Uniview PKC2641-Z28-P 為PKC2641-Z28-(IR)-P，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 PKC2641-Z28-P 香港價格連安裝報價。
| Sensor | 1/1.8-inch 4MP CMOS |
|---|---|
| 焦距 | 2.8 to 12mm |
| Shutter | Auto, range: 1/200 to 1/100000s |
| Minimum illumination | 0.0005lux (F1.4) Horizontal FOV: 106.4° to 50.3°, |
| 視場角 FOV | Vertical FOV: 57.1° to 27.8°, Diagonal FOV: 127.4° to 57.3° |
| WDR | 120 dB |
| S/N | > 50 dB |
| Image collection format | 2688*1520@60,2688*1520@50,2688*1520@30 (default),2688*1520@25 |
| Frame rate | 60, 50, 30 (default), 25, 22, 20, 18, 16, 15, 12.5, 10, 8, 6, 5, 4, 3, 2, 1 |
| 視頻壓縮 | H.264 (default), H.265 |
| ROI | Supports up to 8 regions |
| HLC | Support |
| BLC | Support |
| 除霧 | Digital defog |
| Digital Noise Reduction | 3D DNR Supports 8 overlay areas and allows contents including date, time, date&time, zoom ratio, custom contents Supports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location Main stream: 2688*1520, 1080P (default), 720P, D1; Sub stream: 720P (default), D1, 2CIF, CIF; Third stream: D1 |
| Vehicle detection mode | Supports video detection Supports recognition of license plates with numbers and letters by default Supports allowlist and blocklist configuration, each list allows 20,000 items Supports import, export, add, and delete operations Open barrier only for the recognized vehicles Open barrier for all vehicles |
| Barrier opening policy | Open barrier only for vehicles on the allowlist Open barrier for vehicles not on the blocklist Configurable Boolean output ID |
| Country and Region | United States, Canada, Saudi Arabia, United Arab Emirates, Qatar, Singapore, Malaysia, |
| Supported | Indonesia, Vietnam, Thailand, India, Bangladesh, Cambodia, South Korea, Kyrgyzstan, Tajikistan, Kazakhstan, Uzbekistan, Turkmenistan, Egypt, Tunisia, Brazil, Argentina, Mexico, Finland, Estonia, Latvia, Lithuania, Poland, France, Spain, Portugal, Germany, United Kingdom, Ireland, Bulgaria, Romania, Hungary, Serbia, Bosnia and Herzegovina, Greece, Croatia, Italy, Netherlands, Sweden, Belgium, Austr |
| Detection Direction | Bidirectional、Top to Bottom、Bottom to Top |
| Vehicle Type Recognition | Car/Van/Large Bus/Medium Bus/Heavy Truck/Light Truck/SUV/MPV/Pickup/Motorcycle |
| Vehicle Color Recognition | Red, Yellow, green, blue, purple, pink, brown, white, Grey, black, silver, orange 133 Manufacturers: Audi, ALFA ROMEO, AION, ANKAI, ACURA, Aston Martin, ARCFOX, BYD, BUICK, BENTLEY, BMW, BAIC MOTOR, BUGATTI, BORGWARD, Beiben Truck, Besturn, CHANGAN, Citroën, Cadillac, CHERY, CHRYSLER, Chevrolet, CHTC, DONGFENG, DACIA, Daihatsu, DATSUN, DODGE, DS, DAEWOO, Dongnan, EXEED, FAW, Ford, FORLAND, Ferrari |
| Edge storage | Supports ANR with a Micro SD card, up to 512GB |
| Built-in integrated illumination module, | Built-in integrated illumination module, |
| Illumination | including 4 warm light LEDs, 50m illumination including4 IR LEDs, 50m illumination distance, |
| distance, automatic on/off control | automatic on/off control |
| Bracket | 3-axis mounting bracket |
| Junction box | The camera comes with a junction box for storing tail cable IGMP,IPv6,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTSP,DNS,DDNS,NTP,UPnP,HTTP,HTTPS,802.1x,SN MP,QoS,SSL/TLS,SSH,IPv4 ONVIF (Profile S, Profile G, Profile T),SDK, API |
| 網絡接口 | 1×10M/100M RJ45 |
| Serial port | 2 × RS485 |
| Boolean output | 2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A |
| Boolean input | 2 x input, supports level (up to DC 5V) and switch signal |
| Audio interface | 1 × audio input, 1 × audio output |
| Storage interface | 1 × Micro SD card slot |
| Reset button | Support |
| Wiegand Interface | Supports Wiegand output |
| 重量 | 1.87kg |
| 防護等級 | IP67, IK10 DC12V + 25% - 25% |
| 供電 | Max. power consumption: 20W Supports PoE (802.3at, class 4) |
| Dimensions (L×W×H) | 406mm x 126mm x 130mm |
| Operating environment | -40℃ to 60℃, ≤90% RH |
| Heater | N/A |
| NDAA Compliant | Support CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 61000-3-3:2013+A1:2019+A2:2021,EN IEC |
| EMC | 61000-3-2:2019+A1:2021, EN 50130-4:2011+A1:2014) FCC(FCC CFR 47 part15 B,ANSI C63.4 2014) EN IEC 62368-1:2020+A11:2020 UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863);WEEE (2012/19/EU) IP67(IEC60529:1989+AMD1:1999+AMD2:2013) IK10(IEC 62262:2002+AMD1:2021) |
| TR-UP06-C-IN | TR-UP06-C-IN-V2 |
| Pole Mounting Bracket for Bullet Junction | Pole Mounting Bracket for Bullet Junction |
| Box Only | Box Only Unlimited New View http://www.uniview.com overseasbusiness@uniview.com; globalsupport@uniview.com No. 369, Xietong Road, Xixing Sub-district, Binjiang District, Hangzhou City, 310051, Zhejiang Province, China |
* 規格以原廠最新 Datasheet 為準。
下載完整PDF規格書 →
詳見圖示｜Unit: mm
PKC2641-Z28-P Uniview PKC2641-Z28-(IR)-P亦適合以下專業服務機構使用，保安同合規要求同一般商鋪唔一樣，歡迎查詢度身方案。
HKEZIT 提供原廠行貨連保養，PKC2641-Z28-P 原廠行貨連保養，提供上門評估、安裝、調試及使用教學一站式服務，全港 32 區均有服務。
支援 PoE 供電時一條網線同時傳輸數據與電力，無需另行鋪設電源線；詳細供電規格請參閱上方規格表，安裝時我們會按現場環境設計走線。
儲存時間取決於解像度、碼率及硬碟容量，配合 H.265+ 壓縮可大幅延長；透過 EZView/EZLive App 可隨時遠程實時監看及回放，無需固定 IP。
兩者主要規格分別：Sensor方面，PKC2641-Z28-P 係 1/1.8-inch 4MP CMOS，PKC1150-4-Z28-C-P 係 1/2.7" 5MP CMOS；焦距方面，PKC2641-Z28-P 係 2.8 to 12mm，PKC1150-4-Z28-C-P 係 2.8mm to 12mm zoom lens；Shutter方面，PKC2641-Z28-P 係 Auto, range: 1/200 to 1/100000s，PKC1150-4-Z28-C-P 係 1/100000 to 1/25s。實際邊個型號更適合，需視乎現場環境同需求而定，可先比較 PKC1150-4-Z28-C-P 詳細規格，或直接聯絡我們免費現場評估，由工程師建議最合適方案。
HKEZIT 提供 PKC2641-Z28-P 原廠行貨連保養，安裝後如有故障可直接聯絡我們安排上門維修，毋須自行聯絡原廠。詳情請參閱CCTV 監控安裝工程頁面或聯絡我們查詢保養範圍。
HKEZIT 於全港各區提供 PKC2641-Z28-P Uniview PKC2641-Z28-(IR)-P供貨連專業安裝服務（裝CAM、裝CCTV、裝監控），熱門地區包括：大圍CCTV 閉路電視安裝、大埔CCTV 閉路電視安裝、大角咀CCTV 閉路電視安裝、將軍澳CCTV 閉路電視安裝、尖沙咀CCTV 閉路電視安裝、屯門CCTV 閉路電視安裝、旺角CCTV 閉路電視安裝、柴灣CCTV 閉路電視安裝。港島、九龍、新界全港 32 區均有上門安裝，歡迎聯絡我們查詢 PKC2641-Z28-P 香港價格連安裝報價。
PKC2641-Z28-P Uniview PKC2641-Z28-(IR)-P適合多種場景使用，以下為部分常見安裝場景，歡迎查詢是否適合您的現場環境。
婦產科診所裝 CCTV 監控候診區同超聲波檢查儀器，診症室私隱合規佈點不入鏡治療過程，超聲波檢查室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →心臟科診所裝 CCTV 監控候診區同心電圖同心臟監測儀器，診症室私隱合規佈點不入鏡治療過程，心臟儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →脊醫／物理治療中心裝 CCTV 監控候診區同衝擊波同物理治療儀器，診症室私隱合規佈點不入鏡治療過程，治療儀器室防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →兒科診所裝 CCTV 監控候診區同疫苗冷藏及診斷儀器，診症室私隱合規佈點不入鏡治療過程，候診及診症區防盜同醫療糾紛錄影存證。免費上門評估，銅鑼灣、尖沙咀專科醫務中心即約報價。免費現場勘察、報價清晰透明，香港、新界一帶即日上門。
WhatsApp 查詢 →商鋪裝 CCTV、裝 CAM 防盜防搶，收銀防糾紛、客流統計一目了然。店舖閉路電視覆蓋舖面死角，老闆手機隨時睇舖。明碼實價報價、免費上門度尺，香港、尖沙咀等旺區商舖即日約勘。專業團隊免費上門評估，香港、新界一帶即日上門。
WhatsApp 查詢 →多間分店閉路電視集中管理，總部一個平台遠端查看各舖即時畫面與錄影。連鎖店監控系統支援客流分析、跨店比對，安裝 CCTV 統一規格方便擴充。統一規格報價、總部一站對接，新界、九龍等核心商圈分店歡迎查詢。免費現場勘察、報價清晰透明，
WhatsApp 查詢 →查看更多CCTV 監控適用場景，請參閱 CCTV 監控安裝工程。
如需整套CCTV 監控方案，請參閱 CCTV 監控安裝工程。
