| IP 視頻輸入 | 4-ch 8-ch |
|---|
| Analog Video Input | 4-ch, BNC 8-ch, BNC |
|---|
| Max IP Video Input | 8-ch 16-ch Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support TVI input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support CVI input: 8MP@15fps 5MP@25fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input |
|---|
| BNC Audio Input | 4-ch, channel audio 8-ch, channel audio |
|---|
| RCA Audio Input | 1-ch HDMI: 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|---|
| BNC Video Output | 1-ch |
|---|
| RCA Audio Output | 1-ch |
|---|
| Live View Display | HDMI/VGA: 1/4/6/8/9 HDMI/VGA: 1/4/6/8/9/16 |
|---|
| Playback Screen | 1/4 1/4/9/16 |
|---|
| 錄影解像度 | 8MP/5MP/4MP/1080P/720P/D1 Main stream: 8MP@8fps Sub stream: D1@8fps Main stream: 5MP@12fps Sub stream: D1@12fps Main stream: 4MP@15fps Sub stream: D1@15fps Main stream: 1080P@25fps Sub stream: D1@25fps Main stream: 720P@30fps Sub stream: D1@30fps |
|---|
| Audio Sample Rate | 8 kHz, 16 bit per channel |
|---|
| 音訊碼率 | 64 Kbps per channel Analog: 4 x 8MP @8, 4 x 5MP @12, 4 x 4MP @15, Analog: 8 x 8MP @8, 8 x 5MP @12, 8 x 4MP @15, 4 x 1080P@25, 4 x 720@30 8 x 1080P@25, 8 x 720@30 IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30, 8 x IP: 2 x 8MP@30, 4 x 4MP@30, 8 x 1080P@30, 16 720P@30 x 720P@30 8-ch 16-ch |
|---|
| Audio over Coaxial | 4-ch, One-way Audio(TVI UNV )/One-way 8-ch, One-way Audio(TVI UNV )/One-way |
|---|
| Cable(Form) | Audio(CVI UNV) Audio(CVI UNV) |
|---|
| 雙向語音 | 1-ch, RCA (Using the audio input and output) |
|---|
| FTP/Schedule/Event | Schedule/FTP/Event snapshot:4-ch snapshot, Schedule/FTP/Event snapshot:8-ch snapshot, |
|---|
| Snapshot | up to 704*576 resolution up to 704*576 resolution 40Mbps (Up to 48Mbps after all analog channel 80Mbps (Up to 96 Mbps after all analog |
|---|
| conversion) | channel conversion) |
|---|
| 出口頻寬 | 64Mbps 160Mbps |
|---|
| Remote Users | 128 |
|---|
| 網絡協議 | TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP |
|---|
| Browser(Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ Ultra Motion Detection (UMD) |SIP (Intrusion Ultra Motion Detection (UMD) |SIP (Intrusion |
|---|
| Analog Smart by XVR | Detection, Cross Line Detection, Enter Area, Detection, Cross Line Detection, Enter Area, |
|---|
| Leave Area)|Face Detection | Leave Area) Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Defocus Detection, Scene Change Detection, Object Removed, Object Left Behind, Auto Tracking |
|---|
| VCA Search | Face Search, Behavior Search |
|---|
| Smart Functions by XVR | 4-ch (UMD)|2-ch (SIP)|1-ch (Face Detection) 8-ch (UMD)|4-ch (SIP) |
|---|
| Smart Functions by IP Camera | 2-ch (SIP) 4-ch (SIP) |
|---|
| General Alarm | Motion IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, |
|---|
| GUI Language | Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
|---|
| SATA | 1 SATA interface |
|---|
| 容量 | Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature) 1 RJ45 10 M/100 M self-adaptive Ethernet 1 RJ45 10 M/100 M/1000 M self-adaptive |
|---|
| 接口 | Ethernet Interface |
|---|
| USB | Rear panel: 2 × USB2.0 Rear panel: 1 × USB2.0, 1 × USB3.0 |
|---|
| RS485 | 1 |
|---|
| RS232 | N/A |
|---|
| Alarm In | 4-ch |
|---|
| Alarm Out | 1-ch |
|---|
| 供電 | DC 12 V/2 A |
|---|
| 工作溫度 | -10 ℃ to 55 ℃ (14 ℉ to 131 ℉ ) |
|---|
| 工作濕度 | ≤ 90% RH (non-condensing) |
|---|
| ≤ 10W | ≤ 12W |
|---|
| Weight (without HDD) | ≤1.1 Kg ( 2.42lb ) ≤1.2 Kg ( 2.65lb ) |
|---|
| 尺寸 | 260mm ×251mm× 46mm (10.2" × 9.9"×1.8") |
|---|
| Certification | CE, FCC, UL, RoHS, WEEE |
|---|
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2 |
|---|
| FCC | Part15 Subpart B RM-1U-260 1 HDD 1U NVR Rack Mount Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
