| 解碼格式 | Ultra 265, H.265, H.264 Smart Off: H265: 6 x 4K@30, 8 x 6MP@30, 10 x 5MP@30, 12 x 4MP@30, 16 x 3MP@30, 25 x 1080P@30, 32 x 720P@30, 64 x D1@30 |
|---|
| 解碼能力 | H264: 6 x 4K@30, 8 x 6MP@30, 10 x 5MP@30, 12 x 4MP@30, 16 x 3MP@30, 25 x 1080P@30, 32 x 720P@30, 64 x D1@30 |
|---|
| Smart On: When Smart by NVR on, | the decoding capacity is same as Smart off. The resolution of each channel cannot exceed 4096 pixels in length or width| For VGA/HDMI |
|---|
| Description | output by default. To output the highest resolution video from the HDMI port, please clear the VGA video on the preview page. |
|---|
| 音訊壓縮 | G.711A, G.711U |
|---|
| 入口頻寬 | 512 Mbps |
|---|
| 出口頻寬 | 512 Mbps |
|---|
| Max Users Can Be Added | 128 |
|---|
| Max Remote Users | 128 TCP/IP|P2P|SMTP|RTSP| UPnP| NTP| DHCP| |
|---|
| 網絡協議 | PPPoE| HTTP| DNS| DDNS| IPv6|IPv4|HTTPS| SNMP |
|---|
| Browser (Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
|---|
| Browser (Plugin-Free) | Chrome 57+, Edge 16+, Firefox 58+, Safari 11+ |
|---|
| IP 視頻輸入 | 64-ch |
|---|
| BNC Audio Input | N/A |
|---|
| RCA Audio Input | 1-ch |
|---|
| Ip Speaker | 16-ch |
|---|
| POS | All channels Support 3-ch HDMI, 1-ch VGA, HDMI1 and VGA |
|---|
| Video Output | simultaneous output, HDMI1 /VGA and HDMI2 and HDMI3 independent output. 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1280 × 720/60 Hz |
|---|
| VGA 輸出 | 1920 × 1080/60 Hz, 1280 × 720/60 Hz |
|---|
| HDMI Standard | HDMI1.4 |
|---|
| BNC Audio Output | N/A |
|---|
| RCA Audio Output | 3-ch HDMI1 and VGA: 1/4/6/8/9/16/25/36/64 |
|---|
| Liveview Display | HDMI2: 1/4/6/8/9/16/25/36 HDMI3: 1/4/6/8/9/16/25/36 |
|---|
| Default Num of Live Screen | HDMI1 and VGA: 64; HDMI2: 36; HDMI3: 36 |
|---|
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
|---|
| Playback Screen | 1/4/9/16 1/3 |
|---|
| 雙向語音 | 1-ch, RCA (Using the audio input and output) 32 MP/16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF |
|---|
| Num of Concurrent Playback | 32-ch 16-ch All channels (up to 16 images/s in total) Face Detection, Face Comparison, Vehicle Detection (LPR), Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring, People Counting Face Detection|Face Comparison|Smart Intrusion Prevention (SIP)|Video Metadata|Plate Comparison|Illegally Parked Motor Vehicle|Ultra Motion Detection (UMD)|People Counting (People Flow Counting, Crowd De |
|---|
| VCA Search | AcuSearch|AcuTrack|Face Snapshot Search|Face Comparison Search|Motor Vehicle Search|Non-Motor Vehicle Search|Human Body Search|General Search|People Counting Report|Behavior Search|SmartSearch+|Heat Map All channels with UNV SIP/UMD Camera|Up to |
|---|
| Acu Search Performance | 16-ch with normal camera (UNV and Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) All channels with UNV SIP/UMD Camera|Up to |
|---|
| Acu Track Performance | 16-ch with normal camera (UNV and Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) All channels with UNV SIP/UMD Camera|Up to |
|---|
| SeekFree Performance | 16-ch with normal camera (UNV and Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) |
|---|
| SeekFree Language | English Up to 32-ch with UNV Face Detection Camera|Up to 16-ch with normal camera (UNV and Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) |
|---|
| Search by Image | Support Up to 16-ch with normal camera (UNV and Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) N/A Up to 16-ch with normal camera (UNV and |
|---|
| analysis with normal cameras | Third-part brand, 16-ch 2MP, 8-ch 4MP, 4-ch 4K) No Helmet Detection|No Chef Hat Detection|No Work Clothes Detection|Smoking Detection|Smoke and Fire Detection|Calling Detection|No Mask Detection|Rat Detection|Long Stay Detection|Fall Detection|Fight Detection|Absence Detection|Quick Moving|People Dispersion|People Gathering|Using Mobile Phone Detection|No Reflective Clothing Detection|Sleep on Dut |
|---|
| Video Metadata Type | Length, Lower Garment Length, Upper Garment Color, Lower Garment Color|Non-Motor Vehicle: Non-Motor Vehicle Type, Direction, Gender, Age, Upper Garment Length, Upper Garment Color Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total 2 millions records for SIP|2 millions records for |
|---|
| Capacity of Snapshot Records | vehicle snapshot|3 millions records for face snapshot Defocus Detection|Scene Change Detection|Object Left Behind|Object Removed|Auto Tracking|Motion Detection|Tampering|Human Body Detection|Video Loss|Audio Detection|Alarm Input IP Conflict|Network Disconnected|Disk Offline|Disk Abnormal|Illegal Access|Hard Disk Space Low|Hard Disk Full|Recording/Snapshot Abnormal|High CPU Temperature|High Mother |
|---|
| SATA | 8 SATA Interfaces Up to 24 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size, The environment temperature for use should not exceed 40°C.) |
|---|
| Disk Group | Support |
|---|
| Redundant Storage | Support |
|---|
| Disk Array Type | RAID 0, 1, 5, 6, 10 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface Muli-access, load balance, network fault-tolerance |
|---|
| USB | Front panel: 2 × USB2.0|Rear panel: 2 × USB3.0 |
|---|
| RS485 | 1 |
|---|
| RS232 | 1 |
|---|
| Alarm In | 16-ch |
|---|
| Alarm Out | 10-ch |
|---|
| eSATA | 1 |
|---|
| miniSAS HD | N/A |
|---|
| miniSAS | N/A |
|---|
| 電源輸出 | 12 V |
|---|
| Extension Board | 1 |
|---|
| Buzzer | Support |
|---|
| 供電 | AC 220 V |
|---|
| Power Switch | Support |
|---|
| Redundant Power Supply | N/A |
|---|
| PoE Interface | N/A |
|---|
| Max Power | N/A |
|---|
| Supported Standard | N/A |
|---|
| 工作溫度 | -10 ℃ to 55 ℃ (14 ℉ to 131 ℉) |
|---|
| 工作濕度 | ≤ 90% RH (non-condensing) ≤50W |
|---|
| Heat Dissipation | Fan|Radiator 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, |
|---|
| GUI Language | Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
|---|
| Certification | CE; FCC; UL; RoHS; WEEE EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130 |
|---|
| FCC | Part15 Subpart B |
|---|
| Preset Num | 32 |
|---|
| N+1 Hot Spare | Support |
|---|
| Fisheye Dewarping by IPC | Support |
|---|
| ANR | Support |
|---|
| Dual-lens Cameras | Support |
|---|
| Downlink ONVIF | Support (Profile S) |
|---|
| Box-Dome Linkage | Support |
|---|
| Uplink ONVIF | N/A Support |
|---|
| UCS (Web socket) | Support |
|---|
| NAS | Support |
|---|
| Ucode Basic Mode | Support |
|---|
| Ucode Advanced Mode | Support |
|---|
| Output Mode | N/A |
|---|
| NDAA Compliant | Support Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
