| 解碼格式 | Ultra 265, H.265, H.264 |
|---|
| Smart Off: 2 x 16MP@30, 2 x 12MP@30, 4 x | Smart Off: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30 4K@30, 8 x 4MP@30 |
|---|
| Smart On: 2 x 12MP@30, 2 x 4K@30, 4 x | Smart On: 2 x 12MP@30, 2 x 4K@30, 6 x 4MP@30 4MP@30, 8 x 3MP@30 The resolution of each channel cannot exceed 8192 pixels in length and 4096 pixels in width |
|---|
| 音訊壓縮 | G.711A, G.711U |
|---|
| 入口頻寬 | 80 Mbps |
|---|
| 出口頻寬 | 80 Mbps |
|---|
| Remote Users | 128 |
|---|
| TCP/IP, P2P, | NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4 |
|---|
| Browser (Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
|---|
| IP 視頻輸入 | 4-ch 8-ch |
|---|
| RCA Audio Input | 1-ch |
|---|
| Ip Speaker | 16-ch |
|---|
| POS | All channels |
|---|
| Video Output | Support 1-ch HDMI, 1-ch VGA, HDMI and VGA simultaneous output 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|---|
| RCA Audio Output | 1-ch |
|---|
| Liveview Display | 1/4 1/4/6/8/9 |
|---|
| Corridor Mode Screen | 3/4 3/4/5/7/9 |
|---|
| 雙向語音 | 1-ch, RCA (Using the audio input and output) 4-ch snapshot (max. 8 MP (3840 × 2160) video resolution, with 1080P snapshot resolution) |
|---|
| 錄影解像度 | 16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF |
|---|
| Num of Concurrent Playback | 16-ch All channels (up to 8 images/s in total) Face Detection, Face Comparison, Vehicle Detection (LPR), Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring Face Detection, Face Comparison, Smart Intrusion Prevention (SIP), Ultra Motion Detection (UMD) Single Mode (Face Recognition), Single Mode (SIP), Single Mode (UMD), Single Mode (AcuSearch/AcuTrack), Modes cannot active simulta |
|---|
| VCA Search | Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map |
|---|
| Acu Search Performance | All channels with UNV SIP/UMD Camera |
|---|
| Acu Track Performance | All channels with UNV SIP/UMD Camera |
|---|
| Up to 4-ch with UNV Face Detection | Up to 8-ch with UNV Face Detection |
|---|
| by NVR | Camera|Up to 2-ch with normal camera (UNV Camera|Up to 2-ch with normal camera (UNV |
|---|
| and Third-part brand, 2-ch 2MP, 1-ch 4MP) | and Third-part brand, 2-ch 2MP, 1-ch 4MP) |
|---|
| Vehicle Number Library | Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total Up to 4-ch with normal camera (UNV and Third-part brand, 4-ch 2MP, 2-ch 4MP, 1-ch 4K) |
|---|
| UMD by NVR with normal | Up to 4-ch with normal camera (UNV and Up to 8-ch with normal camera (UNV and |
|---|
| cameras | Third-part brand, 4-ch 2MP, 2-ch 4MP, 1-ch 4K) Third-part brand, 8-ch 2MP, 4-ch 4MP, 2-ch 4K) |
|---|
| Capacity of Snapshot Records | 500 thousand records for face snapshot, One and a half millions records for SIP and vehicle Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recor |
|---|
| GUI Language | Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
|---|
| SATA | 1 SATA Interface Up to 24 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size, The environment temperature for use should not exceed 35°C.) |
|---|
| 網絡接口 | 1 RJ45 10 M/100 M self-adaptive Ethernet Interface |
|---|
| USB | Front panel: 1 × USB2.0, Rear panel: 1 × USB3.0 |
|---|
| RS485 | N/A |
|---|
| RS232 | N/A |
|---|
| Alarm In | N/A |
|---|
| Alarm Out | N/A |
|---|
| 供電 | DC 48 V/1.35 A DC 52 V/1.8 A 4 RJ45 10 M/100 M self-adaptive Ethernet 8 RJ45 10 M/100 M self-adaptive Ethernet |
|---|
| 接口 | Interface |
|---|
| Max Power | Max 30 W for single port, Max 50 W in total Max 30 W for single port, Max 75 W in total |
|---|
| Supported Standard | IEEE 802.3at, IEEE 802.3af |
|---|
| 工作溫度 | -10 ℃ to 50 ℃ (14 ℉ to 122 ℉) |
|---|
| 工作濕度 | ≤ 90% RH (non-condensing) ≤ 8W |
|---|
| Weight (without HDD) | ≤ 1Kg (2.2lb) |
|---|
| Height | 1U |
|---|
| 尺寸 | 205mm ×212mm × 46.6mm (8.1" ×8.3" ×1.8" ) 270mm ×210mm × 46.6mm (10.6" ×8.3" ×1.8" ) |
|---|
| Certification | CE; FCC; UL; RoHS; WEEE |
|---|
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
|---|
| FCC | Part15 Subpart B Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
