| Leakage rate | 1% of kvs Internal threads / flange in accordance with DIN EN 1092-2 |
|---|
| Ports | depending on type (see section "Specification and Order Number" on page 2) |
|---|
| Angle of rotation | 90 ° |
|---|
| Internal threads | 8 windings long |
|---|
| APPLICATION | Packing Double o-ring sealing |
|---|
| Material body | Cast iron Heating water according to VDI 2035 (oxygen concentration less than 0.2 g/m , pH 8...9.5), glycol-water Water temperatures in the valve |
|---|
| M7061/VRM actuators. | depend on type (see sections "Dimensions with DRxxGMLA (mm)" Weight and "Dimensions with DRxxxGFLA (mm)" on page 3) |
|---|
| Flow characteristic | equal percentage |
|---|
| ® U.S. Registered Trademark | EN0B-0607GE51 R0711 torque [Nm] for |
|---|
| kVS | ∆p max nominal OS no. OS no. |
|---|
| DN | reduced ∆p (40 |
|---|
| [m³/h] | [kPa] torque [Nm] internal thread flange kPa) 15 4,0 100 10 DR15GMLA – 10 20 6,3 100 10 DR20GMLA DR20GFLA 10 25 10 100 10 DR25GMLA DR25GFLA 10 32 16 100 10 DR32GMLA DR32GFLA 10 40 25 100 20 DR40GMLA DR40GFLA 10 50 40 100 20 – DR50GFLA 20 65 63 100 20 – DR65GFLA 20 80 100 100 30 – DR80GFLA 20 100 160 100 40 – DR100GFLA 30 125 250 70 40 – DR125GFLA 30 150 630 50 40 – DR150GFLA 40 200 1600 50 40 – DR |
|---|
| OS no. | OS no. OS no. torque [Nm] 24 Vac floating 230 Vac floating 0/2...10 V 10 M6061A1013 M6061L1019 M7061E1012 20 M6061A1021 / VMM20-24 M6061L1027 / VMM20 M7061E1020 / VRM20 30 M6061A1039 / VMM30-24 M6061L1035 / VMM30 – 40 M6061A1047 / VMM40-24 M6061L1043 / VMM40 – 40 VMM40-24F VMM40F – |
|---|
| OPERATION | MOUNTING |
|---|
| characteristics. | C° |
|---|
| R | L |
|---|
| L | R |
|---|
| EN0B-0607GE51 R1110 | 2 |
|---|
| 類型 | DN a c SW h i net weight |
|---|
| DR15GMLA | 15 110 179 41 55 R ½ in. 2.2 kg |
|---|
| DR20GMLA | 20 110 179 46 55 R ¾ in. 2.3 kg |
|---|
| DR25GMLA | 25 115 179 50 58 R 1 in. 2.4 kg |
|---|
| DR32GMLA | 32 140 188 60 70 R 1 ¼ in. 4.1 kg |
|---|
| DR40GMLA | 40 150 188 65 75 R 1 ½ in. 4.3 kg |
|---|
| a | i |
|---|
| DR20GFLA | 20 140 15 179 90 70 3.5 kg |
|---|
| DR25GFLA | 25 150 15 179 100 75 4.0 kg |
|---|
| DR32GFLA | 32 160 17 188 120 80 6.6 kg |
|---|
| DR40GFLA | 40 170 16 188 130 85 7.1 kg |
|---|
| DR50GFLA | 50 190 16 202 140 95 9.8 kg |
|---|
| DR65GFLA | 65 210 16 219 160 105 12.3 kg |
|---|
| DR80GFLA | 80 250 18 219 190 125 21.4 kg |
|---|
| DR100GFLA | 100 270 18 240 210 135 26.5 kg |
|---|
| DR125GFLA | 125 310 20 267 240 155 42.0 kg |
|---|
| DR150GFLA | 150 330 20 274 265 165 49.0 kg |
|---|
| DR200GFLA/ DR200GFLA1 | 200 390 22 314 320 195 78.0 kg |
|---|
