HANWHA SNO-L6013R CCTV攝影機安裝・保養

Name: HANWHA SNO-L6013R 2Megapixel Full HD Weatherproof Network IR Camera
Brand: hanwha
SKU: SNO-L6013R

產品簡介

hanwha SNO-L6013R 為2Megapixel Full HD Weatherproof Network IR Camera，HKEZIT 提供原廠行貨連保養、上門安裝、調試及使用教學一站式服務。詳細規格以下方原廠 Datasheet 欄位為準，歡迎聯絡我們查詢 SNO-L6013R 香港價格連安裝報價。

Imaging Device：1/2.9" 2.19M CMOS
Total Pixels：2,000(H) x 1,121(V)
Effective Pixels：1,984(H) x 1,105(V)
Scanning System：Progressive
最低照度：Color : 0.15Lux (1/30sec, F1.8), 0.003Lux (2sec, F1.8) B/W

HKEZIT 提供原廠行貨保養。硬件連專業安裝、設定及使用教學一站式報價，無需自行研究安裝與設定。我們同時承接裝CAM、裝CCTV、裝監控工程，硬件與工程同一團隊負責。

查詢價格連安裝 →

SNO-L6013R hanwha 2Megapixel Full HD Weatherproof Network IR Camera 產品圖片

詳細規格

Imaging Device	1/2.9" 2.19M CMOS
Total Pixels	2,000(H) x 1,121(V)
Effective Pixels	1,984(H) x 1,105(V)
Scanning System	Progressive
最低照度	Color : 0.15Lux (1/30sec, F1.8), 0.003Lux (2sec, F1.8) B/W : 0Lux (IR LED on)
Focal Length (Zoom Ratio)	3.6mm fixed
Max. Aperture Ratio	F1.8
Angular Field of View	H : 86.5˚ / V : 47.8˚ / D : 101.2˚
Min. Object Distance	0.5m (1.64ft)
鏡頭類型	Fixed
Mount Type	Board type Operational
IR Viewable Length	20m (65.62ft)
Camera Title	Off / On (Displayed up to 15 characters)
日夜切換	True Day & Night
Backlight Compensation	Off / BLC Contrast Enhancement (DWDR) SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction	SSNR (Off / On)
Motion Detection	Off / On (4ea rectangular zones)
Privacy Masking	Off / On (6ea rectangular zones)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor LDC (Lens Distortion Correction) Off / On (5 levels with min / max)
Electronic Shutter Speed	Minimum / Maximum / Anti flicker
Flip / Mirror	Flip / Mirror / Hallway view
Key Features	Intelligent Video Analytics Motion detection with metadata, Tampering
Alarm Triggers	Motion detection, Tampering detection, SD card error, NAS error
Alarm Events	File upload via FTP and E-mail, Local storage recording at event, Notification via E-mail
• Max. 2M (1920 x 1080) resolution	Network
• 3.6mm fixed lens	Ethernet RJ-45 (10/100BASE-T)
Video Compression Format	H.264, MJPEG Resolution 800 x 600, 720 x 576, 640 x 480, 320 x 240 H.264 : Max. 30fps at all resolutions Max. 15fps at other resolution
• Motion detection, Tampering, DWDR	Video Quality Adjustment H.264 : Target bitrate level control, MJPEG : Quality level control
• micro SD/SDHC memory slot, PoE	Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 3 profiles)
• IR viewable length 20m, IP66	Audio I/O Line in G.711 u-law / G.726 selectable
• Hallway view support (Rotate 90˚/270˚)	Audio Compression Format G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
尺寸	Unit : mm (inch)
安全	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	6 users at unicast mode micro SD/SDHC max. 32G, NAS
Storage	- Motion images recorded in the SD memory card can be downloaded - Manual recording at local PC Application Programming Interface ONVIF Profile S, G, SUNAPI (HTTP API) English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Webpage Language	Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish 103.8 103.8(4.09") (4.09") Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 35),
Web Viewer	Google Chrome (Ver. 15 ~ 40), Apple Safari (Ver. 8.0.2(Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) (2.86") 72.6 (2.86") * Mac OS X only
Central Management Software	SmartViewer 72.6 Environmental Operating Temperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -20°C (-4°F) Ø58.6 Ø58.6 (2.31") (2.31") Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH 165.2 (6.5") 165.2 (6.5")
防護等級	IP66 67.9 67.9 (2.67") (2.67") 181.5 181.5 (7.15") (7.15") Electrical
Input Voltage / Current	PoE (IEEE802.3af, Class2)
功耗	Max. 5.7W
Color / Material	Dark gray / Plastic
Dimensions (WxH)	Ø58.6 x 165.2mm (Ø2.31" x 6.5") (Without sunshield)
重量	250g (0.55 lb) * The latest product information / specification can be found at www.samsungsecurity.com mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur when a memory card reaches end of life, which varies according to operational conditions. No guarantee is given against damage (including passive damage). 11-09-2015 ⓒ 2015 Hanwha TECHWIN CO., LTD.
