| Camera | Gain Control Auto/Manual |
|---|
| 影像感測器 | 1/3” 4Megapixel progressive scan CMOS Noise Reduction 3D DNR |
|---|
| Effective Pixels | 2688(H)x1520(V) Motion Detetion Off / On (4 Zone, Rectangle) |
|---|
| RAM/ROM | 512MB/32MB |
|---|
| Region of Interest | Off / On (4 Zone) |
|---|
| Scanning System | Progressive Electronic Image Stabilization |
|---|
| Electronic Shutter Speed | Auto/Manual, 1/3~1/100000s N/A (EIS) 0.06Lux/F1.6( Color,1/3s,30IRE) |
|---|
| Smart IR | Support |
|---|
| Minimum Illumination | 0.4Lux/F1.6( Color,1/30s,30IRE) 0Lux/F1.6(IR on) |
|---|
| 除霧 | N/A |
|---|
| S/N Ratio | More than 50dB |
|---|
| Digital Zoom | 16x |
|---|
| IR Distance | Distance up to 80m (262.5ft) |
|---|
| Flip | 0°/90°/180°/270° |
|---|
| IR On/Off Control | Auto/ Manual |
|---|
| IR LEDs | 4 Mirror Off / On |
|---|
| 鏡頭 | Privacy Masking Off / On (4 Area, Rectangle) |
|---|
| 鏡頭類型 | Fixed Audio |
|---|
| Mount Type | Board-in Compression G.711a/ G.711Mu/ AAC/ G.726 |
|---|
| 焦距 | 3.6mm (6mm, 8mm, 12mm optional) |
|---|
| Max. Aperture | F1.6 (F1.6, F1.6, F1.6) |
|---|
| Ethernet | RJ-45 (10/100Base-T) |
|---|
| Angle of View | H: 83° (55°, 38°, 25°), V: 45° (31°, 21°, 14°) HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; |
|---|
| Optical Zoom | N/A FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; |
|---|
| Focus Control | Fixed IGMP; SNMP |
|---|
| Close Focus Distance | 1.5m (3.1m, 3.6m, 10.8m) |
|---|
| Interoperability | ONVIF, PSIA, CGI |
|---|
| Streaming Method | Unicast / Multicast 3.6 mm 80m(262ft) 32m(105ft) 16m(52ft) 8m(26ft) |
|---|
| DORI Distance | 6.0 mm 120m(394ft) 48m(157ft) 24m(79ft) 12m(39ft) Max. User Access 10 Users /20 Users 8.0 mm 110m(361ft) 44m(144ft) 22m(72ft) 11m(36ft) NAS |
|---|
| Edge Storage | Local PC for instant recording 12.0mm 250m(820ft) 100mm(328ft) 50m(164ft) 25m(82ft) Mirco SD card 128GB |
|---|
| Pan/Tilt/Rotation | Web Viewer IE, Chrome, Firefox, Safari |
|---|
| Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ Management Software Smart PSS, DSS, Easy4ip |
|---|
| Intelligence | Smart Phone IOS, Android |
|---|
| IVS | Tripwire, Intrusion, Object Abandoned/Missing Certifications Advanced Intelligent Functions Face Detection CE (EN 60950:2000) |
|---|
| Certifications | UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|---|
| Compression | H.265+/H.265/H.264+/H.264 Interface |
|---|
| Video Interface | N/A |
|---|
| Streaming Capability | 3 Streams |
|---|
| Audio Interface | 1/1 channel In/Out 4M(2688×1520)/3M(2304×1296)/ 1080P(1920×1080)/1.3M(1280x960)/ RS485 N/A Resolution 720P(1280×720)/D1(704×576/704×480)/ |
|---|
| VGA(640×480)/CIF(352×288/352×240) | 1 channel In: 5mA 5VDC Alarm 1 channel Out: 300mA 12VDC Main Stream: 4M(1~25/30fps) Electrical |
|---|
| Frame Rate | Sub Stream: D1(1~25/30fps) |
|---|
| 供電 | DC12V, PoE (802.3af)(Class 0) Third Stream: 720P(1~25/30fps) DC12V: 3.2W, 10.1W(IR On) |
|---|
| 碼率控制 | CBR/VBR Power Consumption PoE: 3.9W, 12W(IR On) H.264: 24K ~ 10240Kbps Bit Rate H.265: 14K ~ 9984Kbps www.dahuasecurity.com Day/Night |
|---|
| Environmental | Auto(ICR) / Color / B/W Accessories |
|---|
| BLC Mode | BLC / HLC / WDR(120dB) |
|---|
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Optional: |
|---|
| Strorage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
|---|
| 防護等級 | IP67 |
|---|
| Vandal Resistance | IK10 Construction |
|---|
| Casing | Metal |
|---|
| PFA135 | PFA152-E LR1002 |
|---|
| 尺寸 | 244.1mm×79mm×75.9mm (9.61”×3.11”×2.99”) Junction Box Pole Mount ePoE Over Coax Converter |
|---|
| 淨重 | 0.815kg (1.80lb) |
|---|
| 毛重 | 1.08kg (2.38lb) |
|---|
| Juncon Mount | Pole Mount |
|---|
| 類型 | Part Number Description |
|---|
| DH-IPC-HFW4431TP- | 4MP IR Mini Bullet Network Camera, |
|---|
| ASE | WDR, PAL |
|---|
| DH-IPC-HFW4431TN- | 4MP IR Mini Bullet Network Camera, |
|---|
| PFA152-E | Pole Mount (optional) |
|---|
| LR1002 | ePoE Over Coax Converter Dimensions (mm/inch) www.dahuasecurity.com |
|---|
