| 解碼格式 | Ultra 265, H.265, H.264 Smart off: H265: 3 x 12MP@25, 5 x 4K@30, 8 x 5MP@30, 10 x 4MP@30, 13 x 3MP@30, 16 x 1080P@30, 27 x 960P@25, 32 x 720P@30, 64 x D1@30 H264: 2 x 12MP@25, 4 x 4K@30, 4 x 5MP@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30, 27 x 960P@25, 32 x 720P@30, 64 x D1@30 Smart on: |
|---|
| When Smart by NVR on, | the decoding capacity is same as Smart off. The resolution of each channel cannot exceed 4096 pixels in length or width| For VGA/HDMI |
|---|
| 解碼能力 | independent output, the VGA live video is |
|---|
| Description | output by default. To output the highest resolution video from the HDMI port, please clear the VGA video on the preview page. |
|---|
| 音訊壓縮 | G.711A, G.711U |
|---|
| 入口頻寬 | 512 Mbps |
|---|
| 出口頻寬 | 512 Mbps |
|---|
| Max Remote Users | 128 TCP/IP|P2P| UPnP| NTP| DHCP| PPPoE| HTTP| |
|---|
| 網絡協議 | HTTPS| DNS| DDNS| SNMP|SMTP|NFS|RTSP|802.1x| IPv6|IPv4 |
|---|
| Browser (Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
|---|
| IP 視頻輸入 | 64-ch |
|---|
| RCA Audio Input | 1-ch 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, |
|---|
| HDMI 輸出 | 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|---|
| VGA 輸出 | 1920 × 1080/60 Hz, 1280 × 720/60 Hz |
|---|
| RCA Audio Output | 1-ch VGA:1/4/6/8/9/16/25/36, HDMI1/HDMI2:1/4/6/8/9/16/25/36/64 |
|---|
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
|---|
| 雙向語音 | 1-ch, RCA (Using the audio input and output) Full-ch snapshot (max. 4000 × 3000 video resolution, with snapshot resolution same as the video resolution) 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF 16-ch Face Detection|Face Comparison|Vehicle Detection|SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area)|Ultra Motion Detection (UMD)|Temperature |
|---|
| VCA Detection by IPC | Detection (Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection)|People Counting (People Flow Counting, Crowd Density Monitoring)|Video Metadata|Traffic Monitoring All channels (up to 64 images/s in total)Face Detection, Face Comparison, Vehicle Detection, Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring Face Detection|Face Comparison|Smart Intrus |
|---|
| face detection by NVR | 32-ch |
|---|
| Search by Image | Support 32-ch 32-ch Motor Vehicle: Vehicle Color, Vehicle Type, Vehicle Brand, Direction. Non-Motor Vehicle: Non-Motor Vehicle Type, Direction, Gender, Age, Upper Garment Length. Human Body: Gender, Age, Mask, Hairstyle, Bag Style, Direction, Upper Garment Length, Lower Garment Length. Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total Defocus Detection|Scene Change Det |
|---|
| SATA | 16 SATA Interfaces Up to 16 TB for each HDD (The maximum HDD |
|---|
| 容量 | capacity varies with environment temperature) |
|---|
| Disk Group | Support |
|---|
| Redundant Storage | Support |
|---|
| Disk Array Type | RAID 0, 1, 5, 6, 10, 50, 60 |
|---|
| Hot Swap | Support 4 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface |
|---|
| USB | Front panel: 2 × USB2.0|Rear panel: 2 × USB3.0 |
|---|
| RS485 | 1 |
|---|
| RS232 | 1 |
|---|
| Alarm In | 24-ch |
|---|
| Alarm Out | 8-ch |
|---|
| eSATA | 1 |
|---|
| miniSAS | 2 |
|---|
| 電源輸出 | 12 V |
|---|
| 供電 | AC 100 to 240 V |
|---|
| Power Switch | Support |
|---|
| Redundant Power Supply | Support |
|---|
| 工作溫度 | -10 ℃ to 50 ℃ (14 ℉ to 122 ℉) |
|---|
| 工作濕度 | ≤ 90% RH (non-condensing) ≤ 200W |
|---|
| Weight (without HDD) | ≤ 12.5Kg (27.56lb) |
|---|
| Height | 3U |
|---|
| 尺寸 | 482mm × 533mm × 131mm (19.0"×21.0"×5.1") 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, |
|---|
| GUI Language | Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
|---|
| Certification | CE; FCC; UL; RoHS; WEEE EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
|---|
| FCC | Part15 Subpart B |
|---|
| FB-HD04-B-NB | FB-HD07-B-NB DEU1016-B 4-ch HDMI Output Decoding Card 7-ch HDMI Output Decoding Card 16 HDDs 3U Disk Enclosure |
|---|
| SL-A | PWR-DC12-350A-IN |
|---|
| Slide Rail | 350W Power Accessories Module Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
|---|
