| SIZE | 5.1 x 2.8 x 2.0 in. / 13.1 x 7.0 x 5.2 cm STANDARD MEASURING |
|---|
| 重量 | 11.5 oz. / 328 g |
|---|
| GASES | RANGE RESOLUTION |
|---|
| 工作溫度 | -4 to 122ºF / -20 to 50ºC |
|---|
| HYDROGEN SULFIDE (H2S) | 0 - 200 ppm 1 / 0.1 ppm |
|---|
| HUMIDITY | 10 - 100% RH (non-condensing) |
|---|
| CARBON MONOXIDE (CO) | 0 - 1,000 ppm 1 ppm |
|---|
| ALARMS AND TYPE | Visual, vibrating, audible (95 dB); Low, High, TWA, |
|---|
| OXYGEN (O2) | 0 - 30% vol. 0.1% vol. STEL, OL (over limit), Low Battery, Pump |
|---|
| COMBUSTIBLE GASES (LEL) | 0 - 100% LEL 1% LEL |
|---|
| SELF-TEST | Audible/visual alarms on activation, sensors, 0-5.0% v/v 0.1% v/v battery, pump and circuitry (continuous) |
|---|
| TYPICAL BATTERY LIFE | 13 hours @ 32ºF / 0ºC Alarm setpoints for all sensors are user adjustable. Setpoint(s) 8 hours @ -4ºF / -20ºC are automatically displayed during instrument start-up. Recharges in 6 hours |
|---|
| PUMP DRAW | Sample from up to 75 ft. / 23 m OPTIONS AND ACCESSORIES Note: Do not attempt to calibrate a Honeywell BW™ Max XT with tubing longer than the standard calibration tubing supplied with the detector. |
|---|
| USER OPTIONS | • Confidence beep • Force calibration when overdue MicroDock II Compatible |
|---|
| • Safety (sensor) lock | • Sensor configuration Automatic test and calibration station |
|---|
| • Latching alarms | • Detector identification |
|---|
| • Safe display mode | • Low alarm acknowledge |
|---|
| • Calibration IR lock | • Language choices (five) |
|---|
| • Location selection | • Set custom start-up message |
|---|
| • Force block test | • Confidence interval |
|---|
| • Force bump test when overdue | • Datalog interval Concussion-proof boot |
|---|
| RATINGS | EMI/RFI: Complies with EMC Directive 2004/108/EC |
|---|
| 防護等級 | IP66/67 |
|---|
| CERTIFICATIONS AND | h: Class I, Div. 1, Gr. A, B, C, D Honeywell BW™ Connect* |
|---|
| APPROVALS | Real-Time Monitoring |
|---|
| IECEx : | Ga Ex ia IIC T4 |
|---|
| ATEX : | X g II 1 G Ga Ex ia IIC T4 *Contact Honeywell Analytics for availability |
|---|
| : | Br Ex ia IIC T4 |
|---|
| WARRANTY | Full two year warranty including all sensors Multi-unit cradle charger |
|---|
| US: ha.us.service@honeywell.com | Datasheet_Max XT II_DS01105-07_US-EN | 04/18 |
|---|
| AP: ha.ap.service@honeywell.com | ©2018 Honeywell International Inc. |
|---|
