4.1 Mounting the Control Panel Cabinet Read the envir
Red	Black Battery Jumper (P/N 140694) Shipped With Panel
UL Recognized	UL Recognized 12V Battery 12V Battery Figure 4-2 Battery Connection 4-2 4.3.1 Battery Accessory Cabinets The Model RBB or AB-55 Accessory cabinets can be used when you are required to use backup batteries that are too large to fit into the main control panel cabinet. The RBB cabinet holds batteries up to the 35 AH size. The RBB dimensions are 16" W x 10" H x 6" D (40.64 cm W x 25.4 cm H x 15.24 cm
•	If mounting onto drywall the accessory cabinet must be mounted onto 3/4-inch plywood. This is neces- sary because the weight of the batteries inside the accessory cabinet could cause the cabinet to pull away from the drywall.
+	- + - RBB / AB-55 Cabinet Cover Screws Figure 4-5 Battery Connections in the RBB or AB-55 Cabinet Note: Figure 4-5 is an example of how the wire connections can be routed. However, any other cabinet knock-outs (on either the main control panel or the RBB/AB-55 cabinet), that are not previously being used may be uti- lized to connect conduit between the two cabinets. 4. Connect battery leads to the
Model Number	Worst Case Current Draw
Unimode 600ANN Fire Annunciator	.120 amps 5815XL .150 amps 5824 Serial/Parallel Printer Interface Module .040 amps 5880 LED I/O Module .250 amps 5865 LED Annunciator .200 amps 5895XLIntelligent Power Supply .010 amps 5496 Intelligent Power Supply .010 amps
ECS-50W	.010 amps
ECS-125W	.010 amps
ECS-VCM / ECS-VCM with ECS-SW24*	.115 amps /.185 amps
Unimode 600RM / Unimode 600RM with ECS-	.210 amps /.325 amps SW24*
ECS-DUAL50W WITH ECS-50WBU	.010 amps Note: Refer toTable 3-1 if using LiteSpeed SLC devices for maximum number of each type of device that can be used per system. * All devices must use the same SBUS and VBUS. After calculating the total worst case current draw, refer toTable 4-1 for the maximum distance the modules can be located from the panel on a single wire run. The table ensures 6.0 volts of line drop maximum. In gene
Maximum Resistance (Ohms) =	6.0 Volts Total Worst Case Current Draw (amps)
Maximum Wire Length (Feet) =	Maximum Resistance (Ohms) * 500 (6000 feet maximum) Rpu where: Rpu = Ohms per 1000 feet for various wire gauges (see table below) Table 4-2: Typical Wire Resistance Per 1000 ft. Using Copper Wire
Wire Gauge	Ohms per 1000 feet (Rpu) 22 16.2 18 6.4 16 4.02 14 2.54 4-6 Wiring Distance calculation example: Suppose a system is configured with the following SBUS modules: 2 - Module Unimode 600ANN Fire Annunciator 1 - 5895XL Intelligent Power Expander 1 - 5865 LED Annunciator 1 - 5824 Serial/Parallel Interface Module The total worst case current is calculated as follows:
Unimode 600ANN Current Draw	= 2 x .120 amps = .240 amps 5895XL Current Draw = 1 x .010 amps = .010 amps 5865 Current Draw = 1 x .200 amps = .200 amps 5824 Current Draw = 1 x .040 amps = .040 amps
Total Worst Case Current Draw	= .490 amps Using this value, and referring to the Wiring Distance table, it can be found that the available options are: 370 feet maximum using 22 Gauge wire 938 feet maximum using 18 Gauge wire 1493 feet maximum using 16 Gauge wire 2362 feet maximum using 14 Gauge wire 4.4.2 Wiring Configurations Figure 4-7 illustrates SBUS 1, Class A wiring configuration and Figure 4-8 illustrates SBUS1 Class B
Supervised	For proper system supervision do not use looped
Power Limited	wire under terminals marked A, B, +, and - of the SBUS device connectors. Break wire runs to provide supervision of connections. Figure 4-7 SBUS Class A Wiring 4-7
To panel via SBUS	To SLC loop Figure 4-16 5815XL Board 4-14 4.6.1 5815XL Connection to the Panel Connect the 5815XL to the control panel as shown in Figure 4-17. After the 5815XL is connected to the panel, it must be added to the system. This programming steps are described in Section 9.2.2. Supervised Power Limited Figure 4-17 5815XL Connection to Main Panel Assembly 4-15
Defaulted to No	Parallel or Serial. (Most printers
Select “Yes” for	are parallel) event Logging Figure 4-20 Selecting Printer and Output Port Options 6. Select options for the printer as needed for your installation. Most printers are parallel. Note: When setting Monitor Printer to “Yes” the system defaults to printing only for the connected panels site. Use Unimode 600PK to configure the 5824 to print for multiple sites. 4-17
Option	Choices
Baud Rate:	75 - 19200
Data Bits:	5-8
Stop Bits:	.5, 1, 2
Parity:	None, Even, Odd 4.8 5880 LED I/O Module The 5880 is an LED driver board that can be used in a wide variety of applications, including as an interface with most customized floor plan annunciator boards. The 5880 can drive up to 40 LEDs and has one PZT controller. The 5880 also has eight inputs for dry contact monitoring. The following sub-sections describe hardware installation. Refer to Section 9
point numbers for	Plexiglass plate mounted to LED board at factory. 1 2 11 12 21 22 SILENCE 5865-4 switches 3 4 13 14 23 24 follow main FACP; 5 6 15 16 25 26 no installation
TROUBLE	or programming 7 8 17 18 27 28 required. 9 10 19 20 29 30 RESET 5865-4 Board Assembly 5865-3 Board Assembly Figure 4-25 5865-3 and 5865-4 Assembly (front view) 4.9.1 FACP Connection The 5865 connects to the panel via the SBUS. Make connections as shown in Figure 4-26. After the 5865 is connected to the panel, it must be added to the system. This programming step is described in Section 9.2.2. Supe
UL Listed EOL	Supervised Model 7628 4.7 k Regulated 24 VDC 3A per Circuit, 9A max Combined Figure 4-31 Class B Notification Appliance Circuit Wiring Maximum voltage drop is 3V per Class B notification. See Table 4-3. Table 4-3: Maximum Impedance Class B
UL Listed EOL Model	Maximum Impedance 7628 4.7 k per circuit is 50 Figure 4-33 Class B Input Switches 4.12.2.2 Class A Inputs You can connect conventional Class A switches, such as waterflow switches and pull stations, directly to the Flexput circuits of the control panel. To install a Class A switch: 1. Wire the Class A switch as shown in Figure 4-34. 2. Configure the circuit through programming (see Section 9.5).
Flexput circuit 5 and 6	Any 2 wire
used as an example.	smoke detector Any Flexput point pairing
could be used.	listed in Appendix A Maximum Impedance per circuit is 50 Figure 4-36 Two-Wire Class A Smoke Detector Connections Note: In programming any point that uses multiple Flexput circuits, the lowest Flexput circuit number is used to refer to the circuit pair. For example, Figure 4-36 uses both Flexput circuit 5 and 6, so in programming it would be referred to as point 5. 4.12.4 Installing 4-Wire Smoke D
per Circuit is 50	EOL Resistor Model 7628 Note:
Any Flexput point pairing	Supervision
Model 160150	circuit is 50 Supervision Module Air Products PAM-2
Terminal #	Connects To Terminal # Connects To Not suitable for remote station protected premise service where separate transmission circuits are required for fire supervisory (if applicable), and trouble signals. Intended for connection to a polarity reversal circuit of a remote station receiving unit having compatible ratings. Figure 4-41 Keltron 3158 Connection to Control Panel 4-35
Panel Operations	F1 Function Key F2 Function Key F3 Function Key F4 Function Key ECS Control Request Function ECS Super User Function System Tests Fire Drill Menu Indicator Test Walk Test-No Report Walk Test -With Report Dialer Test Clear History Buffer Point Functions Disable/Enable Point Point Status
Panel Menus	Set SLC Device Address SLC Single Device Locator SLC Multiple Device Locator I/O Point Control Event History Set Time & Date System Information Upload/Download Network Diagnostics Network Programming Panel Programming To change an access code: 1. Enter the installer code. The panel will automatically go to the main menu. 2. Select 6 for Network Programming Menu. 3. Select 5 for Access Codes. 6-4
Display reads:	Select Profile 01 Fire Fighter’s Key 4. Select the access code you wish to edit by pressing the or arrow. 5. Then press ENTER. Profile Edit Menu From the Profile Edit Menu you can change the users name, access code, and the panel functions that the user will have access to with their code. Note: Profile 1 (Fire Fighter’s Key) the user name and access code can not be edited. Profile 2 (Installer) t
ECS Timer	Option
Control Lockout	Immediate/Timer/Never
Auto Reset ECS Custom Event	Never/Timer/Event Disabled
Auto Reset ECS Event 1	Never/Timer/Event Disabled
Auto Reset ECS Event 2	Never/Timer/Event Disabled
Auto Reset ECS Event 3	Never/Timer/Event Disabled
Auto Reset ECS Event 4	Never/Timer/Event Disabled
Auto Reset ECS Event 5	Never/Timer/Event Disabled
Auto Reset ECS Event 6	Never/Timer/Event Disabled
Auto Reset ECS Event 7	Never/Timer/Event Disabled
Auto Reset ECS Event 8	Never/Timer/Event Disabled 6.5.2 Edit Voice Commands When a voice output group is selected to be activated by a zone, the cadence pattern choice does not apply. For voice output groups, one of six system wide voice commands will activate instead of the cadence pattern. 1. Enter the installer code. The panel will automatically go to the main menu. 2. Select 6 for Network Programming Menu. 3. Select
Menu	Options/Defaults Comments
Learn	Guest or member Add or remove See Section 6.2.1
Network	panels into the
Programing	Network
Site Names	Edit Site Member Edit Site Names Names
Edit Panel	Change current See Section 6.2.3
ID	panel ID
Computer	Computer Access *123456 See Section 6.2.4
Access	Number
Computer Code	*0
Computer Phone	Up to 40 digits Number
Edit Name	Profile 1 is the profile that dictates what functions the Firefighter Key Edit Access Code has access to. Because this is the
System Reset	profile for a keys, the user name and
System Silence	the access code can not be edited for this profile. System ACK Fire Drill Key Profile 2 is the profile for the installer
System Tests	and is referred to as the “Installer Code”. This profile’s user name and Fire Drill Menu panel functions can not be edited. Indicator Test See Section 6.3.
Codes	Dialer Test Select Profile Clear History Buffer (01 - 20)
Panel Functions	Point Functions Disable/Enable Buffer Point Status Set SLC Device Address SLC Single Device Locator SLC Multi-Device Locator I/O Point Control Event History Set Time & Date Network Diagnostics 6-10
Panel Programming	has access to. Because this is the profile for a keys, the user name and
System Information	the access code can not be edited
Upload/Download	for this profile. Multi-Site Profile 2 is the profile for the installer
F2 Function Key	panel functions can not be edited. See Section 6.3. F3 Function Key F4 Function Key ECS Control Request ECS Super User
Dialer Assignments Select Panel	Primary 0= unused See Section 6.4.1
Enable pi SIA	Yes See Section 6.4.2
Dialer	Modifier Miscellaneous
Programming	(1-4)
Receiver Format	Contact ID
Receiver	SIA500
Configuration	SIA8 SIA20 UNUSED PHONE Number
Dialer Report Table	Primary Receiver See Section 6.4.4 Primary Account Test Primary Account Secondary Receiver Secondary Account Test Secondary Account 6-11
Edit Timers	Control Lockout Immediate/ See Section 6.5.1 Timer/Never
Auto Reset ECS	Never/Timer/
Event 1-8	Event
Choose Site	Fire Pre Alarm
Emergency	See Section 6.5.2 Commands Communication 1-8 System Alert 1-5 Trouble Fire Interlock Release Fire Interlock Alert Emergency Supervisory CO Alarm CO Supervisory
Sync	See Section 6.6 Options 6-12 Caution! To avoid the risk of electrical shock and damage to the unit, power should be OFF at the control panel while installing or servicing. 7.1 List of LiteSpeed SLC Devices The following LiteSpeed SLC devices can be used with the control panel. See the device installation instructions (packaged with the device) for more information. Note: The control panel supports
Tyco Part Numbers	Model Name/Description Sheet PN
SD355	Photoelectric smoke detector
SD355T	Photoelectric smoke detector with thermal (135°F) I56-3660-000
AD355	Multi-criteria photoelectric smoke detector with thermal (135°F)
BEAM355	Reflected beam smoke detector without test feature I56-2425-000
BEAM355S	Reflected beam smoke detector with test feature
CP355	Ionization smoke detector I56-3656-000
H355	Fixed temperature thermal detector (135°F)
H355R	Rate-of-rise thermal detector with 135° fixed temperature I56-3657-000
H355HT	Fixed high temperature thermal detector (190°F)
BG-12LX	Addressable dual action pull station 51094
I300	Fault isolator module I56-1381-000
MMF-300	Monitor module I56-3653-000
MMF-301	Mini monitor module I56-1193-000
MDF-300	Dual input monitor module I56-0013-000
MMF-300-10	10 input monitor module I56-1873-000
CRF-300	Relay module F300-04-00
CRF-300-6	Six circuit relay module F300-21-00
CDRM-300	Multi module with 2 relay outputs & 2 monitor inputs I56-3726-000
MMF-302	Zone interface module I56-1192-000
MMF-302-6	Six zone interface module I56-1900-000
CMF-300	Supervised control module I56-3650-000
CMF-300-6	Six circuit supervised control module I56-1874-000
SD355CO	CO Smoke Detector I56-
B200S	Intelligent sounder base I56-3387-000
B350LP	6" mounting base I56-0954-01
B224BI	6" isolator base I56-0725-000
B224RB	6" relay base I56-3737-000
B200SR	Sounder base I56-3392-000
B501	4" mounting base I56-0357-000 7-1
wards through the list with	). 6. When you reach the last detector on this device, press . 7. The system will ask you if there are more duct detectors in the system. If there are, select 1 for Yes and repeat from Step 3. If there are no more duct detectors, select 2 for No and continue with Step 8. 8. The system will restart in 10 seconds. You can press 1 to restart immediately. 9. After the system resets, it will use the ne
System	Zone Panel Site
Manual Pull Alarm	System Aux 1 Alarm Fire Drill
Water Flow Alarm	System Aux 2 Alarm General Fire Alarm
Detector Alarm	General Fire Supervisory (heat or smoke detectors)
Zone Aux 1 Alarm	General Fire Pre-Alarm Zone Aux 2 Alarm Fire Interlock Alert Interlock Release Pre-Alarm Fire Supervisory CO Alarm CO Supervisory LOC ECS 1-8 Alarm Emergency General ECS Alarm General ECS Supervisory Point ECS 1-8 Alarm
Trouble	SBUS Expander Trouble General Trouble
Status Point Active	SBUS Class A Trouble Site Silenced
SLC Loop Trouble	Voice Aux In 1-8 Alarm
AC Loss Trouble	F1 Key Active
Battery Trouble	F2 Key Active Advisory
Ground Fault Trouble	F3 Key Active
Phone Line Trouble	F4 Key Active
Reporting Account Trouble	Voice Aux in 1-2
Printer Trouble	System Mic Active
Aux Power Trouble	Background Music
System Switch Trouble	F1 Key Active Output Group Trouble 8-7
To	Press
Select from a menu.	The corresponding number on the annunciator.
Enter numeric data.	The appropriate number on the annunciator.
Enter text (alphanumeric data).	See Appendix B for complete list of characters.
Select from a scrolling list.	The up arrow or down arrow to move through the list of available options. When the option you want to select is displayed, press ENTER. 8-15
Edit Module	Select Module Enter Module Name Section 9.2.1 Edit Module specific options 5824-Serial/Parallel/ Unimode 600ANN LCD Annunciator 5815XL-SLC Loop Expander 5895XL Power Supply 5496 Nac Expander 5880-LED/IO Module 5865-LED Annunc. Module
Add Module	Amplifier Section 9.2.2 ECS-125W-Voice Amplifier ECS-DUAL50W- Voice Amplifier ECS-VCM-Voice Control Module Unimode 600RM - Remote Voice Module VIP-VCM-Voice Control Module VIP-RM Remote Voice Module
Delete Module	Select Module Section 9.2.3
View Module List	Select Module Section 9.2.4 Section Edit Zone Name 9.3.1.1 *1-Count
Zone	Edit Zone Select Zone 2-Count
Properties	Type 9.3.1.2 PAS SNGL ILOCK 8-17
Heat Temp	devices 135° to 190°F
Set	Section Zone
Smoke	Section Medium
靈敏度	9.3.1.2 High
Edit Zone	Select Zone
Station	00-23 Cadence
Accessory	Multi station 00-23 9.3.1.3
Opt	Cadence Yes Local Zone
View Zone Points	Select Zone Section 9.3.2 Section Group Name 9.4.1.1
Voice Group	Y or N
Switch	1-64
Template	Section
Y or N	9.4.1.2
Edit Group	Select Group Override
Group	Allow Sys
Group1	Override Dynamic Act/
Override	(See Appendix C) Cadence
View Group Points	Select Group Section 9.4.2 Edit OPG Template Select template Modify name and which OPGs are in template Section 9.4.3 UNUSED MANUAL PULL
WATER	*LATCH
FLOW	NON-LATCH
FIRE	*LATCH
SUPERVSY	NON-LATCH FIRE DRILL
LiteSpeed Devices	Select SILENCE
Point	on Internal and Enter Pt Module Section 9.5
External 5815XL	LiteSpeed SWITCH RESET P.A.S. ACK *LATCH ZONE AUX1 NON-LATCH LATCH ZONE AUX2 NON-LATCH
SYSTEM	LATCH
AUX1	NON-LATCH 8-18
SWITCH	SYSY-TEM LATCH
AUX2	NON-LATCH DETECTOR SW
防拆	NON-LATCH MANUAL RELEASE INTERLOCK STATUS POINT CO DETECTOR SWITCH LATCH ECS INPUT NON-LATCH
Select	ECS LATCH
VISORY	NON-LATCH
OUTPUT PT	Select Group AUX CONST NOTIF AUX RESET AUX DOOR
on Internal and	Enter PT External 5815XL
DETECTOR	2-WIRE Select Zone SMOKE UNUSED PHOTO SDR BAS RLY BAS ION SDR BAS RLY BAS Select
Sensor	No (LiteSpeed DETECTOR Accessory
ONLY)	HEAT SDR BAS RLY BAS
PHOTO	Accessory DUCT DCT RLY ACCLI-MATE SDR BAS RLY BAS 8-19
SUP DET	LATCH DE- TECTOR
SDR BAS	Single station or Multi station RLY BAS Silence or
CO ALARM/	Non-Silence FIRE ALARM Latch or non-
I-SdrBA	latch Single (Intelligent station or Multi
Sounder	station
Base)	Silence or Non-Silence
CO SUPR/	Non-Silence FIRE ALARM Latch or non-
Enter Pt	CO FIRE (LiteSpeed FIRE ALARM Latch or non- ONLY)
B NOTIF	Super-vised CONTROL Yes or No CIRCUIT NOTIF Select Group
OUTPUT	Section 9.5
A NOTIF	Supervised CONTROL
AUX PWR	AUX DOOR AUX POWER SYNC*
Enter Pt /Select Function	MANUAL PULL WATER- FLOW FIRE Latch and Non-Latch feature
SUPER-	only appear for VISORY WATERFLOW,FIRE
B SWITCH	TAMPER TAMPER, ZONE AUX1, ZONE AUX2, SYSTEM FIRE
DRILL	AUX1, SYSTEM AUX2., ECS INPUT, ECS TAMPER, and
SILENCE	ECS SUPERVISORY. RESET P.A.S. ACK ZONE AUX 1 8-21
MANUAL	AUX1, SYSTEM AUX2., ECS
RELEASE	INPUT, ECS TAMPER, and INTER-LOCK ECS SUPERVISORY.
ECS	Latch and Non-Latch feature
Enter Pt /Select Function (cont.)	ECS SUPER- SUPERVISORY, FIRE
Internal Power and	VISORY TAMPER, ZONE AUX1,
External Power	ZONE AUX2, SYSTEM (cont.) STATUS AUX1, SYSTEM AUX2., ECS
A SWITCH	Same as B SWITCH 2-WIRE SMOKE
B DETECT	4-WIRE SMOKE
CO 4-WIRE DET	Section 9.5 2-WIRE SMOKE
A DETECT	4-WIRE SMOKE CO 4-WIRE DET
Select Group or	Group or Zone selection will
Zone Number	appear depending on the
Series Amplifiers	Select Group
Auto Time Test	Set the Minutes *02:00AM Section 9.6.1 Select AM/PM For each phone line (1 & 2) select:
Options	Number of rings before
Phone Lines	Select Phone Line panel answers
# of Answer Rings	Range: 00-15 *06 a call from a computer Section 9.6.2.2 8-22
TT	Touch Tone TouchTone alternating
Select Dialing Option	TT/PL *TT with pulse see Section 9.6.2.3
PULSE	Pulse dialing U = 60/40
Dial Tone Disabled	Y or N *N Section
Monitor Line	Y or N *N 9.6.2.6 Section
Answering Machine Bypass	Y or N *N 9.6.2.7 Section
Phone Line Unused	Y or N *N 9.6.2.8 Yes
Enable/Disable	*No Daytime/Nighttime
Day Start	Enter time *6:00AM Section 9.6.3 Sensitivity
Night Start	Enter time *6:00PM
Days of the Week	Select days -MTWTF- 01/01, 07/
Holiday Days	Holidays 1 to 18 Enter dates 04, 12/24, 12/ Section 9.6.4
Alarm Verification	1 to 250 seconds *60 sec Alarm Verification time section
Time	9.6.5.2
Low AC Report Time 0 - 30 hours	*3 hrs Low AC Report Delay. Section Time Options 9.6.5.3
AC Freq:	50 Hz *60Hz Section 9.6.5.4 60 Hz Neither
Clock Display	AM/PM *AM/PM System Clock Format (AM/PM
Format	MIL or military). Section 9.6.5.5
SYNC Strobes when	Y *N Section 9.6.6.1 Silenced
Auto Display Events	Y *N Section 9.6.6.2
Miscellaneous	N
IFP-RPT Both Ports	Y Section 9.6.6.4 Used
Auto Daylight Saving Y	*Y Section 9.6.7.1 Time
Daylight Saving	N
DST End	4th or Last 9.6.7.2 8-23
Edit Banner	Refer to Appendix B Section 9.6.8 IP Address Subnet Mask
DCHP Enable	*N Y (Yes)
Start	See Section 9.7 N (No)
Restore	Y (Yes) See Section 9.8
Defaults	N (No)
ECS-VCM	PC Connection
Voice	Maintenance Local Recording Section 9.6.9
Permitted in	Permitted in Settings Settings
Menu Item	UL 864 UL 2572 (Y/ Permitted in UL Permitted in
Time Options	Low AC Yes Yes 0–30 hours 1–3 1–3 Report Delay
Display Oldest	Y (Enabled) Yes Yes Yes & No Yes Yes
Event	N (Disabled) No No Yes & No No No
Initial Delay	0-28 Yes Yes 0-28 3-10 4-28
Inter Message	Yes Yes 4-32 4-32 4-28 4-32
Auto Reset	Auto Reset Yes Yes Never Never Never
ECS Custom Event	ECS Custom Timer Event Disabled Disabled
ECS Input	ECS Input Yes Yes Latching Latching Latching Non-Latching
Event Priority	CO Alarm No No Yes & No No No 9.2 Modules This section lists the options available under the module option in the Panel Programming. The following modules are available for the control panel: 5824 serial/parallel/IO printer interface module, Unimode 600ANN remote fire alarm annunciator, 5815XL SLC expander, 5496 intelligent power module, 5895XL, 5880 LED I/O module, 5865 LED-annunciator, ECS-50W o
Use	to select Figure 9-1 Edit module Name Programming Screen Example 9.2.1.3 Changing Module Options Each module has a unique set of options that specifically applies to the functionality of the module being edited. 9. Use the left and right arrow keys to move between available options. 9-2 10. Option settings are edited by pressing the or arrow. or using the keypad for numerical entry. 9.2.2 Adding a
Detection type is selected from this	Select temperature that will cause heat
screen (see Table 9-1).	detectors in this zone to go into alarm. Range: 135-190°F (LiteSpeed) Zone # being Select sensitivity LOW, MEDIUM, or HIGH 9-4 Alarm Delay Characteristics The programmed zone type is provided for user reference only. To modify the zone type use the Unimode 600PK Software Suite. Table 9-1 list the detector characteristics and a description of each. Table 9-1: Detector Characteristics
Type of Delay	Description One Count (No Delay). When this option is enabled, an alarm occurs immediately when a single device of 1-Count any of the following types goes into alarm: detector, manual pull, water flow, Zone Aux1 or Zone Aux2. This is considered the most typical operation and is the default for all zones. When this type of alarm delay is used, two or more detectors within the zone must go into alar
Single Interlock	See Section 10.8.1 for single interlock releasing operation.
Double Interlock	See Section 10.8.2 for double interlock releasing operation. Heat Detector Sensitivity Use this feature to set the temperature at which high temperature detectors will respond.All detectors in the zone will respond in the same way.The range for heat detector is from 135°F to 190°F. The high temperature heat detectors are absolute temperature devices. This means that they respond to an alarm immedi
Low (3.5% obscurity)	If the day/night sensitivity option is selected, you can have
SD355, AD355,	different sensitivity settings during the day and at night. You can Medium (2.5% obscurity)
High (1.5% obscurity)	automatically adjust. You can also designate specific days as
Low (55 pA)	Holidays. Holiday and weekend days use night sensitivity for the entire day
LiteSpeed	CP355 Medium (68 pA) High (80 pA) Low (2.5% obscurity)
D355PL	Medium (2.0% obscurity) High (1.5% obscurity) * Automatic drift compensation is always in effect for all detectors. Detectors are sampled every 3 hours. See Section 10.4.10 for information about how to check if a detector is in compliance. 4. Use the or keys to scroll through the range 5. Then press ENTER. 9.3.1.3 Zone Accessory Options 1. Do steps 1 through 5 of Section 9.3.1. 2. Press 3 to edit
Group #	“Switch# only applies
Voice EVAC Only	if the group is a voice group.” Figure 9-3 Group Properties Screen Programming Options Defining Output Group Type Each output group is defined as either a voice output group or a non-voice output group. Output points that are audio circuits (all circuits on the ECS-50W, ECS-125W, ECS-DUAL50W and ECS-CE4) can only be assigned to voice output groups. Output points that are non-voice circuits (all ot
Corresponding	Corresponding
Key and LED Numbers	Key and LED Numbers
Function	Latching Option Comments Selection
UNUSED	Select for SLC points that are unused.
ION	Spot ionization detector.
PHOTO DUCT	Duct photoelectric detector.
ION DUCT	Duct Ion detector.
ACCLIMATE	Acclimate photoelectric detector.
HEAT HT	High temperature heat detector.
PHOTO-HEAT	Photoelectric detector with heat sensor.
BEAM	Beam smoke detector. 2-WIRE SMOKE 2-wire smoke detector. PHOTO ION HEAT PHOTO DUCT
Non Latching	alarm. ACCLIMATE HEAT HT PHOTO-HEAT BEAM CO ALRM / FIRE ALRM CO ALRM / FIRE
CO SMOKE	SUPR
CO SUPR / FIRE	Latching Supervisory can be latching or non-latching.
SUPR	Non Latching Use this switch type for manual pull stations. This input is always MANUAL PULL latched. The switch can clear only when an alarm is reset.
Latching (default)	Use this switch type for monitoring water flow in a sprinkler system. Switch closure will cause a sprinkler alarm. Water flow switches can be programmed as latching or non-latching. You can program a delay of up to 90 seconds to be used with a water flow switch. The delay allows for normal, brief changes in
WATERFLOW	sprinkler system water pressure. The water flow alarm will not
Latching	Use this switch type for tamper monitoring of sprinklers and other
FIRE SUPER-	fire protection devices. If a contact closes, a sprinkler supervisory
P.A.S. ACK	is not already in progress, a trouble will occur. You must use a UL listed normally open, momentary switch type. The switch must be rated at 5V, 100 mA (minimum) and be used with an EOL resistor for supervision.
ZONE AUX1	conditions (such as dry contact from a remote power supply). Non Latching Latching ZONE AUX2 Non Latching
FIRE TAMPER	a tamper switch on the LCD annunciator. Non Latching
INTERLOCK	Interlock release switch input. STATUS POINT Latching ECS INPUT Non Latching
ECS SUPER-	Latching
CO DETECT SW	CO Detector Switch Output point, a general use notification type. Use for driving
NOTIF	Use for auxiliary power, resettable applications. See Section AUX RESET 4.12.5.3 for a description of how this option operates. Use for auxiliary power, door holder applications. For example, if you were using an auxiliary power supply for door holders, you AUX DOOR would use this option. See Section 4.12.5.1 for a description of how this option operates. 9-11
LED NUMBER	01-80 For use with SD devices only. 80 sub addresses on LED.
SLC LED	Unused LED FUNCTION
Press	to skip point name edit. 12. Repeat Steps 1 through 16 for all circuits. 9-12 Table 9-4: Menu choices for Internal/External Power Module
Choices	Type Selections Selections for Comments each Type Enter Point UNUSED
CONSTANT	Constant auxiliary power.
AUX_PWR	AUX RESET Resettable auxiliary power.
AUX DOOR	Door holder auxiliary power. MANUAL PULL WATERFLOW FIRE SUPERVISORY
FIREDRILL	Table 9-3 for description of these options. SILENCE Latch or Non-latching feature only
重設	appears for WATERFLOW, FIRE SUPERVISORY, FIRE TAMPER, ZONE P.A.S. ACK AUX1, ZONE AUX2, SYSTEM AUX1,
Select Type	ZONE AUX1 SYSTEM AUX2, ECS INPUT, ECS B SWITCH
ZONE AUX2	TAMPER, and ECS SUPERVISORY. SYSTEM AUX1 User also has ECS Event Number 1-8
SYSTEM AUX2	option for ECS INPUT. MANUAL RELEASE Only available when an ECS-VCM is
Select Zone/Group	Group or Zone selection will appear depending on the type selected.
Enter Point	Select NOTIF or Unused Select an output Group for this Zone/Group Select a name for the Point Figure 9-5 Programming Points as Outputs for the 5880 Module
Select Switch or Unused	Select Function Figure 9-6 Programming Points as Inputs for the 5880 Module 5. Enter the point number, then press ENTER. 6. Press the or arrows to select the type (notification or unused)., then press ENTER. 7. Press the or arrows to select the desired group., then press ENTER. 8. Press ENTER to edit point name. See Appendix B. Or, Press to skip point name edit. 9. Repeat Steps 1 through 8 for all
SYSTEM AUX1	User also has ECS Event Number 1-8
ECS-VCM/ECS-RVM	AUX1, ZONE AUX2, SYSTEM AUX1,
MANUAL RELEASE	User also has ECS Event Number 1-8
#	Pound (or number) key on the telephone
*	Star key on the telephone
,	Comma (character for 2-second pause) Use the number buttons on the annunciator or the up- and down-arrow keys to select special characters. Special characters begin displaying after “9”. 6. Enter a dialing prefix (if needed), then press ENTER.
Dial Option	Description
TT/PL	TouchTone. It will switch to pulse if TouchTone is not successful on the first attempt. It will continue to alternate between TT and pulse for additional attempts. 9.6.2.4 Rotary Format 9. Press the or arrow to select the pulse ratio for rotary dialing option, then press ENTER. Options are:
U	U.S. standard format. Uses the 60 msec / 40 msec make/break ratio.
or	arrow, then press ENTER. 9.6.2.8 Phone Line Unused This option is used so that you can set unused phones lines to “Yes”, so no autotest will be sent through that line. This option is factory programmed as No. 13. Select Y or N by pressing the or arrow, then press ENTER. 9-20 9.6.3 Daytime/Nighttime Sensitivity If you need to change the time that sensitivity levels take effect (that is, the time th
characters, then press	to move to the next character. 6. When done, press ENTER to save the custom banner. 9.6.9 Edit Ethernet 1. Enter the installer code. The panel will automatically go to the main menu. 2. Select 7 for Panel Programming. 3. Select 5 for System Options. 4. Select 9 for Edit Ethernet. Figure 9-15 Edit Ethernet Message 9-25
Main Menu Options	Description 1- System Tests Access to Fire Drill, Indicator Test, Walk Tests, Dialer Test, Clear History Buffer, and Manual Dialer Reset. 2- Point Functions Enable/disable points, Point Status, Set SLC Address, Device Locator, and I/O Point Control. 3- Event History Display event history on the LCD. See Section 10.4.3 for more information. 4- Set Time & Date Set time and date for the system. 5- Ne
To select an option:	Enter the number of the option. –OR– Press ENTER Key if the option has the = symbol next to it. Exit Menu (left arrow) 10.4 Basic Operation 10.4.1 Setting Time and Date 1. From the Main Menu, select 4 for Set Date & Time. 2. Make changes in the fields on the screen. Use right arrow to move through the fields. Use the or arrow to select options in the fields. 3. When the date and time are correct,
On multi-site displays, pressing ENTER or	brings you directly into View Event History and allows you to view the Event History from every panel in each of the sites that the multi-site display is assigned to. 10.4.3.1 To clear the event history From the main menu select 1 for System Tests. From the test menu select 6 Clear History Buffer. In network systems, this clears the History Buffer of all panels in the site. 10.4.4 Conduct a Fire D
Fire System	Emergency System
Fire Manual Pull Alarm	Emergency LOC Alarm
Fire Detector Alarm	Emergency 1 Point Alarm
Fire Water Flow Alarm	Emergency 2 Point Alarm
Fire Interlock Release Alarm	Emergency 3 Point Alarm
Fire Zone Aux 1 Alarm	Emergency 4 Point Alarm
Fire Zone Aux 2 Alarm	Emergency 5 Point Alarm
Fire System Aux 1 Alarm	Emergency 6 Point Alarm
Fire System Aux 2 Alarm	Emergency 7 Point Alarm 10-9
Count of fire system	Count of emergency
alarms currently active	communication system alarms currently active Counts of CO alarms currently active Figure 10-4 Highest Priority Event Display Event displayed out
site #	panel # module # of total number of events
fire alarm supervisory	CO alarm supervisory
is active	is active system trouble is active Figure 10-5 Event Display After Two Minutes Sitting Idle Figure 10-6 Interlock Release In Alarm After Two Minutes Sitting Idle This screen will display when more than 3 event types are active Figure 10-7 All System Display 10-11
Occurs When	System Behavior In This Mode You Can Mode
Normal	No alarm or SYSTEM POWER LED is on. Enter the appropriate code to activate the User or
trouble condition	The All Systems Normal display indicates that Installer Menu.
exists and	the system is in normal mode. menus are not in use. The current date and time display on the last line of the LCD.
A smoke	The dialer seizes control of the phone line and Press the down arrow to view the alarm. A screen
detector goes	calls the central station. similar to this one displays.
into alarm or a	The on-board annunciator will sound loud,
pull station is	steady beeps to distinguish Alarm signals. For
activated.	Fire Alarm, the sequence is a loud steady beep.(Any notification devices attached to the system will also sound). For ECS Alarm, the sequence is four seconds on, one second off. GENERAL ALARM LED is on. The LCD displays a screen similar to this one. Count of alarms. In this example, there Press SILENCE to silence the annunciator (and any
are 5 in fire and 1 in ECS.	notification devices attached to the system). When the alarm condition clears, press RESET to CO Detector goes restore the panel to normal. into alarm Press the down arrow to view the type
If more than 3	and location of alarm (Message
categories are	alternates with the date/time display).
time and ECS is	Note: Alarm and Prealarm are combined into single
enabled, top	alarm count screen will display. If ECS is not enabled, it will look like bottom screen. 10-12 Table 10-2: Operation Mode Behavior
The system	The dialer seizes control of the phone line and Press down arrow to view the fire supervisory
detects a	calls the central station. condition. A screen similar to this one displays.
supervisory	The on-board annunciator sounds a loud,
condition.	pulsing beep to distinguish supervisory signals. For Fire Supervisory the sequence is two seconds on, two seconds off. For ECS Supervisory, the sequence is two seconds on, three seconds off. SUPERVISORY LED is on. The LCD displays a screen similar to this one. Press SILENCE to silence the annunciator. After sitting idle, events will display in a screen similar to this:. The system detects a superv
A single detector Touchpad PZT beeps.	Press down arrow to view the prealarm. A screen trips in a 2-Count The LCD displays a screen similar to this one. similar to this one. zone. (2-Count means two detectors must trip before an alarm is reported.) All system operations are available in this mode. After sitting idle, events will display on a screen
Prealarm	similar to this: Note: Alarm and Prealarm are combined into a single alarm count. 10-14 Table 10-2: Operation Mode Behavior
The RESET	All LEDs are on briefly then the LCD displays Menus are not available during the reset process.
button is pressed	“RESET IN PROGRESS”. If the reset process
valid code, if	mode screen displays. necessary.
An alarm or	SYSTEM SILENCE LED is on. SYSTEM Press down arrow to view the location of the alarm,
has been	ALARM LED (depending on condition) is on. exists, the SYSTEM SILENCED and SYSTEM
silenced but still	The annunciator (and any notification devices TROUBLE LED, SUPERVISORY and/or GENERAL
exists. To silence	attached to the system) will be silenced. ALARM LEDs turn off. alarms and troubles, press SILENCE followed by the Installer or User Code, if necessary. 10.7 Multi-Site Annunciator and Multi-Site User Access Multi-site Annunciators are unique as they can display the status and event history of all sites they are assigned to. These displays can be especially useful in guard shacks or security center
Manufacturer	Part Number Rating Current Freq
Asco	T8210A107 24 VDC 3A max 0 Hz 8210G207 24 VDC 3A max 0 Hz Model 7641* must be mounted at the solenoid Releasing solenoid Use 24 VDC, UL listed model in table 10-3 1 solenoid per circuit Figure 10-8 Wiring Configuration for Solenoid *When ordering, order as P/N 7641-L8 10-16 10.8.1 Single Interlock Zone Releasing A single interlock zone utilizes a minimum of two addressable detectors and a designate
Inputs	Output Results 1st Addressable Detector X X X X 2nd Addressable Detector X X X X
Manual Release Station	X X X X Interlock Release Alarm and Detector Alarm Interlock Release Alarm and Detector Alarm Interlock Release Alarm and Detector Alarm Interlock Release Alarm and Detector Alarm Interlock Release Alarm and Detector Alarm Interlock Release Alert Interlock Release Alert Normal 10-17
ALL CALL	NON-ACTIVE CALL ECS Control ECS Control LED
Key	Key Key Select LEDs Message Keys Select Keys Message LEDs Figure 11-1 ECS-VCM / ECS-RVM Front View 11.2.2 Gaining ECS Control When attempting to gain ECS Control, there are three things that govern whether or not ECS Control can be obtained: 1. LOC Priority. 2. LOC Lockout. 3. User profile access control. 11.2.2.1 LOC Priority LOCs are assigned (through panel or Unimode 600PK programming of the EC
ECS Message Key 1	Select message slot to record to.
ECS Message Key 3	Start and stop recording from Aux. Audio Input
ECS Message Key 8	Erase user message 1-15
Select Keys 1-15	Message slot 1-15 While in the Local Record mode, Select Keys 1-15 will be used to reference message slots 1-15. The associated green Select Key LED will indicate that a message is currently programmed in the corresponding slot. When there is no message recorded (or the message is erased), the associated green Select Key LED will be off. While recording a particular message, the associated red Sel
LED	LED State Meaning
Select Key 1-15 Green LED	On Message is currently programmed in this slot
Select Key 1-15 Red LED	On Message recording is in progress
Select Key 1-15 Green/Red LED	Off/Off Message slot is empty
Press Select	Press ECS
Key 2 to record	Message Key 3
Message to	to start and top
this message	Recording from the
lot	Aux Audio Input Figure 11-6 Aux Audio Input Example 11.8.2 Recording Messages 1-15 Using the Microphone Messages can be recorded into the ECS system by using the onboard microphone. Follow these steps to use the microphone to record your message: 1. Enter programming mode at main control panel. 2. Select 5 for System Options. 3. Select 8 for ECS-VCM Maintenance. 4. Select 2 Local Recording. 5. Sel
Silent Knight	Model 9800 SIA and Contact ID
Model 9000 (SIA formats)	SIA
Ademco	Model 685 (Contact ID ) Contact ID
Sur-Gard	SG-MLR2-DG (V. 1.64 or higher) SIA and Contact ID
Osborne Hoffman	Quickalert SIA and Contact ID 12.2 Reporting Formats Table SIA Reporting Format Contact ID Reporting Format
SIA pi Modifier	SIA Unimode 600 Fixed Length Format NN - panel ID
SIA	XX- SBUS ID
Module ID	Event
Event Description	Event Parameter ZZZ - Zone # Qualifier Group # Contact #
# (If Any)	Code
System Events	Note: System Events are reported when either “Report by Point” or Report by Zone is selected
AC power low trouble	AT 0 ATNN000000 1 301 00 000
AC power low trouble restore	AR 0 ARNN000000 3 301 00 000
Auto dialer test communications	YC 1 YCNN000001 1 350 Receiv- 001
trouble line 1	er #
trouble line 1 restore	er #
trouble line 2	er #
trouble line 2 restore	er #
Automatic test normal	RP 0 RPNN000000 1 602 00 000
Automatic test off normal	RY 0 RYNN000000 1 608 00 000 12-1
Battery voltage trouble	YT Exp. ID YTNNXX0000 1 302 Exp. ID 000
Battery voltage trouble restore	YR Exp. ID YRNNXX0000 3 302 Exp. ID 000
Date changed event	JD 0 JDNN000000 1 625 00 000
ECS Reset	OR 1 ORNN000001 1 401 00 001
Emergency System Overridden	QS 0 QSNN000000 1 244 00 000
Fire drill has begun	FI 0 FINN000000 1 604 00 000
Fire drill has ended	FK 0 FKNN000000 3 604 00 000
F1 Mapping Inhibited	FT 2001 FTNN002001 1 570 00 001
F1 Mapping Inhibited Restoral	FJ 2001 FJNN002001 3 570 00 001
F2 Mapping Inhibited	FT 2002 FTNN002002 1 570 00 002
F2 Mapping Inhibited Restoral	FJ 2002 FJNN002002 3 570 00 002
F3 Mapping Inhibited	FT 2003 FTNN002003 1 570 00 003
F3 Mapping Inhibited Restoral	FJ 2003 FJNN002003 3 570 00 003
F4 Mapping Inhibited	FT 2004 FTNN002004 1 570 00 004
F4 Mapping Inhibited Restoral	FJ 2004 FJNN002004 3 570 00 004
Fire Reset	OR 0 ORNN000000 1 401 00 000
Fire System Overridden	FS 0 FSNN000000 1 245 00 000
Fire System Override Restore	FR 0 FRNN000000 3 245 00 000
Ground fault condition trouble	YP Exp. ID YPNNXX0000 1 310 Exp. ID 000
Initial power up	RR 0 RRNN000000 1 305 00 000
Local programming aborted or	LU 0 LUNN000000 1 628 00 000
Local programming begin	LB 0 LBNN000000 1 627 00 000
Local programming ended	LS 0 LSNN000000 1 628 00 000
Network node trouble (panel miss-	EM Panel ID EMNNNN0000 1 334 Panel ID 000
Network node trouble restore	EN Panel ID ENNNNN0000 3 334 Panel ID 000
OPG Inhibit Trouble	FT Group # + FTNN001GGG 1 320 00 Group # 1000
OPG Inhibit Trouble Restore	FJ Group # + FJNN001GGG 3 320 00 Group # 1000
OPG Inhibit of Releasing Group	SS Group # + SSNN001GGG 1 203 00 Group # 1000 12-2 SIA Reporting Format Contact ID Reporting Format
Phone line 1 trouble detected	LT 1 LTNN000001 1 351 00 000
Phone line 1 trouble restore	LR 1 LRNN000001 3 351 00 000
Phone line 2 trouble detected	LT 2 LTNN000002 1 352 00 000
Phone line 2 trouble restore	LR 2 LRNN000002 3 352 00 000
Printer is off-line trouble	VZ Exp. ID VZNNXX0000 1 336 Exp. ID 000
Printer is off-line trouble restore	VY Exp. ID VYNNXX0000 3 336 Exp. ID 000
Printer is out of paper trouble	VO Exp. ID VONNXX0000 1 335 Exp. ID 000
Printer is out of paper trouble re-	VI Exp. ID VINNXX0000 3 335 Exp. ID 000
Releasing Notif/Control Circuit	pi Exp. ID SS Point # SSNNXXPPPP 1 203 Exp. ID Point #
Remote programming aborted or	RU 0 RUNN000000 1 413 00 000
Remote programming ended nor-	RS 0 RSNN000000 1 412 00 000
Repeater ground fault trouble	EM 0103 EMNN000103 1 334 Panel ID 103
Repeater ground fault trouble re-	EN 0103 ENNN000103 3 334 Panel ID 103
Repeater missing trouble	EM 0100 EMNN000100 1 334 Panel ID 100
Repeater missing trouble restore	EN 0100 ENNN000100 3 334 Panel ID 100
Repeater Rx1 communication	EM 0101 EMNN000101 1 334 Panel ID 101
Repeater Rx2 communication	EM 0102 EMNN000102 1 334 Panel ID 102
SBUS Class A supervision lost	ET Exp. ID ETNNXX0000 1 333 Exp. ID 000
SBUS Class A supervision restore	ER Exp. ID ERNNXX0000 3 333 Exp. ID 000
SBUS expander trouble	ET Exp. ID ETNNXX0000 1 333 Exp. ID 000
SBUS expander trouble restore	ER Exp. ID ERNNXX0000 3 333 Exp. ID 000
SLC class A supervision trouble	ET Exp. ID ETNNXX0000 1 331 Exp. ID 000
SLC class A supervision trouble re-	ER Exp. ID ERNNXX0000 3 331 Exp. ID 000
SLC programming ended, system	TE 0 TENN000000 3 607 00 000 12-3
SLC programming started, system	TS 0 TSNN000000 1 607 00 000
SLC short circuit trouble	ET Exp. ID ETNNXX0000 1 332 Exp. ID 000
SLC short circuit trouble restore	ER Exp. ID ERNNXX0000 3 332 Exp. ID 000
Time changed event	JT 0 JTNN000000 1 625 00 000
Unable to report to account	RT Receiver # RTNN00RRRR 1 354 00 Receiv-
trouble	er #
trouble restore	er #
User access code changed	JV 0 JVNN000000 1 602 00 000
User initiated manual dialer test	RX 0 RXNN000000 1 601 00 000
Walk test begin	TS 0 TSNN000000 1 607 00 000
Walk test end	TE 0 TENN000000 3 607 00 000
Zone Events	Note: Zone events are reported only when “Report by Zone” is selected
Auxiliary power trouble	FT 0000 FTNN000000 1 320 00 000
Auxiliary power trouble restore	FJ 0000 FJNN000000 3 320 00 000
CO Detector Alarm	GA Zone # GANN000ZZZ 1 162 00 Zone #
CO Detector Alarm Restore	GH Zone # GHNN000ZZZ 3 162 00 Zone #
CO Detector Supervisory Alarm	GS Zone # GSNN000ZZZ 1 200 00 Zone #
CO Detector Trouble	GT Zone # GTNN000ZZZ 1 373 00 Zone #
CO Detector Trouble Restore	GJ Zone # GJNN000ZZZ 3 373 00 Zone #
Detector Alarm Restore	FH Zone # FHNN000ZZZ 3 110 00 Zone #
Detector trouble	FT Zone # FTNN000ZZZ 1 373 00 Zone #
Detector trouble restore	FJ Zone # FJNN000ZZZ 3 373 00 Zone #
ECS Switch Trouble	QT 0 QTNN000000 1 242 00 000
ECS Switch Trouble Restore	QJ 0 QJNN000000 3 242 00 000
ECS Supervisory/Tamper Alarm	QS 0 QSNN000000 1 241 00 000
ECS Output Group Trouble	QT Group # QTNN001GGG 1 320 00 Group # +1000
External Reset/Silence/Fire Drill	UT 0000 UTNN000000 1 373 00 000 12-4 SIA Reporting Format Contact ID Reporting Format
LOC Mic Activated ECS Alarm	QA 0 QANN000000 1 220 00 000
LOC/Point ECS # Alarm	QA Emergency QANN0E0000 1 220 + 00 000
LOC/Point ECS # Alarm Restore	QH Emergency QHNN0E0000 3 220 + 00 000
Manual pull switch alarm	FA Zone # FANN000ZZZ 1 115 00 Zone #
Manual pull switch alarm restore	FH Zone # FHNN000ZZZ 3 115 00 Zone #
Manual pull switch trouble	FT Zone # FTNN000ZZZ 1 373 00 Zone #
Manual pull switch trouble restore	FJ Zone # FJNN000ZZZ 3 373 00 Zone #
Notification output trouble	FT Group # + FTNN001GGG 1 320 00 Group # 1000
Notification output trouble restore	FJ Group # + FJNN001GGG 3 320 00 Group # 1000
Positive Alarm Sequence acknowl-	FT Zone # FTNN000ZZZ 1 373 00 Zone #
SLC LED Module trouble	ET 0000 ETNN000000 1 333 00 000
SLC LED Module trouble restore	ER 0000 ERNN000000 3 333 00 000
Status Point Types Trouble	UT 0 UTNN000000 1 379 00 000
Supervisory Detector Alarm	FS Zone # FSNN000ZZZ 1 200 00 Zone #
Supervisory/Tamper Alarm	FS Zone # FSNN000ZZZ 1 200 00 Zone #
Supervisory/Tamper alarm condi-	FR Zone # FRNN000ZZZ 3 200 00 Zone #
Supervisory/Tamper switch	FT Zone # FTNN000ZZZ 1 373 00 Zone #
System-based AUX1 switch alarm	UA 1000 UANN001000 1 140 01 000
System-based AUX1 switch trou-	UT 1000 UTNN001000 1 373 01 000
System-based AUX2 switch alarm	UA 2000 UANN002000 1 140 02 000
System-based AUX2 switch trou-	UT 2000 UTNN002000 1 373 02 000
Voice Aux ECS 1 Alarm	UA 3 UANN003000 1 171 00 000
Voice Aux ECS 1 Alarm Restore	UH 3 UHNN003000 3 171 00 000
Voice Aux ECS 2 Alarm	UA 4 UANN004000 1 172 00 000
Voice Aux ECS 2 Alarm Restore	UH 4 UHNN004000 3 172 00 000
Voice Aux ECS 3 Alarm	UA 5 UANN005000 1 173 00 000
Voice Aux ECS 3 Alarm Restore	UH 5 UHNN005000 3 173 00 000
Voice Aux ECS 4 Alarm	UA 6 UANN006000 1 174 00 000
Voice Aux ECS 4 Alarm Restore	UH 6 UHNN006000 3 174 00 000
Water flow switch alarm	SA Zone # SANN000ZZZ 1 113 00 Zone #
Water flow switch alarm Restore	SH Zone # SHNN000ZZZ 3 113 00 Zone #
Water flow switch trouble	ST Zone # STNN000ZZZ 1 373 00 Zone #
Water flow switch trouble Restore	SJ Zone # SJNN000ZZZ 3 373 00 Zone #
Zone-based AUX1 switch alarm	UA Zone # + UANN001ZZZ 1 140 01 Zone # 1000
restore	1000
Zone-based AUX1 switch trouble	UT Zone # + UTNN001ZZZ 1 373 01 Zone # 1000
Zone-based AUX2 switch alarm	UA Zone # + UANN002ZZZ 1 140 02 Zone # 2000
Zone-based AUX2 switch trouble	UT Zone # + UTNN002ZZZ 1 373 02 Zone # 2000
Point Events	Note: For LiteSpeed devices, sensors 1–159 are reported as Points 1–159, modules 1–159 are reported as Points 201–359.
An unexpected SLC device has	pi Exp. ID XE Point # XENNXXPPPP 1 380 Exp. ID Point #
Auxiliary power disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Auxiliary power enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Auxiliary power Trouble	pi Exp. ID FT Point # FTNNXXPPPP 1 320 Exp. ID Point #
Background Music Switch is	pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
CO Detector Disabled	pi Exp. ID GB Point # GBNNXXPPPP 1 571 Exp. ID Point #
CO Detector Enabled	pi Exp. ID GU Point # GUNNXXPPPP 3 571 Exp. ID Point #
Detector Alarm restore	pi Exp. ID FH Point # FHNNXXPPPP 3 110 Exp. ID Point #
Detector Disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Detector Enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Detector Trouble	pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
Detector Trouble restore	pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
Detector CO Alarm	pi Exp. ID GA Point # GANNXXPPPP 1 162 Exp. ID Point #
Detector CO Alarm Restore	pi Exp. ID GH Point # GHNNXXPPPP 3 162 Exp. ID Point #
Detector CO Supervisory Alarm	pi Exp. ID GS Point # GSNNXXPPPP 1 200 Exp. ID Point #
ECS Alarm # Point Alarm	pi Exp. ID QA (EPPP) E - QANNXXEPPP 1 220 + Exp. ID Point #
Emergency #	Emer-
PPP - Point #	gency #
ECS Alarm # Point Alarm Restore	pi Exp. ID QH (EPPP) E - QHNNXXEPPP 3 220 + Exp. ID Point #
ECS Alarm # Point Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point # 12-7
ECS Alarm # Point Trouble Re-	pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Alarm # Point Disabled	pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Alarm # Point Enabled	pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS Supervisory/Tamper Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Supervisory/Tamper Dis-	pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS NAC Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS NAC Trouble Restored	pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Control Circuit Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS Control Circuit Trouble Re-	pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Relay Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS Relay Trouble Restored	pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Notification Trouble	pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
Interlock switch alarm (Water Re-	pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
Interlock switch disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Interlock switch enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Interlock switch trouble restore	pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
LOC ECS # Alarm	pi Exp. ID QA Emergency # QANNXXE000 1 220 + Exp. ID 000 Emer- gency #
LOC ECS # Alarm Restore	pi Exp. ID QH Emergency # QHNNXXE000 3 220 + Exp. ID 000 Emer- gency #
Manual pull switch disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Manual pull switch enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Manual release switch alarm	pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
Manual release switch alarm re-	pi Exp. ID FH Point # FHNNXXPPPP 3 110 Exp. ID Point #
Manual release switch disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Manual release switch enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Manual release switch trouble	pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
Manual release switch trouble re-	pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
Notification output point disabled	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Notification output point enabled	pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Notification output point trouble	pi Exp. ID FT Point # FTNNXXPPPP 1 320 Exp. ID Point #
Status Point Trouble	pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Status Point Trouble Restored	pi Exp. ID UJ Point # UJNNXXPPPP 3 379 Exp. ID Point #
Status Point is Disabled	pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
Status Point is Enabled	pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point # 12-9
Supervisory/Tamper point dis-	pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Supervisory/Tamper point trouble	pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
System-based AUX1 switch dis-	pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
System-based AUX1 switch en-	pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
System-based AUX2 switch dis-	pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
System-based AUX2 switch en-	pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
System-based AUX2 switch	pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Voice Aux ECS 1 Point Alarm	pi Exp. ID UA (3PPP) PPP UANNXX3PPP 1 171 Exp. ID Point # - Point #
Voice Aux ECS 2 Point Alarm	pi Exp. ID UA (4PPP) PPP UANNXX4PPP 1 172 Exp. ID Point # - Point #
Voice Aux ECS 3 Point Alarm	pi Exp. ID UA (5PPP) PPP UANNXX5PPP 1 173 Exp. ID Point # - Point # 12-10 SIA Reporting Format Contact ID Reporting Format
Voice Aux ECS 4 Point Alarm	pi Exp. ID UA (6PPP) PPP UANNXX6PPP 1 174 Exp. ID Point # - Point #
Voice Aux ECS Point Trouble	pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Voice Aux ECS Point Disabled	pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
Voice Aux ECS Point Enabled	pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point #
Voice Aux Status 1 Switch is	pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Voice Aux Status 2 Switch is	pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Water flow switch alarm restore	pi Exp. ID SH Point # SHNNXXPPPP 3 113 Exp. ID Point #
Water flow switch disabled	pi Exp. ID SB Point # SBNNXXPPPP 1 571 Exp. ID Point #
Water flow switch enabled	pi Exp. ID SU Point # SUNNXXPPPP 3 571 Exp. ID Point #
Water flow switch trouble restore	pi Exp. ID SJ Point # SJNNXXPPPP 3 373 Exp. ID Point #
EE	Event code (2 characters) ZZZZ Event parameter (up to four digits – not zero filled) 1. The account number is sent using an account block that is separate from the event block 2. Multiple events can be sent within a single event block. Events are separated by a “/” character. 3. Event parameter can be either a zone, point or module number. 4. When reporting by point is enabled, the dialer uses a “
Fire Alarm-Zone	Zone n/a n/a97 15 n/a EE-ZZ FA15
Fire Alarm-Point	Point n/a 01 n/a 123 EE-ZZ /EE- pi01/FA123 ZZZ
Expander Trouble	n/a n/a 11 n/a n/a EE-ZZ ET11
Auto Test	n/a n/a n/a n/a n/a EE-Z RP0
Battery Trouble-Panel 32	n/a n/a 98 n/a n/a EE-ZZ YT98
Battery Trouble-Expander	n/a n/a 18 n/a n/a EE-ZZ YT18
SLC Loop Shorted	n/a n/a 44 n/a n/a EE-ZZ ET44
Program Begin Panel	n/a n/a n/a n/a n/a EE-Z LB0 ID=32
Program Begin Panel ID=	n/a n/a n/a n/a n/a EE-Z LB0
AC Power Loss - Panel 22	n/a n/a 98 n/a n/a EE-Z AT0
Fire Trouble	Point n/a 97 n/a 200 EE-ZZ /EE- pi97/FT200 ZZZ
Fire Trouble-Nac	Point n/a 98 n/a Nac EE-ZZ /EE- pi98/FT7
Circuit 7	Z Z=Pt. #
PP	Panel number (2 digits – Zero Filled) (valid range from 1 to 64)
MM	Module number (2 digits – Zero Filled) (valid range from 1 to 98, typically Module information) ZZZZ Event parameter (4 digits – Zero Filled) (typically Point, Zone or Circuit information) 1. The Event field will contain 10 digits including the 2 digit event code (EE), 2 digit panel ID (PP), 2 digit Module Number (MM) and a 4 digit Event Parameter (ZZZZ). 2. Based on the actual Event Code, the Mod
Battery Trouble-Expander 18	n/a 32 18 n/a n/a EE-PP-MM-ZZZZ YT32180000
Program Begin	n/a 32 n/a n/a n/a EE-PP-MM-ZZZZ LB32000000
AC Power Loss- Panel 22	n/a 22 98 n/a n/a EE-PP-MM-ZZZZ AT22980000 MM = 00
Problem	Possible Cause / Suggested Actions
Trouble message "DBL ADDR" (Double	An address has been assigned to more than one detector. Correct the address
Address) displays on LCD.	following the procedure described in Section 7.5 if using LiteSpeed devices
Auxiliary power or notification circuits	Correct polarity. For notification and auxiliary power circuits: When in alarm or powered,
have incorrect polarity.	terminals labeled “X” are positive, terminals labeled “O” are negative.
SLC devices are not being recognized	Check hardware connections. (trouble message "Missing" displays). If devices are physically connected, make sure wiring is correct (Section 7.4 if using LiteSpeed devices). For 5815XL devices, make sure the device connects to the 5815XL via the SLC OUT terminals. There can be only one SLC loop on the main panel and on each 5815XL module. Do not connect devices to terminals labeled SLC IN. Make sur
The panel indicates a ground fault	An earth ground fault occurs when the panel senses an unexpected flow of current from
trouble condition (trouble message	one or more of its terminals to the earth connection (Terminal 2).
"GROUND FAULT" displays).	Isolate the wiring that is causing the fault by removing wiring connections one at a time until the earth fault is no longer present. Pause at least five seconds after removing a wire before removing the next one. 13-1
